4010106/Radiator Assembly
Радиаторный Блок
Ensamblaje del Radiador
The 4010106-DZ97259532020 is the complete, genuine OEM Radiator Assembly designed and engineered specifically for the Shacman X5000 heavy-duty truck. This critical cooling system component, bearing the part numbers 4010106 and DZ97259532020, is responsible for dissipating the immense heat generated by the truck’s engine during long-haul and high-load operations. It is an integrated unit that typically includes the core, tanks, mounting brackets, and often connections for the transmission oil cooler (if applicable), ensuring a perfect, leak-free fit and optimal thermal performance right out of the box.
Constructed with high-efficiency aluminum cores and robust brass or composite tanks, this radiator assembly is built to withstand extreme pressure cycles, temperature fluctuations, and corrosive coolant mixtures. Its primary function is to maintain the engine within its ideal operating temperature range, preventing catastrophic overheating that can lead to engine seizure, head gasket failure, and other costly damages. For fleet managers and owner-operators, choosing the genuine Shacman 4010106-DZ97259532020 assembly guarantees compatibility, reliability, and longevity, directly impacting vehicle uptime and total cost of ownership.
| Parameter | Details |
|---|---|
| OEM Part Number(s) | 4010106-DZ97259532020 (also referenced as 4010106) |
| Product Name | Radiator Assembly (Complete Unit) |
| Brand | Shacman Genuine Part |
| Compatible Truck Model | Shacman X5000 Series (Multiple Configurations) |
| Core Material | High-Strength Aluminum Alloy |
| Tank Material | Reinforced Plastic Composite / Brass |
| Core Dimensions (Approx.) | Varies; Designed for X5000 Engine Bay |
| Number of Rows | 2 or 3 Rows (Based on Cooling Capacity) |
| Integrated Oil Cooler | Optional / Model-Specific (Transmission or Hydraulic) |
| Pressure Cap Rating | Standard 1.1 Bar (16 psi) Shacman Cap |
| Inlet/Outlet Size | Matched to X5000 Engine Hoses |
| Package | Secure Wooden Crate or Heavy-Duty Carton |
The 4010106-DZ97259532020 radiator features a multi-row aluminum core with tightly spaced fins and turbulator-equipped tubes. This design maximizes the surface area for heat exchange between the hot coolant and the incoming airflow forced through by the truck’s fan clutch system.
Advanced manufacturing techniques ensure consistent tube-to-header joints, preventing the common failure point of leakage. The high thermal conductivity of aluminum allows for rapid heat transfer, enabling the radiator to manage the BTU output of the X5000’s high-torque diesel engine even under peak load in hot climates.
The assembly is built to endure harsh operating environments. The aluminum core is treated with protective coatings to resist corrosion from modern coolant mixtures and road salt. Tanks are constructed from materials immune to electrolytic corrosion when paired with the aluminum core.
All mounting points and brackets are reinforced to handle the constant vibration and shock loads experienced in heavy-duty trucking. This robust construction prevents cracks and stress fractures, ensuring the radiator’s structural integrity over hundreds of thousands of kilometers.
As a complete assembly, part number 4010106-DZ97259532020 is designed as a drop-in unit. It includes all necessary mounting hardware, brackets, and connection ports pre-installed or supplied. This eliminates compatibility issues and reduces installation time compared to piecing together individual components.
For models requiring it, the assembly may incorporate an internal oil cooler for transmission or hydraulic fluid. This integrated approach saves space, reduces external plumbing, and improves overall cooling system efficiency by utilizing the radiator’s airflow.
A failing radiator in a Shacman X5000 can lead to a rapid sequence of engine problems. The initial symptom is often overheating, indicated by the temperature gauge rising into the red zone. If unchecked, this can cause engine coolant to boil, leading to a loss of coolant and even greater overheating.
Prolonged overheating warps cylinder heads and engine blocks, blows head gaskets, and can cause piston rings to lose tension or pistons to seize. The resulting engine damage requires a complete overhaul or replacement, costing tens of thousands of dollars and weeks of downtime.
Using a non-genuine or inferior quality radiator assembly risks incorrect fitment, reduced cooling capacity, and premature failure due to substandard materials. The genuine 4010106-DZ97259532020 is tested to Shacman’s rigorous standards for heat exchange, pressure cycling, and vibration resistance, ensuring it matches the engine’s cooling demands exactly.
Installation Preparedness: Replacing the radiator assembly is a significant repair. Ensure the engine is completely cool. Drain the coolant into a proper container. Disconnect the battery. Have appropriate tools ready, including wrenches for hose clamps and mounting bolts. Carefully remove shrouds, hoses, and any obstructing lines.
The Replacement Process: After removing the old radiator, thoroughly clean the mounting area and check the fan clutch and shroud for damage. Carefully position the new 4010106-DZ97259532020 assembly, aligning all mounting points. Do not force it into place. Reconnect all hoses with new clamps if recommended. Refill the system with the correct type and mix of OEM-approved coolant.
Bleeding the System: Air pockets can cause overheating. Follow the Shacman service manual procedure to bleed the cooling system. This often involves running the engine with the radiator cap off (or a spill-free funnel) until the thermostat opens and coolant circulates without bubbles.
Routine Maintenance: To extend the life of the new radiator, perform regular inspections. Check coolant level and condition. Keep the external fins clean from bugs, dirt, and debris by gently flushing with water (never high pressure). Inspect hoses and clamps annually for signs of wear or leaks. Use only recommended coolants to prevent internal scaling and corrosion.
While the initial purchase price of the genuine Shacman radiator assembly might be higher than some aftermarket options, its value is realized over the long term. A reliable radiator prevents the single most expensive mechanical failure an engine can experience: catastrophic overheating.
Consider the cost of a tow, the labor for an engine rebuild, the price of replacement engine parts, and the revenue lost from weeks of truck downtime. The genuine part acts as an insurance policy against these costs. Its precise fit eliminates labor time spent on modifications, and its durability means it won’t need replacement again prematurely.
For fleet managers, standardizing on genuine Shacman cooling components like the 4010106-DZ97259532020 simplifies inventory, ensures predictable maintenance intervals, and supports a reputation for reliable fleet operations. Consistent engine temperature also optimizes fuel efficiency and reduces emissions.
Always specify the full part number 4010106-DZ97259532020 when ordering. Verify the number from your old radiator’s identification tag or the official Shacman parts catalog for your VIN. Genuine parts will arrive in official Shacman packaging (or authorized distributor packaging) with clear labeling and often a security hologram or quality seal.
Inspect the radiator upon receipt. Look for the Shacman logo or casting marks on the tanks or headers. Check the fin array for uniformity and the overall build quality. Counterfeit radiators often have uneven fins, poor welding, and flimsy brackets. Purchasing from authorized dealers is the best way to guarantee authenticity and receive full manufacturer support.
While this assembly is designed for the Shacman X5000, always confirm compatibility with your truck’s specific model year, engine displacement, and optional equipment (e.g., presence of an integrated oil cooler). Minor design revisions can occur; providing your truck’s VIN to the parts supplier is the most accurate method.
The Shacman Radiator Assembly 4010106-DZ97259532020 is not just a part; it’s the heart of your truck’s cooling system. Ensure peak performance, prevent costly breakdowns, and maintain your X5000’s reliability with a genuine, precision-engineered replacement. Secure your cooling system integrity today.
