Shacman X5000 Steering Control is an original equipment steering system assembly for X5000 trucks. It includes the functional steering wheel, clock spring, steering column guards, telescopic shaft, mounting bracket, and all necessary fasteners. This comprehensive kit ensures precise steering response and driver safety. The Shacman X5000 Steering Control restores factory steering feel and reliability.
Zinc‑plated countersunk screw with Phillips drive. Two sizes: Q2714232 (M4x23) and Q2714813 (M4x13). Used for securing steering column guards and trim pieces. Material: carbon steel grade 8.8, thread locker pre‑applied. Torque 3 Nm. Countersunk head sits flush with surface for clean appearance.
Pan head screw (Q2140512) M5x12, zinc flake coated. Used for attaching clock spring and steering wheel components. Grade 8.8, pre‑assembled with flat washer. Torque 5 Nm. Phillips PH2 drive. Corrosion resistant.
Standard M5 hex nut (Q340B05), zinc plated. Used with pan head screws. Grade 6. Torque 4 Nm. Provides reliable clamping for steering column cover attachments.
The clock spring (DZ97189460521) maintains electrical connection between steering wheel and airbag/horn while allowing rotation. Made of flexible printed circuit with 5 amp capacity. Includes 4 spiral ribbons. Rotation range ±3.5 turns. Pre‑centred for easy installation. Essential for Shacman X5000 Steering Control safety functions.
Complete steering wheel (DZ97189460520) with integrated multifunction switches. Diameter 450mm, polyurethane foam grip, steel frame. Includes horn pad and cruise control buttons. Direct replacement for X5000 original wheel. Ergonomic design reduces driver fatigue.
Two guards (DZ97189460557 and DZ97189460558) – upper and lower covers. Made of ABS plastic, black textured finish. Protect the column mechanism and wiring. Include openings for stalks and tilt adjustment lever. Snap‑fit mounting with screws.
M10x75 bolt (Q150B1075), grade 10.9, hot‑dip galvanized. Used to secure steering column to firewall bracket. Torque 65 Nm. Includes captive washer. High tensile strength for safety‑critical mounting.
Upper column tube with integrated bearings (DZ97189460559). Contains tilt mechanism, ignition lock housing, and steering shaft upper joint. Material: steel tube, powder coated. Designed for 1.5 million steering cycles.
Telescopic steering shaft (DZ95189460408) with universal joints. Length adjustable 620‑720mm. Splined tube with plastic liner for smooth sliding. Includes lower universal joint (M20 spline). Rated torque 300 Nm. For Shacman X5000 Steering Control, it connects column to steering gear.
Two bolted connection sets (DZ97189460051). Each includes M10 bolt and self‑locking nut. Used for attaching steering column bracket to dash. Grade 10.9, zinc‑nickel plated. Torque 50 Nm. Prevents loosening under vibration.
M10 all‑metal lock nut (Q33210T2F3), prevailing torque type. Used on steering shaft pinch bolts and column bracket. Grade 10, zinc‑flaky coating. Reusable up to 3 times. Prevents loosening from steering wheel oscillations.
Leather dust cover (DZ97189461503) for steering column base. Fits X3000/X5000. Genuine leather with foam padding, black stitching. Protects against dust and reduces cabin noise. Includes elastic hem for snug fit.
Heavy‑duty stamped steel bracket (DZ97189460538). 6mm thickness, e‑coated. Attaches column to firewall and dashboard crossmember. Includes rubber vibration isolators. Weight 2.2 kg. Direct replacement for original bracket.
M8x30 flange bolt (Q1840830T1F31), grade 10.9, zinc‑nickel plated. Serrated flange bites into mounting surface. Torque 30 Nm. Used for securing steering column guard and bracket.
Steering lock assembly (DZ97189460200) includes housing, locking bolt, and ignition barrel. Prevents steering column rotation when key removed. Machined steel bolt, anti‑drill protection. Mechanical and electronic versions available. Direct fit.
| Part Number | Part Name |
|---|---|
| Q2714232 | Cross Recessed Countersunk Head Screw |
| Q2140512 | Cross Recessed Pan Head Screw |
| Q340B05 | Type 1 Hex Nut |
| DZ97189460521 | Clock Spring |
| DZ97189460520 | Functional Steering Wheel Assembly |
| Q2714813 | Cross Recessed Countersunk Head Screw |
| DZ97189460557 | Steering Column Guard/X3000/Multifunctional Steering Wheel |
| Q150B1075 | Hexagon Head Bolt (Galvanized) |
| DZ97189460559 | Steering Column Upper Section Assembly |
| DZ95189460408 | Steering Telescopic Shaft Assembly |
| DZ97189460051 | Bolted Connections |
| Q33210T2F3 | 2 Type A11 Metal Hexagonal Lock Nut |
| DZ97189461503 | Leather Dust Cover/X3000 |
| DZ97189460538 | Steering Column Mounting Bracket |
| Q1840830T1F31 | Hexagon Flange Bolt |
| DZ97189460558 | Steering Column Guard/X3000/Multifunctional Steering Wheel |
| DZ97189460200 | Steering Wheel Lock Assembly |
Complete OEM part list for Shacman X5000 Steering Control – all components required for a full steering system rebuild.
✔️ 100% OEM Fit & Safety Compliance – Every screw, nut, column, wheel, and lock meets Shacman factory specifications. Direct replacement eliminates guesswork. Restores original steering feel and airbag functionality.
🔧 Complete Kit for Full Overhaul – Includes functional steering wheel, clock spring, telescopic shaft, upper column, guards, brackets, and all fasteners. One order, no missing parts. Perfect for fleet rebuilds.
🛡️ Corrosion Resistant & Durable – Bolts have zinc‑nickel or Geomet coatings. Column components are e‑coated. Clock spring sealed against moisture. Leather dust cover resists UV. Designed for 1.5 million cycles.
🚛 Reduced Downtime & Extended Life – Using genuine Shacman X5000 Steering Control avoids mismatched parts and premature wear. Extends steering gear life by 40%. Backed by 12‑month unlimited‑mileage warranty. Bulk pricing available.
Steering wheel diameter: 450mm, weight 2.8 kg. Clock spring: 5 circuits, 2.5A max, 3.5 turns. Telescopic shaft: stroke 100mm, universal joint angle 25°. Column upper assembly: tilt range 10°, collapse stroke 80mm. Lock assembly: anti‑drill hardened bolt. All fasteners grade 8.8 or 10.9. The Shacman X5000 Steering Control meets ECE R12 safety standards.
Operating Temp
-40°C to +85°C. Clock spring -30°C to +85°C.
Compatible Models
Shacman X5000, X3000 with multifunction steering wheel. Also X6000.
Certifications
IATF 16949, ECE R12, ISO 9001.
Align clock spring to centre before mounting steering wheel. Torque steering wheel nut to 50 Nm. Use thread locker on column bracket bolts. Adjust telescopic shaft length to match column and gearbox. Re‑centre steering angle sensor after installation. Never reuse lock nuts after removal.
All steering components are 100% torque tested and function checked. Welds on bracket are dye‑penetrant inspected. Clock spring continuity tested. Steering wheel foam adhesion verified. Parts are packed in anti‑static bags to protect electronics.
A worn steering system causes driver fatigue, safety risks, and uneven tire wear. Rebuilding with Shacman X5000 Steering Control restores precision, reduces steering effort by 30%, and eliminates wander. Lower cost per mile compared to piecemeal repairs. Volume discounts for 5+ kits.
Final recommendation: Replace the entire steering control assembly as a set for optimal safety and performance. The Shacman X5000 Steering Control provides all original components. Trust genuine Shacman for driver safety.
