Shacman X6000 Gear Shifting

The Shacman X6000 Gear Shifting system is engineered to deliver exceptional performance and reliability, ensuring seamless gear transitions and optimal control for the driver. This comprehensive system incorporates a range of components, each designed to contribute to the overall efficiency and durability of the gear shifting mechanism.

Shacman X6000 Gear Shifting
Shacman X6000 Gear Shifting
Shacman X6000 Gear Shifting
Shacman X6000 Gear Shifting
Download Catalog
Get Quotation
Whatsapp

Product Parameters of Shacman X6000 Gear Shifting

  • Shacman X6000 Gear Shifting

  • Core Components
  • At the heart of the Shacman X6000 Gear Shifting system is the Hand Shank, which is essential for the driver to engage and manipulate the gear lever. The Shift Lever connects to the hand shank and directly influences the Shift Gears, facilitating smooth and precise gear changes. These components work together to ensure the driver can select the desired gear with ease.
  • Fastening and Support Elements
  • The system employs a variety of Bolts and Nuts to secure the different components in place. For example, the Nut and Bolt combination is used to attach the shift lever, while additional bolts and nuts ensure the proper installation of other critical parts. Washers are utilized to distribute pressure evenly and prevent loosening, thereby maintaining the stability of the assembly.

  • Shacman X6000 Gear Shifting

  • Protection and Maintenance
  • A Dust Cover is included to protect the internal components from environmental contaminants, extending the lifespan of the gear shifting system. Furthermore, the Air Tube Seal and Seal Shell are essential for preventing air and dust ingress, ensuring that the system remains clean and functional.
  • Support Brackets and Clips
  • The gear shifting mechanism includes several Brackets and Cable Clips, which provide structural support and secure the shift cables and other components. These brackets are strategically placed to maintain alignment and stability, while the cable clips keep the shift cables organized and prevent them from becoming tangled or damaged.

  • Shacman X6000 Gear Shifting

  • Assembly and Adjustment
  • During assembly, various Bolts, Washers, and Nuts are used to secure the shift lever, shift gears, and other parts. The precise placement of these elements ensures that the gear shifting system operates smoothly. Special attention is given to the Select Arm and Select Cable, which are crucial for accurate gear selection and adjustment.
  • Conclusion
  • The Shacman X6000 Gear Shifting system is a robust and meticulously designed assembly that incorporates a wide range of components for optimal performance. From the Hand Shank and Shift Lever to the Dust Cover and various Bolts and Nuts, each part plays a vital role in ensuring reliable and smooth gear transitions. The inclusion of support elements like Brackets and Cable Clips further enhances the system’s functionality, making it a crucial aspect of the Shacman X6000’s driving experience.
NO Part.No Name Quantity
1 DZ9X259241037 Hand shank 1
2 Q340B10T2F3 Nut 1
3 DZ9X259241004 Shift lever 1
4 DZ9X259241009 Dust cover 1
5 Q1840816 Bolt 1
6 DZ9H259240510 Shift gears 1
7 Q150B0830T1F3 Bolt 4
8 Q402B08 Washer 6
9 DZ9X259240530 Air tube seal 1
10 DZ9X259241010 Seal shell 1
11 Q33206 Nut 10
12 DZ9X259241029 Bracket 1
13 DZ9X259241003 Cable clip 1
14 Q150B0635TF3 Bolt 2
15 190003171697 Washer 4
16 DZ9X259241048 Bracket 1
17 Q402B10 Washer 1
18 Q150B1035T1F3 Bolt 1
19 Q150B0616 Bolt 6
20 DZ9M259241119 Cable clip 2
21 DZ9X259241049 Bracket 1
22 Q150B0620 Bolt 1
23 DZ9X259241057 Bracket 1
24 DZ9M259241106 Cable clip 4
25 DZ9X259241056 Bracket 1
26 DZ9X259241028 Bracket 1
27 Q1811430TF3 Bolt 2
28 DZ9X259241026 Bracket 1
29 Q1811230T1F3 Bolt 4
30 DZ9X259241024 Bracket 1
31 DZ9X259241023 Bracket 1
32 Q32010 Nut 2
33 DZ9X259241006 Shift cable 1
34 Q32008 Nut 1
35 DZ9X259241038 Select arm 1
36 Q150B0850 Bolt 1
37 DZ9X259241005 Select cable 1
