Z-Shaped Bend Plate (Left)
Z-Образная Пластина Левая
Placa en Z Izquierda
OEM Z-Shaped Bend Plate (Left) DZ95319931151 precision‑formed for the Shacman X5000 front chassis structure. This purpose‑designed DZ95319931151 offset bracket bridges misaligned mounting surfaces, providing secure attachment at the left side frame interface.
Fabricated from high‑strength structural steel with durable anti‑corrosion coating, the Z-Shaped Bend Plate (Left) DZ95319931151 maintains its offset geometry under continuous vibration and dynamic chassis loading.
Replacing a deformed or corroded bend plate with the genuine DZ95319931151 component restores proper component alignment and prevents the stress concentrations that lead to bracket fatigue.
| Parameter | Specification |
|---|---|
| OEM Part Number | DZ95319931151 |
| Product Name | Z-Shaped Bend Plate (Left) |
| Brand / Model | Shacman X5000 |
| Material | High‑Strength Steel with Black Powder Coating |
| Plate Type | Z‑shaped offset bracket with reinforcement ribs |
| Position | Left side chassis interface |
| Mounting Hole Diameter | 12.50 mm (multiple mounting points) |
| Material Thickness | 5.00 mm |
| Corrosion Protection | Black powder coating, 600 hours salt spray rated |
| Application | Shacman X5000 front chassis component offset mounting |
The DZ95319931151 Z‑shaped bend plate is a structural adapter that connects components whose mounting surfaces are not coplanar. Its offset profile bridges the gap between different chassis planes.
In the Shacman X5000 front structure, this plate provides a rigid connection at the left side frame interface, transferring loads between the bumper assembly and the chassis while accommodating the required dimensional offset.
The Z-Shaped Bend Plate (Left) DZ95319931151 is engineered with reinforcement ribs that prevent the plate from straightening under load, maintaining the designed offset geometry throughout the vehicle’s service life.
The DZ95319931151 plate is stamped from high‑strength structural steel with formed reinforcement ribs that provide rigidity while managing weight. The powder coating ensures durable corrosion protection.
The precise Z‑bend angle is maintained through controlled forming processes, ensuring consistent fit with mating chassis and bumper components at the designated left side mounting position.
The DZ95319931151 plate bolts between the mating chassis and bumper components using high‑strength fasteners through the pre‑punched mounting holes. Bolts must be torqued to specification.
The plate must be oriented correctly according to the service manual to ensure the Z‑offset direction matches the design intent for proper component alignment and load transfer.
Each production batch of DZ95319931151 plates undergoes dimensional inspection to verify bend angle, hole positions, and overall geometry against engineering specifications using precision measurement.
Powder coating adhesion and thickness are verified to ensure the finish meets durability requirements for long‑term exposure to road debris and environmental conditions.
A straightened or deformed DZ95319931151 plate indicates that the component has been overloaded, losing its designed offset geometry and requiring immediate replacement.
Rust staining or bubbling of the powder coating indicates corrosion penetration. Cracks at the bend line or around mounting holes are evidence of fatigue and mandate replacement.
During front‑end inspections or collision repair, the bend plate should be checked for deformation and secure attachment. Damaged plates must be replaced to maintain structural integrity.
The DZ95319931151 plate is specifically designed for the left side of the Shacman X5000 front chassis, with bend angle and hole pattern matching the factory‑specified interface dimensions.
Fleet workshops should maintain spare left and right bend plates for prompt replacement when collision damage or corrosion compromises the original components during front‑end repairs.
Aftermarket plates with incorrect bend angles can cause component misalignment. We supply only the authentic Shacman X5000 Z-Shaped Bend Plate (Left) DZ95319931151 built to OEM specifications.
Each plate is individually packaged with protective wrapping. The part number DZ95319931151 is clearly printed on the packaging for immediate identification.
Our international logistics network ensures genuine DZ95319931151 Z‑shaped bend plates are available for dispatch to dealerships and fleet facilities worldwide.
Single left side Z‑shaped bend plate with powder coating. Ready for installation between chassis and bumper components.
Expert guidance on bend plate installation and chassis component alignment. We help ensure your DZ95319931151 plate provides correct offset mounting.
For current stock availability on the genuine Z-Shaped Bend Plate (Left) DZ95319931151, please use the contact buttons above.
