Pipe Clamp Assembly
Хомут трубопровода в сборе
Conjunto de abrazadera de tubería
The 1000950624 OEM Pipe Clamp Assembly is a precision-engineered heavy-duty retention system manufactured exclusively for the Shacman X5000 truck platform. This complete assembly securely anchors pipes, hoses, and tubes to the vehicle chassis, engine block, and body structure, providing the robust, vibration-resistant mounting that prevents movement, chafing, and fatigue cracking of fluid and air lines under the constant dynamic loads and harsh environmental conditions of heavy-duty truck operation.
Constructed with a high-strength steel clamp body, an elastomeric cushioning liner that isolates vibration and prevents pipe surface damage, and a dedicated mounting bracket or bolt-on base with precision-punched bolt holes, the pipe clamp assembly delivers exceptional clamping force, vibration damping, and long-term corrosion resistance. The 1000950624 part features a precisely formed clamp profile that perfectly conforms to the outer diameter of the specified pipe or hose.
Installing genuine OEM pipe clamp assemblies preserves the designed routing security of all fluid and air lines and prevents the cascading failures that can result from a single loose or failed clamp. The 1000950624 identifier provides complete traceability to Shacman’s rigorous material specifications and precision manufacturing quality assurance standards for this essential retention and protection component.
| Parameter | Specification | Details |
|---|---|---|
| OEM Part Number | 1000950624 | Unique Shacman X5000 identifier |
| Product Name | Pipe Clamp Assembly | Complete retention system with mounting base |
| Brand / Vehicle Model | Shacman X5000 | Heavy-duty truck series |
| Clamp Body Material | High-strength steel | Rigid and durable pipe retention |
| Cushioning Liner | Elastomeric rubber or EPDM | Absorbs vibration and prevents pipe chafing |
| Mounting Base | Integrated bracket or bolt-on flange | Secure attachment to vehicle structure |
| Surface Finish | Zinc-plated or coated | Excellent corrosion and road chemical resistance |
| Clamp Diameter | Precision sized to pipe outer diameter | Firm grip without pipe deformation |
| Application | Engine, chassis, and body fluid line systems | Secures pipes and hoses to vehicle structure |
| Packaging | Protective sealed packaging | Shacman genuine labeled packaging |
The assembly firmly anchors pipes and hoses to the vehicle structure, preventing the movement that could cause contact with hot, sharp, or moving components, kinking that restricts fluid flow, or fatigue cracking from vibration.
The 1000950624 assembly’s elastomeric liner absorbs engine and road vibrations, isolating the retained pipe from high-frequency oscillations that would otherwise cause fatigue and premature failure.
The cushioning liner creates a protective barrier between the pipe and the metal clamp body, preventing the abrasive wear that would eventually wear through the pipe wall and cause a dangerous fluid or air leak.
The pipe clamp assembly 1000950624 is installed by mounting its base to a designated location on the Shacman X5000 vehicle chassis, engine, or body structure using the specified bolts. Before installation, the mounting surface must be clean and free of debris or corrosion. The clamp base is positioned and the mounting fasteners are torqued to the factory specification. The pipe or hose is then placed into the open clamp, the cushioning liner is positioned correctly around the pipe, and the clamp is closed and secured. The clamp fasteners are tightened evenly to the specified torque, taking care not to overtighten and compress the cushioning liner excessively, which would reduce its vibration-damping effectiveness. After installation, the pipe should be checked to ensure it is held firmly but not crushed, and that it has adequate clearance from adjacent components, moving parts, and heat sources along its entire routed length.
Each pipe clamp assembly produced under OEM number 1000950624 is manufactured from high-quality materials selected for their specific functions. The steel clamp body and mounting base are precision-stamped or formed from high-strength steel, then undergo a zinc electroplating or coating process that provides excellent corrosion protection. The elastomeric cushioning liner is molded from EPDM rubber or similar material formulated for resistance to heat, ozone, oil, and the road chemicals encountered in the under-chassis and under-hood environment.
The components are assembled with the liner securely bonded or mechanically retained within the clamp body. Each completed assembly undergoes dimensional inspection to verify correct clamp diameter, mounting hole positions, and overall geometry. The clamping force is verified to ensure it meets the specified retention requirements without exceeding the pipe crush limit. The elastomeric liner is inspected for correct material, hardness, and freedom from defects. The completed assemblies are packaged in sealed, protective packaging and labeled with the 1000950624 part number for complete traceability throughout the supply chain.
Pipe clamp assemblies should be visually inspected during routine vehicle service for any signs of corrosion, cracking, loosening, or deterioration of the cushioning liner. A clamp that shows visible rust or damage to the metal body may be weakened and should be replaced. The elastomeric liner should be checked for cracking, hardening, or compression set that would reduce its vibration-damping ability. Any missing, damaged, or deteriorated clamp must be replaced immediately.
Whenever a pipe or hose that passes through a clamp assembly is replaced, it is good practice to replace the clamp assembly as well, especially if the cushioning liner has taken a set from the old pipe. A worn or compressed liner will not provide adequate cushioning for the new pipe, potentially leading to premature chafing and wear. The cost of a new clamp assembly is minimal compared to the potential consequences of a failed pipe causing fluid loss, engine damage, or a vehicle fire from leaking fuel or oil.
Procuring the authentic pipe clamp assembly for your Shacman X5000 vehicle service is a simple process that ensures reliable pipe retention and protection. Use the inquiry button above to verify current stock availability and request a prompt quotation. We maintain comprehensive inventory of these essential retention components to support both individual system repairs and complete fleet maintenance programs across all international markets.
To ensure you receive the exact factory-specified clamp assembly with correct diameter, mounting configuration, and liner material for your application, always reference the OEM part number 1000950624 in your purchase order. Our logistics team provides complete export documentation with every international shipment for efficient customs clearance and inventory verification at your facility.
