Shacman F2000&F3000 Man 7.5 Ton Drum Steering Shaft

  • The Shacman F2000&F3000 Man 7.5 Ton Drum Steering Shaft is a crucial component essential for steering control and stability in heavy-duty vehicles.
  • This steering shaft configuration includes several important parts such as brake camshafts (left and right), axle packing rings, quill rollers, hex nuts, air-chamber bearers (left and right), pin axles, cotter pins, hex bolts, bushings, automatic gap adjusting arms, indicating plates, brake shoe adjusting washers, washers, circlips for axles, brake air-chambers (left and right),prevented dust caps (right and left), steering knuckle, packing bulkhead, brake floor, protection blocks, hex flange surface bolts, ABS pulse gear rings, packing rings for axles, radial-row-steep roller bearings, oil baffle covers, wheel bolts, front wheel hubs, stop washers, brake drums, wheel nuts, nuts, hex cylinder screws, and wheel hub caps.

Product Parameters of Shacman F2000&F3000 Man 7.5 Ton Drum Steering Shaft

Shacman F2000&F3000 Man7.5 Ton Drum Steering Shaft
Download Catalog
Get Quotation
Whatsapp
  • Each component is meticulously designed and assembled to ensure optimal steering performance and durability under challenging conditions.
  • The Shacman F2000&F3000 Man 7.5 Ton Drum Steering Shaft plays a critical role in providing smooth and responsive steering capabilities, enhancing the overall control and safety of heavy-duty vehicles on the road.
NOPart.NoNameQuantity
181.50301.0223Brake camshaft (left)1
81.50301.0224Brake camshaft (right)1
281.96502.6040Axle packing ring2
381.93404.6005Quill roller4
4Q341B16F6Hex nut4
Q40516F64
581.50310.0313Air-chamber bearer（left）1
81.50310.0312Air-chamber bearer（right）1
606.21569.0077Pin axle2
7Q5004025Cotter pin2
881.96502.6039Axle packing ring2
9Q151B1690TF2Hex bolt4
1081.91710.0163Bushing2
1181.50610.6231Automatic gap adjusting arm2
12Q150B0812Hex bolt2
1381.90711.0714Indicating plate2
1481.90711.0705Brake shoe adjusting washeras needed
81.90711.0706Brake shoe adjusting washeras needed
1581.90711.0707Brake shoe adjusting washeras needed
1681.90701.0769Washer2
17Q43134Circlip for axle2
81.51101.6264Brake air-chamber（left）1
1881.51101.6265Brake air-chamber（right）1
19Q40114Washer2
2081.50101.0224Prevented dust cap (right)2
NOPart.NoNameQuantity
2181.44201.0143Steering knuckle2
2281.96002.0098Packing hulkhead4
23Q150B1012Hex bolt12
2481.50101.0223Prevented dust cap (left)2
2581.96002.0075Packing hulkhead4
2681.50202.0108Brake floor2
27Q151B1640TF2Hex bolt8
28Q151B1635TF2Hex bolt4
2981.90801.0225Protection block2
30Q184A1018TF2Hex flange surfaces bolt2
31Q151B16120TF2Hex bolt4
3281.52403.0008ABS pulse gear ring2
81.96502.6045Packing ring for axle2
3381.93420.0074Radial- row-steep roller bearing2
34HD90009410004Oil baffle cover2
3581.45501.0102Wheel bolt20
36HD90009410040Front wheel hub2
37HD90009410005Oil baffle cover2
38HD95009410007Radial- row-steep roller bearing2
3981.44215.0016Stop washer2
4081.50110.0232Brake drum2
41190003884160Wheel nut20
4281.92901.0066Nut2
43Q218B1040TF2Hex cylinder screw2
4481.44312.0009Wheel hub cap2
NOPart.NoNameQuantity
45Q2541020Bolt4
4681.97610.0115Return spring4
DZ95009440015Return spring4
4781.50211.0018Return spring pin4
DZ95009440010Return spring pin4
48Q43112F3Circlip for axle8
4981.50211.0030Pin4
5081.50201.0137Brake shoe4
DZ95009440006Brake shoe4
5181.50213.0013Roller4
5281.93021.0220Bush4
5306.15113.2615Washer4
54190003933072Circlip for axle4
5581.93021.0117Bush4
5681.50212.0032Brake shoe pin4
5781.50221.0540Lower brake friction plate4
5881.92201.0109Hollowness clincher72
5981.50221.0535Upon brake friction plate4
60DZ9100410055Front axle1
DZ9100410071Front axle1
DZ9100410058Front axle1
6181.46711.6725Steering cross rod1
6281.90610.0015Hex slit bolt2
63Q5005050Cotter pin2
64Q151B22100TF2SHex bolt4
NOPart.NoNameQuantity
6581.46701.0243Steering trapezium arm (left)1
81.46701.0244Steering trapezium arm (right)1
HD95009410031Steering trapezium arm (left)1
HD95009410032Steering trapezium arm (right)1
66199000520096Protect cover4
67190003963114Grease nipple4
68Q43058Circlip for hole4
6981.90711.0941Packing disc4
7081.96501.0671Packing ring4
7181.90770.0096Washer2
7281.93402.6003Quilll roller bearing2
7381.96502.6044Packing ring for axle4
7406.32819.0017Push row-steep roller bearing2
75HD95009410001Fixed bolt2
HD95009410001Fixed bolt2
76Q341B16Hex nut2
7781.96002.0131Packing bulkhead2
7881.46705.0383Steering knuckle arm1
81.46705.0381Steering knuckle arm1
81.46705.0267Left steering knuckle arm1
79Q151B2275TF2SHex bolt2
80DZ9100580214Sensor2
81DZ9100580215Sensor sleevr2
81.96002.0368Packing bulkhead2
8281.44205.0057Steering knuckle pin2
NOPart.No NameQuantity
8381.90711.0671Adjusting washeras needed
 DZ95009410031Adjusting washeras needed
 81.90711.0672Adjusting washeras needed
 DZ95009410032Adjusting washeras needed
 81.90711.0673Adjusting washeras needed
 DZ95009410033Adjusting washeras needed
 81.90711.0674Adjusting washeras needed
 DZ95009410034Adjusting washeras needed
 81.90711.0675Adjusting washeras needed
 DZ95009410035Adjusting washeras needed
 81.90711.0676Adjusting washeras needed
 DZ95009410036Adjusting washeras needed
 DZ95009410037Adjusting washeras needed
 DZ95009410038Adjusting washeras needed
 81.90711.0677Adjusting washeras needed
 81.90711.0678Adjusting washeras needed
 81.90711.0679Adjusting washeras needed
8481.93020.0706Top bush2
