CR Box Rear Bracket
Кронштейн SCR коробки задний
Soporte Trasero Caja SCR
The SCR Box Rear Bracket DZ97259543533 is a genuine, high-precision OEM component engineered exclusively for the Shacman X5000 Truck. This critical part, bearing the official OEM number DZ97259543533, serves as the primary structural support for the Selective Catalytic Reduction (SCR) system’s housing at the rear. Designed and manufactured by Shacman to meet rigorous quality standards, this bracket ensures the secure and stable mounting of the SCR box, which is vital for effective emissions control and optimal engine performance. Its robust construction directly contributes to the truck’s compliance with environmental regulations and long-term operational reliability. Using the correct bracket, specifically DZ97259543533, is essential to prevent misalignment, vibration, and potential damage to the expensive SCR system components.
Crafted from premium-grade materials, this rear bracket withstands the constant stress, shock, and vibrational forces encountered during heavy-duty hauling. It acts as a foundational element, protecting the integrity of the entire after-treatment assembly. A failing or substandard bracket can lead to cracks in the SCR casing, loose connections, or even complete system detachment, resulting in costly repairs and vehicle downtime. The Shacman DZ97259543533 bracket guarantees a perfect factory fit, ensuring all mounting points align correctly with the X5000’s chassis. This precise engineering minimizes wear on adjacent parts and maintains the system’s efficacy in reducing nitrogen oxide (NOx) emissions. Investing in this genuine component is a proactive measure for fleet managers and owners focused on maximizing uptime and maintaining their truck’s value.
| Parameter | Specification / Value |
|---|---|
| OEM Part Number | DZ97259543533 |
| Product Name | SCR Box Rear Bracket |
| Compatible Truck Model | Shacman X5000 Series |
| Brand | Shacman (Genuine Part) |
| Primary Material | High-Tensile Steel, Galvanized |
| Finish / Coating | Anti-Corrosion Powder Coating |
| Weight (Approx.) | 8.5 kg |
| Mounting Type | Bolt-On, Direct to Chassis |
| Function | Structural Support for Rear SCR Module |
The Shacman DZ97259543533 bracket is not just a simple metal piece. Its design incorporates several advanced features. The high-tensile steel core provides exceptional load-bearing capacity. This ensures it can support the substantial weight of the SCR box. A thick, galvanized layer offers foundational rust prevention. This is further enhanced by a robust powder coating. This dual-layer protection is crucial for longevity. It resists corrosion from road salts, chemicals, and moisture.
Precision laser cutting and CNC forming guarantee dimensional accuracy. Every hole and contour matches the Shacman X5000’s chassis perfectly. This eliminates the need for forceful adjustment during installation. Forceful adjustment can introduce stress points. The bracket also features reinforced gussets at high-stress junctions. These gussets distribute mechanical loads more evenly. This design prevents fatigue cracking over millions of vibration cycles. The result is a component built for the harsh reality of freight transportation.
The SCR system is a cornerstone of modern diesel engine compliance. It injects Diesel Exhaust Fluid (DEF) into the exhaust stream. A chemical reaction then converts harmful NOx into harmless nitrogen and water. The SCR box houses vital components for this process. These include the DEF dosing module, mixer, and sensors. The rear bracket DZ97259543533 provides unwavering support for this entire assembly.
Any movement or flex in the bracket can be detrimental. It can misalign the dosing injector, leading to poor spray patterns. It can stress electrical connections to sensors, causing fault codes. In severe cases, it can crack the SCR catalyst housing. A failed emissions test and costly downtime are likely outcomes. This bracket is the unsung hero that keeps the system rigid. It ensures precise alignment and operational integrity for hundreds of thousands of miles.
Replacing the SCR Box Rear Bracket requires mechanical expertise. Always follow official Shacman workshop manuals and procedures. Safety first: park on level ground and engage the parking brake. Safely support the SCR box with a transmission jack or similar device. This removes the load before unbolting the old bracket DZ97259543533.
Thoroughly clean the chassis mounting surface. Remove any rust, debris, or old sealant. Position the new bracket, aligning all bolt holes perfectly. Use the correct grade of bolts and fasteners as specified. Torque all fasteners to the manufacturer’s recommended values in a cross pattern. Avoid over-tightening, as this can warp the bracket or strip threads. Finally, lower the SCR box onto the new bracket and secure it. A professional installation guarantees optimal performance and safety.
Opting for the genuine DZ97259543533 bracket over generic alternatives offers clear advantages. The foremost benefit is guaranteed compatibility. It fits the Shacman X5000 precisely without modification. This saves significant labor time and avoids installation headaches. You also receive assured quality from a trusted manufacturer. Shacman parts are engineered and tested to withstand the same conditions as the original truck.
This translates to longer service life and better value. While the initial cost might be higher, the total cost of ownership is lower. You avoid premature failures, secondary damage, and repeated replacements. Using genuine parts like this also helps maintain your truck’s warranty validity. It ensures the emissions system functions as designed, keeping you compliant with regulations. Protect your investment by insisting on the correct part number: DZ97259543533.
Regular visual inspections can catch bracket issues early. Look for visible cracks, especially near welded joints and mounting holes. Significant rust that has eaten into the metal is a red flag. Elongated or wallowed-out bolt holes indicate excessive movement. Check for bending or deformation of the bracket’s main structure.
Listen for new or unusual rattling or clunking sounds from the rear. These sounds may occur when going over bumps or during acceleration. Also, monitor for recurring SCR system fault codes related to sensor signals or dosing. If the SCR box appears misaligned or sagging, inspect the brackets immediately. Addressing these signs promptly prevents more extensive and expensive damage to the emissions system.
The genuine Shacman SCR Box Rear Bracket with part number DZ97259543533 is typically sold as an individual component. This allows for precise replacement of only the damaged or worn part. However, it is always recommended to inspect the corresponding mounting hardware (bolts, nuts, washers) and replace them if corroded or damaged to ensure a secure fit.
It is strongly discouraged. Welding can compromise the heat treatment and material properties of the high-tensile steel. It may also not restore the original structural integrity and dimensional accuracy. A repair weld often becomes a new stress point, leading to a quicker re-failure. For safety, system reliability, and compliance, complete replacement with a new DZ97259543533 is the only recommended solution.
A visual inspection should be conducted during every major service interval, such as oil changes or brake inspections. For trucks operating in particularly corrosive environments (e.g., coastal areas, winter roads with heavy salt use), more frequent checks are advisable. Any time the truck undergoes work on the exhaust or after-treatment system, take the opportunity to examine the bracket’s condition thoroughly.
The OEM number DZ97259543533 is specifically assigned for use on the Shacman X5000 truck platform. Using it on other models (like F3000 or M3000) is not guaranteed and likely will not fit due to differences in chassis design and SCR system layout. Always verify the exact part number against your truck’s model, VIN, and original parts catalog to ensure correct compatibility.
The SCR Box Rear Bracket DZ97259543533 is a fundamental component for the Shacman X5000. It is far more than a simple piece of metal. It is a precision-engineered safety and compliance device. Its role in securing the emissions control system is indispensable. Choosing the genuine Shacman part ensures perfect fitment, maximum durability, and long-term reliability.
By prioritizing this OEM component, you protect your valuable SCR system investment. You minimize the risk of unexpected breakdowns and costly emissions-related repairs. You contribute to keeping your truck on the road, productive, and within environmental regulations. For your Shacman X5000, insist on the bracket designed for it: DZ97259543533.
