Shacman WP10 Flywheel Group is the heart of your heavy-duty engine’s power transmission system. Engineered for durability and precision, this complete group integrates Cylindrical pin, Flywheel Assembly, Flywheel Bolt, Double End Stud, Deep groove ball bearing, Hole elastic retaining ring, Flywheel, and Flywheel Ring Gear. Each component is manufactured to meet stringent Shacman OEM specifications, ensuring perfect fitment and reliable performance. Whether you are overhauling an WP10 engine or performing routine maintenance, the genuine assembly delivers exceptional rotational stability and extended service life.
The cylindrical pin in this flywheel group ensures precise alignment between flywheel and crankshaft flange. Made from high-strength alloy steel, it withstands torsional vibration and shear loads.
This hardened cylindrical pin guarantees repeatable positioning during assembly, reducing runout and preventing premature wear. For reliable WP10 powertrain, every pin meets strict dimensional tolerances.
The flywheel assembly is the core rotating mass of the Shacman WP10 unit. It stores kinetic energy, smooths engine pulses, and provides a friction surface for the clutch. Cast from high-grade nodular iron, it resists cracking under thermal stress.
Each Shacman WP10 flywheel assembly is dynamically balanced to minimize vibrations. This extends transmission life and ensures smooth gear engagement for heavy haul operations.
Flywheel bolts secure the flywheel to the crankshaft with extreme clamping force. Our flywheel group uses high-tensile steel bolts with micro-encapsulated thread locker to prevent loosening.
Proper torque retention is critical; these bolts undergo magnetic particle inspection. Replacing them with genuine bolts guarantees safety and prevents catastrophic failure.
Double end studs provide robust mounting points for auxiliary components around the flywheel housing. In the Shacman WP10 group, these studs are case-hardened and zinc-plated for corrosion resistance.
They ensure even load distribution when attaching the starter motor or flywheel housing cover. Every double end stud offers consistent thread accuracy and high yield strength.
The deep groove ball bearing supports the input shaft or pilot bearing area, reducing friction. For this assembly, we select C3 clearance bearings with high-temperature grease to endure extreme rpm.
This bearing handles both radial and axial loads, contributing to smooth clutch release. Genuine bearings lower maintenance intervals and improve driveline efficiency.
The hole elastic retaining ring locks the bearing or shaft components axially without play. In this flywheel group, these retaining rings are spring steel and heat-treated for constant clamping force.
They prevent axial shifting under dynamic loads, securing internal parts. Every certified retaining ring withstands thermal expansion and vibration cycles.
The flywheel itself is precision machined with a friction surface for clutch engagement. Our Shacman WP10 flywheel features induction-hardened wear zones and strict surface flatness (≤0.05mm).
It incorporates the starter ring gear mounting and crankshaft pilot. Upgraded flywheels reduce gear rattle and improve engine braking response for heavy-duty trucks.
The flywheel ring gear engages with the starter motor pinion. In this assembly, the ring gear is made from high-carbon steel with induction-hardened teeth to prevent stripping during cold starts.
Precise tooth profile and interference-fit assembly guarantee silent operation. Genuine ring gear ensures long cranking life even under extreme duty cycles.
Shacman WP10 Flywheel Group – Genuine OEM assembly
| Part Number | Part Name |
|---|---|
| 90015050027 | Cylindrical pin |
| 611600020028 | Flywheel Assembly |
| 1002797797 | Flywheel Bolt |
| 9000000707 | Double End Stud |
| 1003500131 | Deep groove ball bearing |
| 90003934310 | Hole elastic retaining ring |
| 611600020027 | Flywheel |
| 611600020005 | Flywheel Ring Gear |
All components of the Shacman WP10 flywheel group meet ISO/TS 16949 quality standards. We supply original-equipment grade parts that ensure drop-in fitment and maximum durability for WP10 engines.
Rigorous dynamic balancing and magnetic crack detection on every assembly. This reduces driveline vibration, extends clutch life, and lowers fuel consumption over thousands of operating hours.
Optimized for harsh conditions: extreme temperature resistance, anti-corrosion coating, and high-strength fasteners. The Shacman WP10 flywheel group delivers consistent starting torque and noise reduction.
Direct OEM replacement with comprehensive engineering support. Each flywheel group comes with traceable serial numbers and 12-month warranty against manufacturing defects.
The Shacman WP10 flywheel group uses advanced CNC machining for flatness and runout control. Each flywheel is surface-ground to a mirror finish, ensuring clutch disc contact uniformity.
Upgraded assembly reduces dual-mass flywheel failures in high-mileage fleets. Ideal for logistics and construction trucks.
Heat-treated flywheel and ring gear resist warping under heavy clutch slipping conditions. This assembly maintains structural integrity even at 500°C peak surface temperatures.
Enhanced cooling channels improve thermal dissipation, reducing hotspots. This extends the life of both the flywheel and the clutch assembly.
Each flywheel group is dynamically balanced to ISO 1940 G6.3 quality grade. This eliminates engine harmonic issues and provides smooth power delivery at all RPM ranges.
Balanced flywheels reduce stress on crankshaft bearings, extending overall engine rebuild intervals by up to 20%.
This assembly is engineered for Shacman heavy trucks equipped with WP10 diesel engines (Euro II/Euro III/Euro IV variants). Commonly fitted in F2000, F3000, X3000 series, and construction machinery like graders and loaders.
Using genuine Shacman WP10 components ensures correct flywheel housing alignment, starter mesh depth, and clutch release bearing clearance. Avoid costly downtime with certified replacement parts directly from OEM supply chain.
Each shipment includes all necessary cylindrical pins, flywheel bolts, double end studs, and retaining rings. The deep groove ball bearing is pre-greased and ready for installation.
For fleet owners, this flywheel group reduces unscheduled repairs thanks to the heavy-duty ring gear and heat-treated flywheel. Field tests show up to 800,000 km service life under standard highway conditions.
Shacman WP10 Flywheel Group is the most trusted replacement assembly for mining and long-haul fleets. The combination of Cylindrical pin, Flywheel Assembly, Flywheel Bolt, Double End Stud, Deep groove ball bearing, Hole elastic retaining ring, Flywheel, and Flywheel Ring Gear offers unmatched reliability. When you purchase this flywheel assembly, you eliminate mismatched aftermarket risks. Every genuine component undergoes 100% inspection including hardness testing, dimensional audit, and magnetic particle inspection.
Upgrade your powertrain with this assembly and experience smoother gear shifts and lower vibration. For heavy haulage, the Shacman WP10 unit is the benchmark solution. Order it today to maximize uptime and reduce total cost of ownership. The OEM-grade assembly provides seamless integration with WP10 engines and original clutches. Mechanics recommend this group because it includes every small part from elastic retaining rings to high-grade bolts. Save time and money by choosing a complete kit.
We supply the Shacman WP10 flywheel group globally with fast logistics. The assembly has been verified for Euro V and CNG variants as well. With this flywheel group, you avoid common failures like ring gear cracking and pilot bearing seizure. Install the assembly with confidence using the included technical datasheet. For any heavy truck workshop, keeping this flywheel group in stock is a smart business decision. The durability of these components ensures fewer comebacks and higher customer satisfaction. Choose genuine Shacman WP10 quality today and drive with uncompromised power delivery. Every bolt, stud, and bearing inside this flywheel group is manufactured to exceed OE expectations.
