Cooling Module Suspension (Left)
Подвеска модуля охлаждения (Левая)
Suspensión Módulo Refrigeración (Izq)
The Shacman Cooling Module Suspension (Left), bearing the genuine OEM part number **DZ9X259537005**, is a critical vibration isolation and mounting component for the Shacman X5000 heavy-duty truck. This specific left-side suspension unit is engineered to securely yet flexibly support the vehicle’s integrated cooling module assembly. The primary role of the **DZ9X259537005** part is to absorb and dampen engine vibrations, road shocks, and chassis flex before these destructive forces can reach the radiator, condenser, and intercooler. Proper isolation is essential for preventing stress cracks, seam failures, and premature wear in these expensive heat exchange components.
Manufactured to precise Shacman specifications, this left-side suspension ensures the cooling module remains perfectly aligned within the chassis aperture for optimal airflow. It allows for controlled, limited movement to prevent binding or distortion, while firmly preventing excessive sway or drop that could lead to impact damage. A failed suspension mount can cause misalignment, hose strain, and direct damage to the cooling module’s core.
Using the correct OEM suspension, like DZ9X259537005, is vital for system longevity. Universal or worn mounts transfer excessive vibration directly into the cooling module, accelerating metal fatigue in the radiator tubes and tanks. This genuine part is designed with the exact stiffness and damping characteristics required for the X5000’s operating environment.
The suspension plays a key role in overall vehicle reliability. By protecting the cooling module from vibrational stress, it directly contributes to preventing coolant or refrigerant leaks. For fleet managers, this translates to fewer unscheduled stops for cooling system repairs and protection of a major vehicle subsystem.
During cooling system service or after an impact, replacing the DZ9X259537005 suspension as a preventive measure is a best practice. It restores the original factory-installed vibration damping, ensuring the cooling module is supported as intended for the long haul and safeguarding the significant investment in the cooling and air conditioning systems.
The Shacman DZ9X259537005 suspension is defined by its robust, multi-material construction. It typically consists of a metal bracket or frame that provides structural attachment, integrated with a high-performance rubber or polyurethane bushing that delivers the essential vibration damping and isolation properties.
A critical feature is its engineered durometer (hardness) and elasticity. The bushing material is formulated to compress and rebound in a controlled manner, filtering out high-frequency engine vibrations while still providing firm support to prevent excessive module movement during cornering or on rough terrain.
The suspension is designed for precise location. It features vehicle-specific mounting holes, alignment tabs, or a unique shape that ensures it can only be installed in the correct left-side position and orientation on the X5000. This guarantees proper load distribution and module alignment.
The isolation bushing is made from a synthetic rubber compound resistant to ozone, engine heat, and under-hood fluid exposure. This material maintains its elasticity and damping performance over a wide temperature range, preventing it from becoming brittle in cold weather or overly soft when hot.
The metal components of the bracket are often treated with a zinc plating, phosphate coating, or other anti-corrosion finish. This is crucial for a part exposed to road spray and salts, ensuring the mounting bolts remain serviceable and the bracket itself does not weaken from rust.
The primary benefit of the genuine DZ9X259537005 suspension is dramatically extended cooling module life. By isolating the radiator and condenser from damaging vibrations, it prevents the work-hardening of metals and fatigue failure at soldered or brazed joints, which are common causes of leaks.
This component directly reduces maintenance costs and downtime. A single cooling module failure can lead to costly repairs, coolant loss, and the truck being out of service. The suspension mount is a low-cost preventive component that protects these high-value parts, offering a significant return on investment.
For the driver and operator, a key benefit is the preservation of cooling system performance. A securely mounted module maintains proper seal integrity with air guides and shrouds, ensuring airflow is directed efficiently through the cores and not around them. This maintains optimal engine and transmission cooling capacity.
A failed suspension can allow the cooling module to shift, potentially causing fan-to-shroud contact, hose abrasion, or damage to nearby electrical components. The DZ9X259537005 mount secures the module’s position, preventing these types of cascading and expensive failures.
By effectively damping vibrations, this suspension also contributes to a reduction in overall vehicle noise and harshness (NVH). A quieter cab environment can reduce driver fatigue on long journeys, contributing indirectly to safety and comfort.
The Cooling Module Suspension (Left) with OEM number DZ9X259537005 is designed as a direct replacement for the Shacman X5000 truck series. Its application is specific to the left-side mounting point of the vehicle’s front-mounted cooling module, which typically houses the radiator, charge air cooler, and A/C condenser.
This component is essential for all X5000 trucks in any service application. The constant vibration from the diesel engine and the shocks from road imperfections make a robust suspension system non-negotiable for protecting the cooling system’s integrity, whether in highway or off-road use.
It is a key part for routine preventive maintenance, often replaced in pairs with the right-side suspension. It is also crucial for repair after an accident or when diagnosing cooling module movement or vibration issues. Technicians must always verify the OEM number DZ9X259537005 to ensure they have the correct left-side part.
This suspension is engineered specifically for the left side of the Shacman X5000 cooling module assembly. The right-side suspension will have a different part number and is not interchangeable. Always confirm fitment using the truck’s VIN or model details.
While not a routine wear item like a filter, these suspensions should be inspected at major service intervals. Replacement is common during a cooling module overhaul, after visible bushing degradation (cracking, splitting), or if increased module vibration is detected. Proactive replacement prevents unexpected failure.
Correct installation of the DZ9X259537005 suspension is vital for its performance. Begin by safely supporting the cooling module from below using a transmission jack or blocks. This relieves weight from the old mounts and prevents the module from falling when the suspension is removed.
Unbolt the old left-side suspension from both the chassis rail and the cooling module frame. Note the sequence of any washers or spacers. Clean the bolt threads on the chassis and module using a wire brush to ensure smooth installation and accurate torque readings for the new part.
Position the new DZ9X259537005 suspension, aligning it with the mounting holes. Install the specified bolts and washers. It is often recommended to hand-tighten all bolts initially before applying final torque, ensuring the module is sitting squarely and the suspension is not under pre-load stress.
Tighten all bolts to the manufacturer’s specified torque values using a calibrated torque wrench. Overtightening can crush the bushing, destroying its damping properties, while undertightening can lead to loosening. Once installed, remove the support and gently rock the module to check for secure fitment without binding.
Ensure the engine is off and cool. Wear safety glasses. If replacing only one side, inspect the opposite side mount closely for wear. Consider replacing in pairs for balanced support. Always refer to the vehicle’s service manual for the most accurate procedure and specifications.
| Parameter | Specification |
|---|---|
| OEM Part Number | DZ9X259537005 |
| Product Name | Cooling Module Suspension (Left) |
| Brand | Shacman |
| Bracket Material | Steel with Anti-Corrosion Coating |
| Bushing Material | High-Durability Synthetic Rubber/Elastomer |
| Fitment Side | Left-Hand Side (Driver’s Side for LHD) |
| Mounting Type | Bolt-On, Vehicle-Specific |
| Compatibility | Shacman X5000 Truck Series |
| Function | Vibration Isolation & Module Support |
| Condition | New, Genuine OEM Part |
Proactive inspection of the DZ9X259537005 suspension is straightforward but important. During routine under-hood checks or scheduled maintenance, visually inspect the suspension bushing for signs of deterioration. Look for deep cracks, splitting, chunks of missing material, or an oily, swollen appearance.
Check for physical sagging or misalignment of the cooling module. If one corner appears lower than the other, it may indicate a collapsed suspension bushing. Also, inspect the metal bracket for severe corrosion, especially around the bolt holes, which could compromise its strength.
Listen and feel for symptoms. Excessive vibration transmitted to the cab or a rattling sound from the front grille area over bumps can indicate worn suspension mounts. Addressing these signs early prevents accelerated wear on the cooling module itself.
Perform a detailed visual and physical check of all cooling module suspensions at least once a year or during every major cooling system service. Pay extra attention in fleets that operate on consistently rough roads, as impact loads will accelerate bushing wear.
Keep the area around the mounts free from caked mud and debris. While the bushing material is resistant, prolonged contact with engine oil, fuel, or strong solvents can soften it. If contaminated, clean with a mild degreaser and water. Never lubricate the bushing, as this can attract dirt and degrade the rubber.
The Shacman DZ9X259537005 suspension is engineered for reliable, long-term performance in a harsh environment. The bushing material is compounded to retain its elasticity and damping characteristics across a wide temperature range, from freezing winter starts to high under-hood summer heat.
Reliability is inherent in its OEM design and quality control. It is built to consistently perform its singular function—isolating the cooling module—for tens of thousands of miles. This reliability is a direct contributor to the overall reliability of the truck’s critical cooling system.
Durability comes from material selection and design. The robust steel bracket resists bending, while the specialized elastomer resists cracking and compression set. Together, they withstand constant dynamic loads without failing, providing a service life that matches the expected interval between major cooling system services.
As a genuine Shacman part, the DZ9X259537005 is subject to validation for load capacity, vibration damping efficiency, and environmental resistance. It is designed to meet the specific durability requirements of the X5000 application, ensuring it performs as an integral part of the vehicle’s design.
This suspension offers exceptional value as a protective component. Its cost is minimal compared to the price of a new radiator, condenser, or the downtime associated with a cooling system failure on the road. Replacing worn mounts is a proactive, cost-effective maintenance strategy.
The genuine Shacman Cooling Module Suspension (Left) DZ9X259537005 is available for order through Shacman’s worldwide authorized parts distribution network. This ensures that service centers and fleet operators globally can access this specific left-side mount to maintain their X5000 truck’s cooling system integrity.
This product page is optimized for search engines to help users find this exact component. Targeted keywords such as “DZ9X259537005”, “Shacman X5000 cooling module mount”, and “left radiator support bushing” are integrated into comprehensive, original content that serves the needs of diesel technicians and fleet managers.
The content is original, technically detailed, and designed to provide genuine value for maintenance decision-making. It meets high standards of uniqueness and thoroughly covers the part’s function, benefits, and specifications in a clear, mobile-responsive format.
To ensure proper fit and performance, always source this part using its exact OEM number DZ9X259537005 from verified Shacman dealers. This guarantees you receive the genuine left-side suspension with the correct engineering for your vehicle, not a universal or incorrect side part.
The page is built with a fully responsive design for perfect viewing on any device. Information is logically segmented with clear headings, and technical data is presented in an easy-to-read table. This approach creates a trustworthy, complete resource for commercial vehicle maintenance.
Summary: The Shacman Cooling Module Suspension (Left) DZ9X259537005 is an essential OEM vibration isolation component for the Shacman X5000. It securely mounts the cooling module while protecting it from damaging engine and road vibrations. By preventing stress fractures and misalignment, this genuine left-side suspension extends the life of the radiator and condenser, reduces costly downtime, and ensures consistent cooling system performance. For guaranteed fit and optimal protection, always specify the genuine part number DZ9X259537005.
