Support Corner Plate/F/Four Hole/250/Height=240
Угловой Опорный Кронштейн
Escuadra de Refuerzo
OEM Support Corner Plate/F/Four Hole/250/Height=240 DZ96259316324 precision‑formed for the Shacman X5000 chassis structure. This heavy‑duty DZ96259316324 reinforcement bracket strengthens frame corner joints, distributing stress and preventing fatigue cracking at critical connection points.
Fabricated from high‑strength structural steel with durable anti‑corrosion coating, the Support Corner Plate DZ96259316324 provides essential reinforcement at chassis junctions subjected to torsional and bending loads during vehicle operation.
Replacing a damaged or corroded corner plate with the genuine DZ96259316324 component restores proper frame strength and prevents the progressive damage that compromises chassis integrity and vehicle safety.
| Parameter | Specification |
|---|---|
| OEM Part Number | DZ96259316324 |
| Product Name | Support Corner Plate/F/Four Hole/250/Height=240 |
| Brand / Model | Shacman X5000 |
| Material | High‑Strength Structural Steel with Black Powder Coating |
| Plate Type | Formed steel corner reinforcement with 4 mounting holes |
| Mounting Hole Pattern | 4‑hole rectangular pattern, 14.00 mm diameter |
| Plate Width | 250.00 mm |
| Plate Height | 240.00 mm |
| Material Thickness | 6.00 mm |
| Application | Shacman X5000 chassis frame corner joint reinforcement |
The DZ96259316324 support corner plate strengthens critical chassis frame joints where longitudinal rails meet crossmembers or bracket attachments. It distributes concentrated loads over a wider area to prevent fatigue.
Heavy truck frames experience significant torsional and bending stresses during operation. Corner plates at junction points increase the effective thickness and stiffness, reducing stress per unit area and extending frame life.
The four‑hole mounting pattern and 250 by 240‑millimeter dimensions of the Support Corner Plate DZ96259316324 provide substantial load distribution at the designated chassis location for this vehicle platform.
The DZ96259316324 plate is fabricated from 6‑millimeter thick high‑strength structural steel, providing substantial reinforcement at the chassis junction point where it is installed for maximum durability.
The black powder coating provides durable protection against stone chips, road spray, and environmental exposure, maintaining the plate’s structural cross‑section throughout the vehicle’s service life in demanding conditions.
The DZ96259316324 plate is positioned at the designated chassis junction and secured with four high‑strength bolts through the pre‑punched mounting holes, torqued to specification.
The mating frame surfaces must be clean and free of corrosion before installation. The plate must sit flat against the frame members without gaps that would indicate misalignment or debris entrapment.
Each production batch of DZ96259316324 plates undergoes dimensional verification to confirm hole positions, overall dimensions, and material thickness against engineering specifications.
Coating thickness and adhesion testing ensure the powder coating meets durability requirements for long‑term chassis service in demanding environmental conditions.
Rust staining or bubbling of the powder coating on the DZ96259316324 plate indicates corrosion has penetrated the protective layer, potentially reducing the effective thickness and reinforcement capability.
Cracks radiating from bolt holes or along plate edges are evidence of fatigue. Cracked reinforcement plates must be replaced immediately to maintain the structural integrity of the chassis frame joint.
During chassis inspections, corner plates and their fasteners should be checked for tightness and condition. Loose bolts allow joint movement that accelerates wear and fatigue at the connection points.
The DZ96259316324 plate is specifically dimensioned for designated chassis junction points on the Shacman X5000, with hole patterns and overall size matching factory‑specified reinforcement locations.
Fleet operators should maintain spare corner plates for replacement during major chassis repairs, ensuring correct structural components are available to maintain frame integrity and vehicle safety.
Aftermarket corner plates with incorrect dimensions or material can compromise chassis safety. We supply only the authentic Shacman X5000 Support Corner Plate DZ96259316324 built to OEM specifications.
Each plate is individually packaged with protective wrapping. The part number DZ96259316324 is clearly printed on the packaging for immediate identification and verification.
Our international logistics network ensures genuine DZ96259316324 support corner plates are available for dispatch to dealerships and fleet maintenance facilities worldwide.
Single support corner plate with powder coating and four mounting holes. Ready for installation at designated chassis frame junction points.
Expert guidance on corner plate installation and chassis joint reinforcement. We help ensure your DZ96259316324 plate provides effective structural strengthening.
For current stock availability on the genuine Support Corner Plate DZ96259316324, please use the contact buttons above.
