Side Turn Signal Floor Harness
Жгут проводов напольного бокового указателя поворота
Arnés de piso del intermitente lateral
The genuine Shacman X5000 Side Turn Signal Floor Harness with OEM number DZ97189772783 is a dedicated wiring assembly designed to power and control the LED side turn signal indicators on the Shacman X5000 heavy‑duty truck. This floor harness ensures reliable, interference‑free transmission of turn signal commands from the vehicle’s body control module (BCM) to the high‑brightness LED markers located on the cab’s side panels, enhancing visibility and safety during lane changes and turns.
Manufactured to exact Shacman specifications, DZ97189772783 features high‑grade cross‑linked polyethylene wire insulation, corrosion‑resistant terminals, and OEM‑specific connectors that guarantee a direct, plug‑and‑play installation without splicing or modifications. Every wire length, connector position, and routing clip matches the original floor layout, ensuring a perfect fit within the cab and along the sidewall. This harness is essential for restoring full side turn signal functionality after damage, wear, or during a lighting system upgrade.
A faulty or degraded harness can cause intermittent or complete failure of the side turn signals, compromising vehicle visibility and safety. Installing OEM DZ97189772783 restores reliable electrical connectivity, ensuring that the LED indicators flash brightly and consistently with the main turn signals. This harness is a critical component for maintaining the X5000’s safety and compliance with lighting regulations.
Each harness is 100% continuity‑tested, inspected for terminal retention, and verified for correct connector orientation and protective routing. Choose genuine Shacman quality for durable, long‑lasting side turn signal electrical performance.
| Parameter | Specification |
|---|---|
| OEM Part Number | DZ97189772783 |
| Product Name | Side Turn Signal Floor Harness (LED) |
| Brand | Shacman (Genuine OEM) |
| Application | Shacman X5000 – LED side turn signal indicators |
| Harness Type | Side turn signal interface harness |
| Wire Gauge | 0.5 mm² to 1.0 mm² (power and signal), color‑coded per Shacman standard |
| Insulation Material | Cross‑linked polyethylene (XLPE), heat‑resistant to 105°C |
| Connector Types | OEM‑specified 4‑pin and 6‑pin waterproof connectors (Tyco, Delphi, or equivalent) |
| Protective Covering | Anti‑abrasion TESA tape and flexible PVC conduit in high‑wear areas |
| Total Length | Approx. 2.8 m (includes branch sections for left and right side markers) |
| Terminal Material | Tin‑plated copper, gold‑plated for signal circuits |
| Temperature Range | -40°C to +105°C |
| Weight (approx.) | 0.55 kg |
| Standards | ISO 9001, IATF 16949, SAE J1128, Shacman Q/SC 805 |
The Shacman side turn signal floor harness DZ97189772783 is engineered with exact wire lengths, connector placements, and routing paths that conform to the X5000’s cab floor and sidewall architecture. Each circuit is color‑coded according to Shacman’s wiring diagrams, simplifying installation and reducing the risk of errors. The wires are made from oxygen‑free copper with cross‑linked polyethylene insulation, providing excellent conductivity, resistance to abrasion, and high‑temperature stability. The harness is wrapped with anti‑abrasion TESA tape and fitted with flexible PVC conduit in areas where it may come into contact with sharp edges, ensuring long‑term durability under the floor carpet and along the side panels.
The integrated connectors are designed to mate directly with the LED side turn signal units and the vehicle’s main body harness, ensuring that every flash command is accurately relayed. The connectors feature positive locking mechanisms that prevent accidental disconnection due to vibration, and the terminals are tin‑ or gold‑plated to resist corrosion and maintain low contact resistance. Each harness is 100% continuity‑tested and subjected to a pull‑test on all terminals to verify retention force. Random samples are subjected to thermal cycling (-40°C to +105°C, 500 cycles), vibration (20G, 10‑2000 Hz), and salt spray (96 hours) to validate the wire insulation, conduit, and connector sealing. These rigorous engineering controls ensure that the DZ97189772783 harness provides reliable, trouble‑free service for the life of the vehicle.
This harness is specifically tailored to interface with LED side turn signal lights, which draw low current but require stable voltage and polarity to function correctly. The harness includes dedicated power and ground circuits for the LEDs, as well as a separate signal line that carries the flash command from the BCM. This configuration ensures that the LED side markers flash in perfect synchronization with the main turn signals, providing a clear, consistent indication to other road users. The robust construction also protects the harness from moisture and vibration, ensuring reliable operation even in harsh weather conditions.
Side turn signals are an essential safety feature on heavy‑duty trucks, alerting other motorists to the driver’s intention to change lanes or turn. The side turn signal floor harness DZ97189772783 is the vital electrical link that powers these indicators, ensuring they operate reliably and are visible from the side of the vehicle. A degraded or damaged harness can cause the side markers to flash intermittently, at the wrong speed, or not at all, significantly reducing the truck’s visibility and increasing the risk of side‑impact collisions. This harness is designed with dedicated circuits for the left and right side markers, ensuring that each side operates independently and reliably. The use of high‑quality wire insulation and sealed connectors prevents moisture ingress, which is a common cause of electrical faults in floor‑mounted harnesses. By restoring full electrical integrity, the DZ97189772783 harness ensures that the side turn signals flash brightly and consistently, enhancing safety during lane changes.
In addition to safety, the harness contributes to the overall reliability of the lighting system. A properly functioning harness prevents the LEDs from flickering or dimming due to voltage drops, ensuring maximum visibility. The harness is also designed to handle the low current draw of LED lights, reducing the load on the vehicle’s electrical system. Fleet operators who prioritize safety will appreciate the reliability and ease of installation of this harness, which reduces downtime and enhances driver confidence. The harness’s color‑coded wires and labeled connectors also make it easier for technicians to troubleshoot any future issues, reducing diagnostic time. The harness is also compatible with both standard and high‑brightness LED side markers, as it is designed to handle the control signals from the BCM.
A reliable side turn signal harness ensures that the indicators flash at the correct rate and brightness, providing a clear signal to other drivers. The DZ97189772783 harness’s low‑resistance conductors and robust connectors ensure that the LEDs receive full power, preventing dimming or erratic flashing. This gives the driver confidence that their intentions are clearly communicated, reducing the risk of accidents.
Installing the Shacman side turn signal floor harness DZ97189772783 is a straightforward process for trained technicians. Begin by disconnecting the vehicle’s battery. Remove the interior trim panels and floor carpet to access the routing path for the harness. Disconnect the old harness (if present) by releasing the locking tabs and unplugging the electrical connectors. Route the new harness along the original path, securing it with the integrated clips and tie‑wraps. Connect the harness to the left and right side LED turn signal units, ensuring that the connectors click securely into place. Connect the main power and signal leads to the vehicle’s BCM or main body harness. Reconnect the battery and test the side turn signals: they should flash in sync with the main turn signals, with no delay or flickering.
This harness is compatible with all Shacman X5000 models from 2015 onward, including the X5000 M12, heavy‑haul, and construction variants, as well as trucks with both halogen and LED side marker systems. It directly replaces original part numbers DZ97189772782 and DZ97189772784. Applications include the side turn signal floor harness for LED indicators. Always verify the OEM marking DZ97189772783 on the harness label before installation. If the vehicle uses a different side marker configuration, ensure that the harness connectors match; if not, consult the vehicle’s wiring diagram for possible adapter requirements.
Keep a spare DZ97189772783 harness in your parts inventory for quick replacement in case of damage. After installation, test the side turn signals in both left and right positions to ensure proper function. If the signals do not operate, check the fuse and relay associated with the turn signal circuit, and verify that the harness is correctly connected to power and ground sources. Ensure that the harness is routed away from moving parts and heat sources.
Periodically inspect the harness for signs of chafing, loose connections, or damaged insulation, especially where it passes through the floor or side panels. If the side turn signals become intermittent, check the harness connectors for corrosion or damage. The harness is designed to be maintenance‑free; however, if any damage is detected, replace the entire harness to avoid potential electrical faults. Ensure that the harness is not pinched by floor trim when reinstalled.
Shacman X5000 trucks are used in a wide range of demanding applications, from construction and mining to long‑haul freight. The side turn signal floor harness DZ97189772783 is designed to withstand the harsh conditions encountered in these environments. The cross‑linked polyethylene insulation resists heat, oil, and abrasion, while the flexible PVC conduit provides additional mechanical protection where needed. The connectors are sealed to prevent moisture and dust ingress, ensuring reliable electrical connections even in heavy rain or dusty conditions. The harness is tested to operate reliably in temperatures from -40°C to +105°C, making it suitable for both arctic and desert climates.
In mining and construction trucks, where vibration and dust are prevalent, the harness’s secure connectors and robust sheathing prevent intermittent faults. For highway fleets, the harness provides a reliable solution for the side turn signal system, ensuring clear visibility in all weather conditions. The harness’s plug‑and‑play design also simplifies the replacement process for fleet maintenance teams, allowing them to restore side signal functionality efficiently. The harness is also compatible with both standard and heavy‑duty LED side markers, as it is designed to handle the control signals from the BCM. The inclusion of dedicated ground and shield wires ensures that the side signals are transmitted without noise, reducing the risk of false triggers.
By using the genuine Shacman harness, fleet operators can avoid the reliability issues associated with aftermarket wiring kits, which often use inferior wire and connectors. The DZ97189772783 harness is backed by Shacman’s quality assurance, providing peace of mind for operators who depend on their side turn signals for safety. The harness’s color‑coded wires and labeled connectors also make it easier for technicians to troubleshoot any future issues, reducing diagnostic time. Its long service life and resistance to environmental factors contribute to lower total cost of ownership.
1. Exact fitment: Designed specifically for X5000 side turn signal routing, with correct wire lengths and connector positions. 2. Superior materials: Cross‑linked polyethylene insulation, gold/tin‑plated terminals, and anti‑abrasion tape. 3. Plug‑and‑play installation: No cutting or splicing required, reducing installation time and errors. 4. LED‑optimized circuits: Dedicated power and ground for stable, flicker‑free LED operation. 5. Full traceability: Batch‑coded with electrical test report and material certification.
Aftermarket harnesses often use low‑grade wire, lack proper connectors, or have incorrect lengths, leading to intermittent side signal faults and potential LED damage. The genuine Shacman harness’s premium materials and exact engineering ensure reliable, long‑lasting performance. Investing in DZ97189772783 protects the vehicle’s side turn signal system, enhances driver safety, and reduces downtime. For fleets, standardizing on genuine harnesses ensures consistent quality and simplifies troubleshooting across all trucks.
A faulty side turn signal harness can lead to reduced visibility, increasing the risk of accidents and costly liability. Replacing a worn or damaged harness with the DZ97189772783 restores full side signal functionality at a minimal cost, preventing these issues. The harness’s long life and corrosion resistance also reduce the frequency of replacements, saving labor and parts costs over the vehicle’s lifetime. Reliable side signals also contribute to driver confidence and safety, enhancing the fleet’s reputation.
Shacman’s side turn signal floor harness DZ97189772783 is produced in an IATF 16949 certified facility. The wire is sourced from approved suppliers and undergoes strict inspection for conductor resistance and insulation thickness. The harness is assembled using automated crimping machines that ensure consistent terminal crimp height and pull‑off strength. The connectors are tested for insertion and retention forces. Each harness is 100% continuity‑tested, with every circuit verified for correct pin‑to‑pin continuity and proper routing. The harness is then wrapped with anti‑abrasion tape and fitted with protective conduit where required, and a final visual inspection is performed.
Random samples are subjected to thermal shock (-40°C to +105°C, 500 cycles), vibration (20G, 10‑2000 Hz), and salt spray (96 hours) to validate durability. Only harnesses that pass all criteria are labeled with the OEM part number and packed in anti‑static bags. This rigorous quality system ensures every DZ97189772783 harness performs identically to the original factory component. Consistency is critical for maintaining the reliability of the side turn signal system and preventing electrical faults across your entire fleet. The facility also complies with REACH and RoHS environmental regulations, using only lead‑free, water‑based coatings.
Genuine Shacman side turn signal floor harness DZ97189772783 is stocked by authorized distributors worldwide. Parts are supplied in sealed anti‑static bags, individually boxed with installation instructions and a wiring diagram, labeled with OEM part number and batch traceability. Bulk packs of 5 harnesses are available for fleet maintenance depots. Expedited shipping options are available through Shacman’s regional logistics hubs in North America, Europe, Asia, Africa, and the Middle East, with typical delivery within 3‑5 business days. Always purchase from certified dealers and verify the holographic authenticity label. Counterfeit harnesses may have incorrect wire gauges, poor connectors, or lack proper insulation, leading to shorts or fires.
For preventive maintenance programs, automated replenishment ensures your workshop never runs out of essential side turn signal harnesses. Keep a stock of DZ97189772783 on every service truck to handle side signal repairs or harness replacements in the field. Many fleets replace these harnesses as part of a scheduled electrical system inspection to ensure reliable side turn signal operation and driver safety.
The Shacman Side Turn Signal Floor Harness DZ97189772783 is a precision‑engineered wiring solution that provides a secure, reliable electrical connection for the LED side turn signal indicators on X5000 trucks. With robust materials, exact fitment, and plug‑and‑play installation, this genuine OEM harness ensures that your side markers flash brightly and consistently, enhancing driver safety and visibility. By choosing DZ97189772783, you restore full side turn signal functionality and protect your vehicle’s electrical system. Don’t trust generic aftermarket wiring – insist on genuine Shacman quality for every side signal harness replacement.
