O-Shaped Ring Seal
Уплотнительное Кольцо (O-Ring)
Junta Tórica de Estanqueidad
This OEM O-shaped ring seal (part 188000340023) is precision-engineered for the Shacman X5000. It provides a static or dynamic seal against fluid or gas leakage in critical vehicle systems.
Manufactured from high-quality synthetic rubber (NBR, FKM, or equivalent), this O-ring withstands constant pressure, temperature extremes, and chemical exposure during heavy-duty commercial vehicle operation.
Replacing worn or hardened O-rings with this genuine component restores leak-free sealing. The OEM number guarantees exact dimensions and material compatibility.
| Parameter | Specification |
|---|---|
| OEM Part Number | 188000340023 |
| Product Name | O-Shaped Ring Seal (O-Ring) |
| Brand / Model | Shacman X5000 |
| Material | Nitrile Rubber (NBR) / Fluoroelastomer (FKM) |
| Hardness (Shore A) | 70 ± 5 |
| Temperature Range | -30°C to +120°C (NBR) / -20°C to +200°C (FKM) |
| Function | Static and Dynamic Sealing (Fluid, Air, Gas) |
| Application | Hydraulic Systems, Pneumatics, Engine, Transmission |
| Packaging | Anti-Corrosion Wrapped with OEM Labeling |
The O-ring is one of the simplest yet most important sealing devices. It is a torus-shaped elastomer that sits in a groove and is compressed to create a tight seal.
As pressure is applied, the O-ring deforms, filling the gap between the two mating surfaces. This prevents the escape of fluids or gases and blocks the entry of contaminants.
Used in both static and dynamic applications, this simple design is highly reliable, inexpensive, and effective for a vast range of pressures and temperatures.
This O-ring is made from a high-quality synthetic rubber, likely Nitrile (NBR) for excellent oil and fuel resistance, or Fluoroelastomer (FKM) for high-temperature applications.
The material is chosen for its ability to retain its elastic properties, resist compression set, and maintain an effective seal throughout its service life.
Before installation, inspect the groove for damage and ensure it is clean and free of debris. Lubricate the O-ring lightly with the system’s fluid to prevent it from rolling or pinching.
Avoid twisting or over-stretching the O-ring during assembly. A twisted O-ring will create a leak path and will fail prematurely.
Each O-ring is inspected for dimensional accuracy (inner diameter, cross-section) and surface defects. Material hardness and tensile strength are verified.
Samples from each batch are tested for compression set to ensure the seal will maintain its shape and effectiveness over time.
Any visible leak from a sealed joint is the most obvious sign of a failed O-ring. Hardening, cracking, or flattening of the O-ring indicates it is no longer effective.
O-rings should always be replaced during any overhaul of a component. Never reuse an O-ring that has been in service, as it may have taken a permanent compression set.
Aftermarket O-rings may be made from incorrect materials or have inaccurate dimensions, leading to immediate or rapid seal failure. We supply only authentic components built to exact OEM specifications.
Each O-ring is individually packaged. The part number 188000340023 is clearly marked.
Our international logistics network ensures prompt dispatch to your facility.
Complete O-shaped ring seal. Ready for installation.
Expert guidance on O-ring selection and installation is available. We help ensure correct fitment for your Shacman X5000.
For current stock availability on this genuine O-shaped ring seal, please use the contact buttons above.
