The Shacman Door Window Control Unit DZ95189586606 represents the pinnacle of automotive engineering excellence, designed specifically for Shacman commercial vehicles. This genuine OEM part ensures perfect compatibility and reliable performance, providing seamless operation of your truck’s power windows. The control unit DZ95189586606 is built to withstand the rigorous demands of commercial use, offering exceptional durability and long-lasting service life. With its advanced electronic protection features, this component prevents overload and short-circuit situations, safeguarding your vehicle’s electrical system. The precise engineering of the DZ95189586606 model guarantees smooth window operation, enhancing driver comfort and convenience during long hauls.
Engineered to meet Shacman’s strict quality standards, the door window control unit undergoes rigorous testing to ensure optimal performance in various environmental conditions. The DZ95189586606 unit features robust construction with high-quality materials that resist wear, corrosion, and temperature fluctuations. This component is essential for maintaining the functionality of your vehicle’s power window system, providing consistent operation without failure. The integration of advanced circuitry ensures quick response times when operating windows, while the compact design allows for easy installation in the designated door panel space. Fleet managers and individual operators can trust this genuine Shacman part to deliver uncompromising performance and reliability.
| Parameter | Specification |
|---|---|
| OEM Number | DZ95189586606 |
| Product Name | Door Window Control Unit |
| Brand | Shacman |
| Voltage Rating | 24V DC |
| Current Capacity | Up to 20A |
| Operating Temperature | -40°C to +85°C |
| Weight | Approximately 0.45 kg |
| Dimensions | 120mm x 80mm x 40mm |
| Housing Material | High-strength ABS Plastic |
| IP Rating | IP54 (Dust and Water Resistant) |
| Connector Type | Weather-proof 12-pin |
| Compatibility | Shacman F3000, M3000, X3000 Series |
The Shacman Door Window Control Unit DZ95189586606 incorporates multiple advanced features that distinguish it from aftermarket alternatives. Its intelligent circuit design includes overload protection that automatically cuts power during obstruction detection, preventing motor burnout and potential injuries. The unit features reverse polarity protection, safeguarding against accidental incorrect connections during installation or maintenance. With its robust microcontroller, the DZ95189586606 ensures precise control of window movement, allowing for smooth operation without jerky motions. The integrated thermal protection mechanism prevents overheating during extended use, particularly important in regions with extreme temperatures.
Another significant advantage of the DZ95189586606 control unit is its plug-and-play compatibility with Shacman vehicles. The precise engineering ensures perfect fitment without modifications, saving valuable time during installation. The unit maintains consistent performance throughout its service life, with minimal voltage drop across connections for reliable operation even when the electrical system is under load. The quality construction using automotive-grade components ensures resistance to vibration, moisture, and dust ingress – common challenges in commercial vehicle operations. These features collectively contribute to enhanced safety, convenience, and longevity for Shacman truck owners and operators.
Durability stands as a cornerstone of the DZ95189586606 door window control unit’s design. The high-strength ABS plastic housing provides excellent impact resistance while remaining lightweight. All internal components are securely mounted to withstand the constant vibration experienced in commercial vehicle applications. The PCB features conformal coating that protects against moisture, corrosion, and chemical exposure. Gold-plated connectors ensure minimal resistance and prevent oxidation, maintaining electrical integrity over years of service. This attention to durability details translates to reduced replacement frequency and lower total cost of ownership for fleet managers.
Safety integration within the DZ95189586606 control unit exceeds industry standards. The anti-pinch functionality automatically reverses window direction when obstruction is detected, protecting passengers from injury. The system includes fail-safe mechanisms that maintain manual control capability even in the event of partial electronic failure. Short-circuit protection immediately isolates faulty circuits to prevent damage to other electrical systems. These safety features demonstrate Shacman’s commitment to passenger protection and vehicle reliability, making the DZ95189586606 an responsible choice for commercial vehicles subject to rigorous daily use.
The Door Window Control Unit DZ95189586606 is engineered specifically for Shacman commercial vehicles, with verified compatibility across multiple model series. This OEM part seamlessly integrates with Shacman F3000, M3000, and X3000 truck series, providing perfect electrical and physical compatibility. The control unit functions as the central nervous system for power window operations, coordinating between door switches and window motors. Its application extends to both driver and passenger side doors in various cab configurations, including sleeper cabs and day cabs. The universal design approach ensures consistent performance regardless of specific truck configuration.
Beyond original equipment applications, the DZ95189586606 serves as an ideal replacement part for vehicles previously equipped with inferior aftermarket components. Fleet maintenance departments can standardize on this genuine Shacman part to ensure uniform performance across their entire truck inventory. The unit also finds application in refurbishment projects where restoring original functionality is paramount. Logistics companies, construction firms, and transportation services that rely on Shacman vehicles will find this control unit essential for maintaining operational efficiency and driver comfort throughout their fleet’s service life.
Proper installation of the DZ95189586606 Door Window Control Unit begins with disconnecting the vehicle’s battery to ensure electrical safety. Removal of the door panel provides access to the existing control unit, which should be carefully disconnected noting the connector orientation. The new DZ95189586606 unit should be mounted securely using the provided brackets or existing mounting points, ensuring all connectors are fully seated and weather seals are properly positioned. Before reassembling the door panel, conduct a functional test by reconnecting the battery and verifying all window control functions operate correctly through their full range of motion.
Routine maintenance for the window control system primarily involves visual inspection during scheduled service intervals. Check for any signs of water ingress, corrosion on connectors, or damage to wiring harnesses. Listen for unusual noises during window operation that might indicate motor strain or mechanical issues elsewhere in the system. Keep the window channels clean and free of debris to reduce overall system load. Avoid excessive force on window switches and address any slow operation immediately to prevent overloading the control unit. These simple maintenance practices can significantly extend the service life of your DZ95189586606 control unit.
Several common issues may arise with power window systems that the DZ95189586606 control unit can help resolve. If windows operate slowly, first check the battery voltage and electrical connections before suspecting the control unit. Intermittent operation often results from loose connectors or damaged wiring rather than control unit failure. Complete failure of all windows typically indicates a power supply issue or main fuse failure, while single window failure may point to motor issues or switch problems. The robust design of the DZ95189586606 minimizes failure points, but proper diagnostic procedures should always be followed to identify the true root cause of any operational issues.
Every Shacman Door Window Control Unit DZ95189586606 undergoes rigorous quality testing throughout the manufacturing process. From component selection to final assembly, each unit must pass multiple checkpoints ensuring electrical functionality, environmental resistance, and durability. The control units are subjected to temperature cycling tests, vibration tests simulating years of vehicle operation, and electrical load testing beyond normal operating parameters. This comprehensive testing regimen ensures that only units meeting Shacman’s exacting standards reach customers, providing peace of mind that this critical component will perform reliably when needed.
The reliability of the DZ95189586606 control unit stems from Shacman’s extensive experience in commercial vehicle manufacturing. The design incorporates lessons learned from millions of miles of real-world operation across diverse climates and operating conditions. Partnerships with tier-one electronic component suppliers ensure consistent quality of internal elements. Advanced manufacturing techniques including automated soldering and robotic assembly minimize production variations. The result is a control unit that delivers exceptional field performance with minimal failure rates, supporting Shacman’s reputation for building tough, reliable commercial vehicles capable of withstanding demanding operational environments.
The Shacman Door Window Control Unit DZ95189586606 is backed by a comprehensive warranty that covers defects in materials and workmanship. This warranty assurance provides customers with confidence in their purchase, knowing they are investing in a quality product supported by the manufacturer. The specific warranty terms may vary by region and distributor, so customers should consult with their authorized Shacman parts supplier for detailed warranty information applicable to their location. This commitment to customer satisfaction demonstrates Shacman’s confidence in the durability and performance of their genuine components.
Technical support for the DZ95189586606 control unit is available through Shacman’s global network of authorized service centers and distributors. These facilities maintain trained technicians familiar with the installation and troubleshooting of Shacman electrical components. Comprehensive technical documentation including wiring diagrams, installation procedures, and specification sheets ensures proper integration and service. This support infrastructure ensures that customers can access the expertise needed to properly maintain their vehicles, maximizing uptime and operational efficiency for businesses that depend on their Shacman trucks for daily operations.
Selecting genuine Shacman components like the DZ95189586606 Door Window Control Unit offers significant advantages over aftermarket alternatives. Genuine parts are engineered specifically for Shacman vehicles, ensuring perfect fitment, optimal performance, and preserved vehicle warranty coverage. The precise specifications of genuine components maintain the original performance characteristics and reliability designed into the vehicle. Shacman’s rigorous testing protocols and quality control measures ensure consistent performance that aftermarket suppliers often cannot match. These factors combine to provide superior long-term value despite potentially higher initial cost compared to non-genuine alternatives.
Beyond immediate performance benefits, choosing genuine Shacman parts supports the manufacturer’s continued investment in research and development, leading to better vehicles and components in the future. The extensive distribution network for genuine parts ensures availability when needed, reducing vehicle downtime. Technical documentation and support resources are more comprehensive for genuine components, facilitating proper installation and troubleshooting. For these reasons, fleet managers and owner-operators who prioritize reliability, safety, and total cost of ownership consistently choose genuine Shacman parts like the DZ95189586606 Door Window Control Unit for their vehicles.
Thank you for considering the genuine Shacman Door Window Control Unit DZ95189586606 for your vehicle needs. We are confident this quality component will deliver reliable performance and enhanced functionality for your Shacman truck.
