Urea Tank Bracket
Кронштейн Бака Мочевины
Soporte del Tanque de Urea
OEM Urea Tank Bracket DZ95259740384 precision‑formed for the Shacman X5000 heavy‑duty truck. This robust DZ95259740384 mounting component secures the diesel exhaust fluid tank to the chassis frame, ensuring stable positioning through all vehicle maneuvers.
Fabricated from high‑strength structural steel with a durable anti‑corrosion finish, the Urea Tank Bracket DZ95259740384 withstands the combined weight of a filled tank and the dynamic forces of heavy‑duty vehicle operation.
Replacing a bent or corroded bracket with the genuine DZ95259740384 component restores proper tank support and prevents the stress that leads to tank cracking and fluid line connection failures.
| Parameter | Specification |
|---|---|
| OEM Part Number | DZ95259740384 |
| Product Name | Urea Tank Bracket |
| Brand / Model | Shacman X5000 |
| Material | High‑Strength Structural Steel with Black E‑coat |
| Bracket Type | Formed steel support arm with reinforcement ribs |
| Mounting Hole Diameter | 10.50 mm (3 chassis frame bolt points) |
| Tank Mounting Slot | 38.00 mm strap slot with edge protection |
| Load Capacity | Supports up to 45 kg filled tank weight |
| Corrosion Protection | Electrophoretic coating, 480 hours salt spray rated |
| Application | Shacman X5000 urea tank chassis mounting system |
The DZ95259740384 urea tank bracket is a structural chassis component that transfers the weight of the DEF tank and its contents directly into the vehicle frame. It must safely support this load through all driving conditions.
A filled 36‑liter urea tank weighs approximately 40 kilograms. During vehicle acceleration, braking, and cornering, dynamic forces can multiply this static weight significantly. The bracket must accommodate these peak loads without deformation.
The Urea Tank Bracket DZ95259740384 also provides the anchor slot through which the tank securing strap passes. This slot positions the strap correctly around the tank circumference for uniform clamping force distribution.
The DZ95259740384 bracket is manufactured from high‑strength structural steel that provides the necessary load‑bearing capacity with a generous safety margin for the overload conditions encountered in demanding applications.
The electrophoretic coating applied to the bracket provides uniform corrosion protection across all surfaces, including internal corners and edges that are difficult to protect with spray‑applied coatings. This e‑coat layer withstands 480 hours of salt spray exposure.
The DZ95259740384 bracket mounts to pre‑drilled holes in the chassis frame rail using high‑strength bolts and prevailing‑torque lock nuts. The mounting surfaces must be clean and free of corrosion before installation.
The bolts should be tightened to the torque specification in the Shacman service manual. Under‑torqued bolts allow bracket movement that can elongate frame holes, while over‑torquing can fracture the bracket or strip threads.
Each production batch of DZ95259740384 brackets is sampled for static load testing. The bracket must withstand a test load of three times its rated capacity without permanent deformation or crack formation.
Coating thickness measurements are taken at multiple points on each bracket using eddy current testing equipment. The e‑coat thickness must meet the minimum specification across all functional surfaces.
Rust staining or bubbling of the coating on the DZ95259740384 bracket indicates that corrosion has penetrated the e‑coat layer. If left unaddressed, this corrosion can progress to pitting that reduces the effective cross‑section.
Cracks propagating from the mounting holes or the strap slot are evidence of fatigue loading. Cracked brackets must be replaced immediately to prevent sudden failure that could cause the urea tank to detach from the vehicle.
During chassis inspections, all tank brackets should be checked for tightness and structural integrity. Loose or damaged brackets compromise the security of the entire DEF storage system.
The DZ95259740384 bracket is specifically designed for the Shacman X5000 chassis frame rail dimensions and urea tank configuration. Its mounting pattern and strap slot geometry match this vehicle platform.
Fleet maintenance programs should include these brackets in their chassis component inventory. Rapid replacement of damaged brackets minimizes the risk of tank‑related incidents and keeps vehicles emissions‑compliant.
Aftermarket brackets made from thinner gauge steel or lacking proper corrosion protection can fail in service. We supply only the authentic Shacman X5000 Urea Tank Bracket DZ95259740384 manufactured to OEM specifications.
Each bracket is individually packaged to prevent coating damage during handling and transit. The part number DZ95259740384 is clearly displayed on both the component label and the packaging.
Our international supply chain maintains strategic stock levels to support fleet operators and service facilities worldwide. Genuine DZ95259740384 brackets are dispatched promptly to minimize vehicle downtime.
Single urea tank bracket with protective e‑coat finish. Mounting hardware available separately. Protective packaging prevents transit damage.
Expert guidance on bracket installation and chassis mounting procedures. We help ensure your DZ95259740384 brackets provide secure long‑term tank support.
For current stock availability and delivery scheduling on the genuine Urea Tank Bracket DZ95259740384, please use the contact buttons above.
