Intermediate Transmission Shaft
Промежуточный Вал КПП
Eje Intermedio de Transmisión
OEM Intermediate Transmission Shaft DZ92189315173 precision‑ground for the Shacman X5000 driveline system. This hardened DZ92189315173 shaft transmits torque between gearbox output and rear axle input, accommodating angular misalignment through universal joint connections.
Manufactured from high‑strength alloy steel with induction‑hardened bearing surfaces, the Intermediate Transmission Shaft DZ92189315173 withstands the torsional loads and vibration of heavy‑duty commercial vehicle operation.
Replacing a bent or worn intermediate shaft with the genuine DZ92189315173 component restores proper driveline alignment and prevents the vibration that causes premature bearing and seal failure.
| Parameter | Specification |
|---|---|
| OEM Part Number | DZ92189315173 |
| Product Name | Intermediate Transmission Shaft |
| Brand / Model | Shacman X5000 |
| Material | High‑Strength Alloy Steel, Induction Hardened |
| Shaft Type | Solid driveline intermediate shaft with splined ends |
| Spline Specification | Involute spline at both ends for yoke attachment |
| Surface Hardness | HRC 55‑60 on bearing and spline surfaces |
| Corrosion Protection | Phosphate coating with anti‑corrosion oil film |
| Balancing | Dynamically balanced for smooth operation |
| Application | Shacman X5000 transmission to rear axle driveline connection |
The DZ92189315173 intermediate transmission shaft is a critical driveline component that bridges the transmission output and the rear axle input. It transmits engine torque through universal joints at each end of the shaft.
This shaft must accommodate the angular changes that occur as the rear axle moves vertically relative to the fixed transmission position during suspension travel over uneven road surfaces and loading conditions.
The induction‑hardened splines and bearing surfaces resist the wear that occurs under high‑torque loading, maintaining precise fit with the universal joint yokes and support bearings throughout the vehicle’s service life.
The DZ92189315173 shaft is manufactured from high‑strength alloy steel with induction‑hardened surfaces at the spline and bearing areas, providing excellent wear resistance where it matters most.
The phosphate coating provides corrosion protection while the anti‑corrosion oil film helps prevent fretting at the spline interfaces with the universal joint yokes during high‑torque operation.
The DZ92189315173 shaft installs with universal joint yokes at both ends. The yokes must be correctly phased to prevent driveline vibration, and the retaining bolts torqued to specification.
Driveline angular alignment should be verified after installation to ensure the operating angles at both universal joints are within the specified range, preventing premature joint and bearing wear.
Each DZ92189315173 shaft undergoes dimensional inspection of spline profiles, bearing diameters, and overall straightness to ensure proper fit and smooth driveline operation in service.
Dynamic balancing is performed on each shaft to minimize vibration, with correction weights applied as needed to meet the specified balance grade for heavy‑duty commercial vehicle driveline applications.
Driveline vibration that increases with vehicle speed indicates that the DZ92189315173 shaft may be bent, out of balance, or have worn splines causing excessive runout during high‑speed rotation.
Worn or fretted splines can create driveline backlash that produces a clunking sound during acceleration or deceleration, requiring shaft inspection and possible replacement to prevent further component damage.
During driveline service, the shaft should be inspected for straightness, spline condition, and surface integrity. Any damage that cannot be corrected requires shaft replacement to maintain driveline reliability.
The DZ92189315173 shaft is specifically configured for the Shacman X5000 driveline system, with spline dimensions, overall length, and balance specification matching this vehicle’s powertrain layout.
Fleet operators should maintain spare intermediate shafts and universal joint components for prompt replacement when driveline issues are diagnosed, minimizing vehicle downtime from driveline failures.
Aftermarket intermediate shafts with incorrect spline specifications or balance can cause driveline vibration. We supply only the authentic Shacman X5000 Intermediate Transmission Shaft DZ92189315173 built to OEM specifications.
Each shaft is individually packaged with protective coating and spline guards. The part number DZ92189315173 is clearly printed on the packaging for immediate identification and verification.
Our international logistics network ensures genuine DZ92189315173 intermediate transmission shafts are available for dispatch to dealerships and fleet maintenance facilities worldwide.
Complete intermediate transmission shaft with hardened splines, phosphate coating, and protective guards. Ready for driveline installation.
Expert guidance on intermediate shaft installation and driveline alignment. We help ensure your DZ92189315173 shaft provides smooth torque transmission.
For current stock availability on the genuine Intermediate Transmission Shaft DZ92189315173, please use the contact buttons above.
