Shacman F2000 Dashboard

The Shacman F2000 Dashboard is a well-engineered assembly that combines functionality, aesthetic appeal, and driver convenience. Designed with the needs of commercial truck drivers in mind, this dashboard features an array of components that work together seamlessly to provide a user-friendly experience while maintaining high durability.

Product Parameters of Shacman F2000 Dashboard

Shacman F2000 Dashboard
Download Catalog
Get Quotation
Whatsapp

  • Shacman F2000 Dashboard

  • Key Components of the Dashboard Assembly
  • At the lower section of the dashboard, the covering lower is installed to provide protection for internal elements and gives the vehicle’s interior a polished look. Fastening this covering in place are several oval-head self-tapping screws and speed nuts, ensuring a secure fit that can withstand the demands of daily use. Above this, the covering upper mirrors the lower section and is similarly secured with speed nuts and additional oval-head self-tapping screws, contributing to the overall stability and integrated design of the dashboard.

  • Shacman F2000 Dashboard

  • Functional Elements
  • The center part assembly is central to the dashboard’s functionality, providing a structured space for vital controls and displays. This assembly is supported by a robust bracket and a steel tube, reinforcing the overall strength of the dashboard. Additionally, plugs strategically placed throughout the assembly allow for easy access to wiring and electronic components, enabling quick maintenance and upgrades.

  • Shacman F2000 Dashboard

  • fastening and Utility Features
  • Fastening elements such as washers, speed nuts, and cylinder screws are essential for holding various parts in place, ensuring a secure attachment throughout the dashboard. A significant feature is the trim center part, which enhances the dashboard’s aesthetic quality while providing mounting options for controls and displays. The inclusion of an ash tray and a shelf adds utility, allowing drivers to store personal items conveniently.

  • Shacman F2000 Dashboard

  • Cover Plates and Additional Features
  • The cover plate center part encloses the central assembly, contributing to a clean finish. Multiple plugs and covers for electronics ensure that sensitive components are protected from dust and moisture, which is critical in rugged working environments. The cover for the additional heater, in a sleek black design, is another thoughtful addition that enhances driver comfort during colder months.
  • Conclusion
  • In summary, the Shacman F2000 Dashboard is meticulously designed to cater to the needs of commercial drivers, combining practicality with an elegant finish. With its thoughtful arrangement of components, including various coverings, fastening systems, and functional elements, the dashboard not only enhances the vehicle’s aesthetic appeal but also significantly improves the overall driving experience. This dashboard is essential for drivers seeking reliability and style in demanding work conditions.
NOPart.NoNameQuantityRemark
181.61701.0120Covering lower1
206.13189.0051Speed nut4ST4.2-4-A3C
306.07158.4503Oval-head self-tapping screw2ST4.2X13Z1-C-H-A3R
406.07158.4505Oval-head self-tapping screw2ST4.2X19Z1-C-H-A3R
581.96002.0420Plug4
681.61701.0119Covering upper1
706.13189.0051Speed nut2ST4.2-4-A3C
806.07158.4503Oval-head self-tapping screw2ST4.2  x  13Z1-C-H-A3R
981.96002.0420Plug2
1081.61701.5169Center part assembly1
81.61701.5170Center part assembly1right-hand drive For right
1181.61430.0053Bracket1
1281.94289.0158Steel tube2
1306.15013.0409Washer3A6.4  x  12  x  1.6-200HV-MAN18
1406.13189.0051Speed nut1ST4.2-4-A3C
1506.02099.0362Cylinder screw3M5  x  30Z1-8.8-A2R
1606.07158.4505Oval-head self-tapping screw5ST4.2  x  19Z1-C-H-A3R
1781.96002.0420Plug5
1806.13189.0012Speed nut4
1906.07158.4505Oval-head self-tapping screw5ST4.2-2-A3C
2081.61701.2227Trim center part1ST4.2  x  19Z1-C-H-A3R
2106.07158.4505Oval-head self-tapping screw4ST4.2  x  19Z1-C-H-A3R
2281.61701.0135Cap1
81.61701.0134Cap1right-hand drive For right
23DZ1642160083Cover plate center part1
81.61701.0124Cover plate center part1
2481.61701.6179Center partassembly1
2581.63745.0019Shelf2
2685.63740.0003Ash tray2
2781.90470.0611Groovde raised head4PT-KA4  x  16-WN1411-ST-A3C
Coll.screw
2881.61701.6178Covering assembly1
Electronics
2906.13189.0051Speed nut4ST4.2-4-A3C
06.13189.0090Speed nut4ST4.2-11  x  15  x  4-CK67-A3C
3006.13189.0051Speed nut3ST4.2-4-A3C
06.13189.0091Slip-on cage nut3M5-14.5  x  17  x  2.0
3181.61701.0123Cover for additional heater2
black
3281.61701.0150Cover1
