Cylinder Head Cover Insulation Board
Теплоизоляционная Панель
Panel Aislante de Culata
OEM Cylinder Head Cover Insulation Board 1008003269 designed specifically for the Shacman X5000 heavy‑duty engine. This precision‑formed 1008003269 component reduces radiated engine noise and manages under‑hood temperatures for improved cab comfort.
Constructed from multi‑layer composite materials with a heat‑reflective facing, the Cylinder Head Cover Insulation Board 1008003269 withstands continuous exposure to high temperatures while maintaining its structural integrity and acoustic performance.
Replacing a degraded or missing insulation board with the genuine 1008003269 unit restores factory‑spec noise levels and protects adjacent wiring and hoses from heat damage.
| Parameter | Specification |
|---|---|
| OEM Part Number | 1008003269 |
| Product Name | Cylinder Head Cover Insulation Board |
| Brand / Model | Shacman X5000 |
| Material | Fiberglass Composite with Aluminum Foil Facing |
| Thickness | 12.00 mm |
| Maximum Temperature Resistance | 220°C continuous |
| Noise Reduction | Up to 5 dB(A) attenuation |
| Mounting Type | Clip‑on with integrated fastening points |
| Flammability Rating | UL94 V‑0 self‑extinguishing |
| Application | Shacman X5000 cylinder head cover top insulation |
The 1008003269 insulation board serves two critical purposes above the Shacman X5000 cylinder head cover. First, it acts as a thermal barrier that reflects radiant heat away from the engine cover and adjacent components in the engine bay.
Second, the Cylinder Head Cover Insulation Board 1008003269 functions as an acoustic absorber that dampens the high‑frequency mechanical noise generated by the valve train, injectors, and camshaft drive gears.
Together, these functions contribute to a quieter cab environment for the driver and reduce the thermal load on the engine compartment, extending the service life of plastic and rubber components.
The 1008003269 board is manufactured from a dense fiberglass mat that is bonded under heat and pressure. This mat provides the bulk of the sound absorption capability through its porous internal structure.
A layer of embossed aluminum foil is laminated to the top surface, serving as a heat shield that reflects infrared radiation. This foil also provides a cleanable surface that resists oil and fuel splashes during maintenance.
The 1008003269 insulation board is designed for simple clip‑on installation over the cylinder head cover. Integrated fastening points align with corresponding studs or brackets on the engine, requiring no adhesive or special tools.
The board should be periodically inspected for secure attachment. Loose insulation can contact hot exhaust components and create a fire hazard. Any board showing signs of delamination or oil saturation should be replaced immediately.
Each production batch of 1008003269 boards is subjected to a 100‑hour heat soak test at 220°C. Post‑test inspection verifies that the board retains its shape, the foil remains bonded, and no charring or smoke emission occurs.
Acoustic absorption coefficients are measured using an impedance tube according to ISO 10534 standards. The Cylinder Head Cover Insulation Board 1008003269 consistently meets or exceeds the specified attenuation targets.
A missing or deteriorated 1008003269 board exposes the cylinder head cover to direct radiant heat from surrounding exhaust components. This can cause the cover gasket to harden prematurely and develop oil leaks.
Increased engine noise in the cab is often the first sign that the insulation board has become dislodged or has lost its acoustic effectiveness through oil contamination or physical damage.
During any service operation that requires removal of the cylinder head cover, the insulation board should be inspected and replaced if necessary. It is a consumable item with a finite service life.
The 1008003269 insulation board is specifically contoured to fit the Shacman X5000 cylinder head cover profile. It cannot be interchanged with boards from other engine models without risk of interference.
Fleet operators should consider keeping spare 1008003269 boards in stock, as they are frequently damaged during routine engine maintenance and are essential for maintaining cab comfort standards.
Aftermarket insulation boards may use inferior materials that melt or emit toxic fumes at normal engine operating temperatures. We supply only the authentic Shacman X5000 Cylinder Head Cover Insulation Board 1008003269.
Each board is packaged flat in a protective sleeve to prevent bending or creasing during transport. The part number 1008003269 is printed on the packaging for quick verification upon receipt.
Our logistics infrastructure ensures that genuine 1008003269 insulation boards are available for prompt delivery to workshops and fleet maintenance facilities around the world.
Single insulation board with integrated mounting clips. Protective packaging ensures the board arrives flat and undamaged, ready for immediate installation.
Expert guidance on insulation board installation and secure fastening. We help ensure your 1008003269 board delivers optimal thermal and acoustic protection.
For current stock availability and pricing on the genuine Cylinder Head Cover Insulation Board 1008003269, please use the contact buttons above.
