Heat Shield Transition Bracket Assembly
Переходной Кронштейн
Soporte de Transición
OEM Heat Shield Transition Bracket Assembly DZ96259542649 precision‑formed for the Shacman X5000 engine compartment. This essential DZ96259542649 mounting interface bridges thermal shields to the engine structure, ensuring secure positioning and proper air gap maintenance.
Fabricated from high‑strength steel with heat‑resistant coating, the Heat Shield Transition Bracket Assembly DZ96259542649 withstands the combined demands of exhaust heat exposure and engine vibration.
Replacing a cracked or loose bracket with the genuine DZ96259542649 component restores proper heat shield alignment and prevents the shield contact that causes rattles and thermal protection gaps.
| Parameter | Specification |
|---|---|
| OEM Part Number | DZ96259542649 |
| Product Name | Heat Shield Transition Bracket Assembly |
| Brand / Model | Shacman X5000 |
| Material | High‑Strength Steel with Heat‑Resistant Coating |
| Bracket Type | Formed steel transition with reinforcement gussets |
| Mounting Hole Diameter | 8.50 mm (multiple engine mounting points) |
| Shield Attachment Points | 3‑point mounting with vibration‑resistant grommets |
| Maximum Service Temperature | Up to 500°C ambient exposure |
| Corrosion Protection | High‑temperature resistant coating, 400 hours salt spray |
| Application | Shacman X5000 heat shield to engine mounting interface |
The DZ96259542649 heat shield transition bracket serves as the structural link between thermal protection panels and the engine block or cylinder head. It positions heat shields at the precise distance required for effective thermal isolation.
Proper heat shield positioning requires maintaining a specific air gap between the shield and the hot component. This bracket’s formed geometry establishes that gap while providing rigid support that resists vibration‑induced movement.
The Heat Shield Transition Bracket Assembly DZ96259542649 also accommodates thermal expansion of both the engine and the shield, preventing the stress buildup that could crack either component during heat cycling.
The DZ96259542649 bracket is formed from high‑strength steel with reinforcement gussets at stress points. The heat‑resistant coating maintains its protective properties despite continuous exposure to radiated exhaust heat.
Vibration‑resistant mounting grommets at the shield attachment points isolate the heat shield from engine vibrations, preventing the fatigue cracking that rigid connections would cause over time.
The DZ96259542649 bracket mounts to designated bosses on the engine using high‑strength bolts torqued to specification. The heat shield then attaches to the bracket’s three mounting points with grommets.
After installation, the shield position should be verified to ensure it does not contact surrounding components throughout the engine’s range of motion on its rubber mounts.
Each production batch of DZ96259542649 brackets undergoes dimensional inspection to verify mounting hole positions, bracket angles, and overall geometry against engineering specifications.
The heat‑resistant coating is tested for adhesion and thermal stability, ensuring it remains bonded to the steel substrate through repeated exposure to engine compartment operating temperatures.
Cracks visible at the reinforcement gussets or mounting holes of the DZ96259542649 bracket indicate fatigue damage from sustained vibration. Cracked brackets must be replaced immediately.
A loose or rattling heat shield may indicate that the mounting grommets have hardened or failed, allowing the shield to vibrate against the bracket or engine surfaces.
During engine service, brackets should be inspected for integrity, coating condition, and secure attachment. Replacing compromised brackets maintains the thermal protection system’s effectiveness.
The DZ96259542649 bracket is specifically designed for the Shacman X5000 heat shield configuration and engine mounting points, matching the factory‑specified interface geometry exactly.
Fleet workshops should inspect these brackets during major engine services and maintain spares for prompt replacement when damage or corrosion is discovered.
Aftermarket brackets with incorrect geometry can misalign heat shields, reducing thermal protection. We supply only the authentic Shacman X5000 Heat Shield Transition Bracket Assembly DZ96259542649.
Each bracket is individually packaged with protective wrapping. The part number DZ96259542649 is clearly printed on the packaging for immediate identification.
Our international logistics network ensures genuine DZ96259542649 transition brackets are available for dispatch to dealerships and fleet facilities worldwide.
Complete transition bracket assembly with integrated grommets and mounting provisions. Ready for installation onto engine mounting points.
Expert guidance on bracket installation and heat shield alignment. We help ensure your DZ96259542649 bracket provides secure thermal shield mounting.
For current stock availability on the genuine Heat Shield Transition Bracket Assembly DZ96259542649, please use the contact buttons above.
