The genuine Shacman X5000 Three Layers Of Controller Mounting Brackets with OEM number DZ97189585627 is a precision‑stamped steel assembly designed to securely mount up to three electronic control units (ECUs) or modules in the cab or chassis of the X5000 heavy‑duty truck. This multi‑tier bracket system provides a compact, organized solution for housing engine controllers, transmission modules, and body control units, saving valuable space while ensuring vibration isolation and proper cooling airflow. Manufactured from high‑strength, zinc‑plated steel, DZ97189585627 offers exceptional rigidity, corrosion resistance, and fatigue life. Every mounting hole and slot matches Shacman’s original chassis patterns, guaranteeing a direct, bolt‑on fit. The tiered design allows easy access to each controller for maintenance or replacement without disturbing adjacent units. This component is essential for restoring original factory mounting after controller upgrades, retrofits, or when replacing damaged brackets.
A missing or bent controller bracket can leave expensive electronic modules unsupported, leading to vibration damage, connector stress, and intermittent electrical faults. Installing OEM DZ97189585627 restores a secure, vibration‑damped mounting platform, protecting the vehicle’s critical electronics and ensuring reliable operation. This bracket set is essential for maintaining the integrity of the X5000’s electronic control system.
Each DZ97189585627 bracket set is 100% inspected for dimensional accuracy, plating thickness, and thread integrity. Choose genuine Shacman quality for secure, long‑lasting electronic module mounting.
| Parameter | Specification |
|---|---|
| OEM Part Number | DZ97189585627 |
| Product Name | Three Layers Of Controller Mounting Brackets / Multi‑Module Support |
| Brand | Shacman (Genuine OEM) |
| Application | Shacman X5000 – Engine, transmission, and body control module mounting in cab or chassis |
| Material | High‑strength steel (DC04 or equivalent), zinc‑nickel plated |
| Number of Tiers | 3 layers (adjustable height via slotted holes) |
| Mounting Hole Pattern | Four M8 threaded holes per tier, 80 mm × 60 mm spacing |
| Overall Dimensions (L×W×H) | 280 mm × 180 mm × 150 mm (approx.) |
| Load Capacity (per tier) | ≤ 10 kg (uniformly distributed) |
| Corrosion Protection | Zinc‑nickel plating, 480h salt spray (ASTM B117) |
| Vibration Isolation | Integrated rubber grommets (optional) and slotted holes for damper mounting |
| Hardware Included | M8 bolts, washers, and lock nuts (12 sets) |
| Temperature Range | -40°C to +105°C (cabin/chassis environment) |
| Weight (approx.) | 1.8 kg (complete set) |
| Standards | ISO 9001, IATF 16949, Shacman Q/SC 760 |
The Shacman three‑layer controller mounting bracket set DZ97189585627 is designed to provide a stable, organized mounting solution for multiple electronic control modules. Each tier is fabricated from high‑strength steel stampings with reinforced ribs to prevent flexing under dynamic loads. The tiers are interconnected by rigid vertical struts that maintain precise alignment and allow the assembly to be bolted securely to the vehicle’s cab floor or chassis rail. Slotted mounting holes on each tier accommodate different controller footprints, while the open‑frame design promotes airflow around the modules, preventing heat buildup. The entire assembly is zinc‑nickel plated to withstand the harsh under‑cab environment, including road salt, moisture, and vibration. The included rubber grommets (optional) can be fitted to reduce transmitted vibration to sensitive electronics, extending their service life. The bracket set is designed to be easily disassembled for module replacement, with all fasteners included.
Each bracket is 100% inspected for dimensional accuracy, ensuring that the tier spacing and hole patterns match the original X5000 controller layouts. The plating thickness is verified to exceed 480 hours of salt spray resistance. Random samples are subjected to static load testing (2x rated capacity) and vibration testing (20G, 10‑2000 Hz) to validate structural integrity. The integrated hardware is grade 10.9, ensuring secure clamping. These engineering controls guarantee that the DZ97189585627 brackets provide reliable, long‑lasting support for the truck’s critical electronic systems.
The three‑tier design allows up to three controllers to be mounted in the footprint of a single unit, freeing up valuable cab or chassis space for other components. The open framework ensures that natural convection cooling is not impeded, reducing the risk of thermal derating of the ECUs. The adjustable height of each tier also accommodates different module heights, making the bracket versatile for various controller combinations.
In modern heavy‑duty trucks like the Shacman X5000, electronic control modules are the brains of the engine, transmission, ABS, and body systems. These units are sensitive to mechanical shock, vibration, and heat. A poorly supported controller can suffer from cracked circuit boards, broken solder joints, or loose connectors, leading to intermittent faults, diagnostic trouble codes, and even complete system failure. The DZ97189585627 bracket set provides a rigid, vibration‑damped platform that isolates the modules from road and engine vibrations. The tiered design also ensures that each module is easily accessible for diagnostics or replacement without disturbing the others, reducing service time.
When a controller bracket is damaged, missing, or improperly installed, the modules can sag or shift, causing stress on the wiring harness connectors and potentially leading to open circuits or shorts. The OEM bracket set restores the factory mounting geometry, ensuring that all connectors align correctly and that the wiring harness is not under tension. This is especially critical in vehicles with high‑mileage or severe‑duty use, where vibration fatigue is a common cause of electronics failure. By using genuine Shacman brackets, fleet operators can significantly reduce the incidence of electrical faults and avoid costly roadside breakdowns. The brackets also provide a grounded mounting surface, which is essential for proper electromagnetic compatibility (EMC) and can help reduce electrical noise interference between modules.
The zinc‑nickel plating of the DZ97189585627 brackets offers superior corrosion protection, ensuring that the mounting hardware remains easy to service even after years of exposure to salt, mud, and moisture. This is particularly important for trucks operating in coastal areas or regions with heavy winter road salting. The brackets are also designed to accommodate the installation of optional rubber vibration isolators, which can be added to further reduce transmitted vibration for especially sensitive modules like the engine ECU.
Electronic modules that are allowed to vibrate freely can develop micro‑cracks in their PCB solder joints, leading to intermittent communication failures that are notoriously difficult to diagnose. The DZ97189585627 bracket’s rigid structure and optional isolation dampers prevent such damage, ensuring reliable, consistent system operation. By securing the modules firmly, the brackets also protect the connectors from fretting corrosion caused by micro‑movement.
Installing the Shacman three‑layer controller mounting bracket set DZ97189585627 is a straightforward procedure. Begin by removing the old bracket (if present) and cleaning the mounting area on the cab floor or chassis rail. Assemble the three tiers according to the desired spacing, using the included M8 bolts and nuts. Secure the bracket assembly to the vehicle using the pre‑drilled chassis holes (pattern matches X5000 factory locations). Torque the fasteners to 25‑30 Nm. Then mount each controller to its designated tier using the provided hardware, ensuring that the connectors are accessible. If rubber isolators are used, insert them between the controller and the bracket before tightening.
This bracket set is compatible with all Shacman X5000 models from 2015 onward, including the X5000 M12, heavy‑haul, and construction variants. It directly replaces original part numbers DZ97189585626 and DZ97189585628. Applications include mounting the engine ECU (ECM), transmission controller (TCM), and body control module (BCM) together in a compact stack. Always verify the OEM marking DZ97189585627 on the brackets before installation. If your vehicle uses a different controller layout, the slotted holes allow for some adjustment; however, it is recommended to use the factory bolt pattern for optimal fit.
When installing multiple brackets, ensure that the wiring harnesses have enough slack to accommodate the tiered layout without stress. Keep a spare DZ97189585627 bracket set in your parts inventory for rapid module replacement or retrofits. After installation, verify that all modules are securely fastened and that no connectors are strained.
Periodically check the bracket bolts for tightness, especially after the first 1,000 km of operation. Inspect the brackets for signs of corrosion or bending. If any damage is detected, replace the bracket set immediately. Keep the mounting surfaces clean to prevent galvanic corrosion between dissimilar metals.
Shacman X5000 trucks are used in some of the most demanding environments – mining, construction, oilfields, and long‑haul freight. The controller mounting bracket set DZ97189585627 is designed to withstand these conditions. The zinc‑nickel plated steel resists corrosion from road salt, mud, and chemical spills. The robust construction can withstand high vibration levels (tested to 20G) without loosening or fatigue cracking. The open design allows debris to fall through, preventing accumulation that could trap moisture.
In mining and construction trucks, electronic modules are exposed to constant dust and shock. The DZ97189585627 brackets keep the ECUs securely in place, preventing them from being dislodged by impacts. In arctic operations, the steel retains its impact toughness down to -50°C, and the plating prevents rust from condensation. For highway fleets, the brackets provide a stable mount that reduces the risk of connector fretting, a common cause of intermittent faults that can be difficult to diagnose. The bracket set is also compatible with the addition of heat shields (sold separately) for applications where exhaust heat is a concern.
The tiered design also facilitates easier harness routing, as each module’s connectors can be oriented for optimal cable management. This reduces the risk of chafing and improves the overall neatness of the electrical installation. By using genuine Shacman brackets, fleet operators can maintain a consistent, professional appearance and ensure that all modules are correctly positioned for cooling airflow.
1. Exact fitment: Precision‑matched to X5000 chassis mounting points, ensuring bolt‑on installation without modifications. 2. Superior material: High‑strength zinc‑nickel plated steel offers durability and corrosion resistance. 3. Organized multi‑tier design: Allows secure mounting of up to three controllers in a compact, accessible layout. 4. Vibration damping option: Accommodates rubber isolators to protect sensitive electronics. 5. Full traceability: Batch‑coded with material test certificate and load test report. Aftermarket brackets often use thinner steel, have poor corrosion protection, or lack precise hole alignment, leading to loose modules and potential damage. The genuine Shacman bracket’s premium materials and exact dimensions ensure reliable support and long service life. Investing in DZ97189585627 protects your truck’s electronic systems, reduces downtime, and maintains warranty compliance. For fleets, standardizing on genuine brackets ensures consistent module mounting and simplifies service across all trucks.
A single ECU failure due to vibration or corrosion can cost thousands in replacement and programming. By using the DZ97189585627 bracket set, you significantly reduce the risk of such failures. The bracket’s long life and corrosion resistance also minimize the need for replacement, saving labor and parts costs over the vehicle’s lifetime. Additionally, organized module mounting simplifies diagnostics, reducing technician time.
Shacman’s three‑layer controller mounting bracket set DZ97189585627 is produced in an IATF 16949 certified facility. The steel is stamped and formed on high‑capacity presses, then welded using robotic welding for consistent joint strength. The welded assembly is normalized to relieve residual stresses, then zinc‑nickel plated in a controlled electroplating line with thickness verification by X‑ray fluorescence. The mounting holes are machined to precise tolerances, and each set is assembled with the included hardware. Random samples are subjected to static load testing (2x rated capacity), vibration testing (20G, 10‑2000 Hz), and salt spray testing (480 hours). Only brackets that pass all criteria are laser‑marked with the OEM part number and packaged in protective bags. The hardware is grade 10.9 and is tested for tensile strength.
This rigorous quality system ensures every DZ97189585627 bracket set performs identically to the original factory component. Consistency is critical for maintaining electronic module security and preventing vibration‑related failures across your entire fleet. The facility also complies with REACH and RoHS environmental regulations, using only lead‑free, water‑based coatings.
Genuine Shacman three‑layer controller mounting bracket set DZ97189585627 is stocked by authorized distributors worldwide. Parts are supplied in sealed anti‑corrosion bags, individually boxed with all hardware and installation instructions, labeled with OEM part number and batch traceability. Bulk packs of 5 sets are available for fleet maintenance depots. Expedited shipping options are available through Shacman’s regional logistics hubs in North America, Europe, Asia, Africa, and the Middle East, with typical delivery within 3‑5 business days. Always purchase from certified dealers and verify the holographic authenticity label. Counterfeit brackets may be made from mild steel, lack proper plating, or have inaccurate hole spacing, leading to misalignment and potential module damage.
For preventive maintenance programs, automated replenishment ensures your workshop never runs out of essential controller brackets. Keep a stock of DZ97189585627 on every service truck to handle module upgrades, retrofits, or bracket replacements in the field. Many fleets replace these brackets during major electrical system overhauls to ensure all modules are securely mounted.
The Shacman Three Layers Of Controller Mounting Brackets DZ97189585627 is a robust, precision‑engineered steel assembly that provides secure, organized mounting for up to three electronic control units. With zinc‑nickel plating, vibration‑damping options, and exact factory fitment, this genuine OEM bracket set protects your vehicle’s critical electronics from damage and ensures reliable operation. By choosing DZ97189585627, you safeguard your investment and reduce downtime. Don’t trust generic aftermarket supports – insist on genuine Shacman quality for every module mounting application.
