Shacman F2000&F3000 Single Stage Reduction Drive Axle Middle Section
  • Introducing the Shacman F2000&F3000 Single Stage Reduction Drive Axle Middle Section, a crucial component engineered to deliver superior performance and reliability in heavy-duty applications. This middle section incorporates a range of meticulously designed parts, each contributing to its robustness and functionality.
  • Key components include the Flange Nut and FlangeΦ180, ensuring secure attachment and stability. The Adjusting Nut allows for precise adjustment, while the Axle Seal Ring maintains a tight seal, preventing leakage and ensuring optimal performance.
  • The Row-steep Roller Bearing and Sliding Engage Cowl work together to support smooth operation, while the Perforation Shaft (input) transfers power effectively. The Bush, Stop Shim, and Shoulder Ring provide additional support and alignment, ensuring proper functionality under varying loads.

Product Parameters of Shacman F2000&F3000 Single Stage Reduction Drive Axle Middle Section

Shacman F2000&F3000 Single Stage Reduction Drive Axle Middle Section
Download Catalog
Get Quotation
Whatsapp
  • The Active Column Gear, Planet Gear, and Cross Axle ensure efficient power transmission and durability, even in the most challenging driving conditions.
  • Experience unmatched durability and performance with the Shacman F2000&F3000 Single Stage Reduction Drive Axle Middle Section, where every component is meticulously engineered for reliability and longevity, ensuring smooth operation and peace of mind on every journey.
NO Part No Name Quantity
1 DZ95149320054 Flange nut 2
2 HD469-2502012 FlangeΦ180 1
3 HD469-2502014 Adjusting nut 1
4 DZ9112320920 Axle seal ring 1
5 31313 Row-steep roller bearing 2
6 DZ90129320102 Sliding engage cowl 1
7 HD469-2502011 Perforation shaft(input) 1
8 HD469-2502019 Bush 1
9 DZ95149320064 Stop shim 1
DZ95149320065 Stop shim 1
DZ95149320066 Stop shim 1
10 HD469-2502017 Shoulder ring 1
11 DZ90129320101 Active column gear 1
12 HD469-2510013 Planet gear 4
13 HD469-2510014 Cross axle 1
14 HD469-2510011 Differential case of axle 1
15 HD469-2510012 Collect oil cover 1
16 HD469-2510015 Bush 1
17 HD469-2510017 Adjusting shim 1
18 HD469-2510016 Axle shaft gear 1
19 32215 Roller bearing 1
20 HD469-2502027 HD469-2502052 Final drive case of cross axle Final drive case of cross axle 1 1
21 HD469-2406011 Spring 2
22 HD469-2511011 Frok 1
NO Part No Name Quantity
23 HD469-2402014 Shim 2
HD469-2402016 Shim 2
24 HD469-2406013 Plunger 2
25 HD469-2406015 O-ring 2
26 HD469-2406014 Bush 2
27 HD469-2406017 shim 2
28 HD469-2406012 Gasket 2
29 Q72318T5F Seal washer 2
30 Q150B0835 Bolt 6
31 81.25503.0244 Gearbox switch 2
32 HD469-2402055 Stop ring 1
33 HD469-2402012 Roller bearing 1
34 HD469-2502031 Active taper gear 1
HD469-2502033 Active taper gear 1
HD469-2502035 Active taper gear 1
HD469-2502037 Active taper gear 1
HD469-2502039 Active taper gear 1
HD469-2502042 Active taper gear 1
35 81.90770.0100 Shim on-demand
36 HD469-2502015 Lock piece 1
37 Q1800816TF2 Bolt 1
38 DZ9003962021 Square head tapered plug 1
39 Q5211228 Pin 2
NO Part No Name Quantity
40 Q1811235TF2 Bolt 14
41 HD469-2502025 Pass-axle box cap 1
42 06.02191.2611 Bolt 4
43 HD469-2502029 Passive column gear 1
44 HD469-2502030 Bearing block 1
45 HD469-2402020 Shim on-demand
46 HD469-2402100 Row-steep roller bearing 1
47 81.35125.0024 Adjusting nut 2
48 32024 Row-steep roller bearing 2
49 HD469-2502032 Passive bevel gear 1
HD469-2502034 Passive bevel gear 1
HD469-2502036 Passive bevel gear 1
HD469-2502038 Passive bevel gear 1
HD469-2502041 Passive bevel gear 1
HD469-2502043 Passive bevel gear 1
50 HD469-2503012 Differential case (left) 1
HD469-2503011 Differential case (left) 1
51 HD469-2403015 Axle shaft gear 2
52 DZ90001500006 Bolt 4
53 HD469-2403017 Axle shaft gear washer 2
54 HD469-2403019 Cross axle 2
55 HD469-2403021 Cross axle 1
56 HD469-2403016 Plant gear 4
57 HD469-2403018 Plant gear washer 4
NO Part No Name Quantity
58 HD469-2403014 Differential case (right) 1
  HD469-2403011 Differential case (right) 1
59 HD469-2406018 Sliding engage cowl 1
60 HD469-2402011 Bolt 16
61 HD469-2506011 Fork 1
62 Q1811660TF2 Bolt 2
63 Q1811650TF2 Bolt 10
64 HD469-2502028 Bearing cap 1
65 Q5220816 Pin 4
66 HD469-2402043 Bearing cap（right） 1
67 DZ9112320028 Locking shim 2
68 Q1800816 Bolt 2
