Bowl Plug
Чашеобразная Заглушка
Tapón Cóncavo
OEM Bowl Plug 612600013582 precision‑manufactured for the Shacman X5000 heavy‑duty diesel engine. This small yet vital 612600013582 plug seals core holes in the engine block and cylinder head, preventing coolant and oil leaks.
Formed from high‑quality steel with a corrosion‑resistant coating, the Bowl Plug 612600013582 maintains a tight interference fit across thousands of thermal cycles. Its cupped design expands slightly during installation for a permanent leak‑proof seal.
Using the genuine 612600013582 plug during engine assembly or rebuild ensures that critical coolant and oil passages remain sealed under all operating conditions.
| Parameter | Specification |
|---|---|
| OEM Part Number | 612600013582 |
| Product Name | Bowl Plug |
| Brand / Model | Shacman X5000 |
| Material | Low‑Carbon Steel with Zinc Plating |
| Outer Diameter | 40.00 mm |
| Depth / Height | 8.50 mm |
| Type | Cupped expansion plug |
| Installation Method | Press‑fit with controlled expansion |
| Operating Temperature | -40°C to +200°C |
| Application | Shacman X5000 engine block and cylinder head core holes |
The 612600013582 bowl plug seals the openings left during the casting process of engine blocks and cylinder heads. These core holes are necessary for foundry sand removal but must be permanently closed before the engine enters service.
A failed bowl plug can release coolant onto hot engine surfaces or allow oil to escape, creating a fire hazard and potentially causing catastrophic engine damage from fluid loss. The Bowl Plug 612600013582 prevents these dangerous scenarios.
Despite its small size, this plug endures constant exposure to pressurized coolant and hot oil. It must maintain its seal integrity through countless thermal cycles as the engine warms from freezing temperatures to full operating heat.
The 612600013582 plug is stamped from low‑carbon steel that provides the right balance of ductility for expansion and strength for retention. The zinc plating offers cathodic protection against rust in the presence of water‑based coolants.
This plating layer withstands over 200 hours of neutral salt spray testing, ensuring that the plug remains corrosion‑free even in engines operating in coastal environments or regions where road salt is used for winter de‑icing.
Installing the 612600013582 bowl plug requires a flat‑faced driver that contacts the outer rim of the plug. Striking the center with a ball‑peen hammer distorts the plug unevenly and compromises its sealing capability.
The bore must be clean and free of burrs before installation. A thin coat of non‑hardening sealant applied to the bore wall provides additional leak protection and reduces the force needed to seat the Bowl Plug 612600013582 fully.
Each production lot of 612600013582 plugs is sampled for dimensional inspection using optical measurement equipment. The outer diameter tolerance is held to plus or minus 0.05 mm for consistent interference fit.
Random samples undergo a push‑out test to verify retention force. The plug must withstand a minimum axial load without movement, confirming that it will not dislodge under the combined effects of pressure and vibration.
A leaking 612600010012 plug often manifests as an external coolant drip or a visible trail of dried coolant residue below the core hole location. Oil‑sealing plugs may show wetness around the plug periphery on the block exterior.
Replacing a failed plug involves carefully prying the old unit out without damaging the bore. The new Bowl Plug 612600013582 must be driven in squarely to the specified depth to ensure full circumferential contact with the sealing surface.
During engine overhaul, replacing all accessible bowl plugs is recommended. The modest cost of the 612600013582 plugs is insignificant compared to the labor and expense of addressing a leak after the engine has been reinstalled in the vehicle.
The Bowl Plug 612600013582 is specified for multiple core hole locations on the Shacman X5000 engine. Its standardized dimensions simplify inventory management for fleet maintenance operations and independent repair facilities.
Using a plug with incorrect diameter or depth can result in inadequate retention or interference with internal engine components. Always verify the part number 612600013582 against the engine service manual before installation.
Inferior aftermarket plugs made from thin gauge steel can fail prematurely. We supply only the authentic Shacman X5000 Bowl Plug 612600013582 with full OEM documentation and material certification.
Each plug is packaged in a sealed plastic bag with the part number 612600013582 clearly printed on the label. Bulk packaging options are available for engine rebuilders who require large quantities.
Our distribution network ensures fast delivery to workshops and fleet depots worldwide. Keeping a stock of genuine 612600013582 plugs on hand prevents delays during engine assembly and rebuild operations.
Available individually or in engine set quantities. Bulk packs for high‑volume rebuild shops with convenient resealable packaging.
Technical guidance on proper plug installation tools and techniques. We help ensure your 612600013582 plugs seal reliably.
For current availability and volume pricing on the genuine Bowl Plug 612600013582, please use the contact buttons above.
