OEM Urea Tank Module Harness (Wp/2.2 Pump/36L) DZ97189774065 precision‑assembled for the Shacman X5000 SCR system. This dedicated DZ97189774065 wiring assembly connects the tank sensor, pump, and heating elements to the engine control module for integrated emissions management.
Constructed with high‑temperature resistant wiring and sealed connectors, the Urea Tank Module Harness (Wp/2.2 Pump/36L) DZ97189774065 ensures reliable electrical communication in the demanding under‑chassis environment.
Replacing a damaged or corroded harness with the genuine DZ97189774065 component restores proper SCR system function and eliminates the intermittent faults caused by degraded wiring connections.
| Parameter | Specification |
|---|---|
| OEM Part Number | DZ97189774065 |
| Product Name | Urea Tank Module Harness (Wp/2.2 Pump/36L) |
| Brand / Model | Shacman X5000 |
| Wire Gauge Range | 0.5 mm² to 2.5 mm² conductors |
| Insulation Material | Cross‑linked Polyethylene with PVC Over‑jacket |
| Connector Types | Sealed 4‑pin, 6‑pin, and 8‑pin Deutsch‑style |
| Compatible Components | WP 2.2 pump, 36L tank sensor, heating elements |
| Operating Temperature | -40°C to +125°C |
| Harness Length | Approximately 1200.00 mm main trunk |
| Application | Shacman X5000 SCR urea tank and pump electrical system |
The DZ97189774065 urea tank module harness is the electrical backbone of the Shacman X5000 SCR system. It carries power and data signals between the engine control module and all the components mounted on or near the urea tank.
This harness connects the integrated tank sensor for quality, level, and temperature monitoring, the WP 2.2 dosing pump for precise DEF delivery, and the heating elements that prevent fluid freezing in cold weather conditions.
A single broken wire or corroded connector in the Urea Tank Module Harness (Wp/2.2 Pump/36L) DZ97189774065 can disable the entire SCR system, triggering diagnostic trouble codes and potentially initiating an engine derate sequence.
The DZ97189774065 harness features cross‑linked polyethylene primary insulation that withstands continuous exposure to temperatures up to 125 degrees Celsius without melting or cracking in the under‑chassis environment.
A durable PVC over‑jacket provides additional protection against abrasion, road spray, and chemical exposure. The jacket is formulated to resist the corrosive effects of diesel exhaust fluid that may contact the harness exterior.
Installing the DZ97189774065 harness requires routing it along the factory‑specified path and securing it with the appropriate clips to prevent sagging or contact with hot exhaust components or moving suspension parts.
Each connector must be fully seated until the locking tab engages with an audible click. After installation, a gentle pull test on each connection confirms proper engagement before the system is powered and tested.
Every DZ97189774065 harness undergoes a 100 percent continuity test that verifies each conductor path from end to end. Resistance values are checked against specification limits for each wire gauge and length.
High‑potential testing applies voltage between adjacent circuits to confirm insulation integrity. This test detects microscopic defects that could cause cross‑talk or short circuits after the harness enters service.
Intermittent SCR system faults that appear and disappear with vehicle movement or weather changes often indicate a wiring harness problem. The DZ97189774065 harness should be inspected for chafing, pinched sections, or loose connectors.
Green corrosion visible at connector terminals indicates moisture ingress past damaged seals. Corroded terminals create high‑resistance connections that generate heat and cause intermittent signal loss to critical SCR components.
When replacing SCR system components, the harness connectors should be carefully inspected. If multiple terminals show signs of fretting or corrosion, the entire Urea Tank Module Harness (Wp/2.2 Pump/36L) DZ97189774065 should be replaced.
The DZ97189774065 harness is specifically configured for the WP 2.2 pump and 36‑liter tank configuration used on the Shacman X5000 platform. Connector pin assignments and wire lengths match this exact system layout.
Fleet operators should maintain spare harness assemblies for rapid replacement when electrical faults are diagnosed. Timely harness replacement prevents the extended downtime associated with intermittent SCR system malfunctions.
Aftermarket harnesses with incorrect wire gauges or inferior connector seals can cause persistent SCR faults. We supply only the authentic Shacman X5000 Urea Tank Module Harness (Wp/2.2 Pump/36L) DZ97189774065.
Each harness is factory‑tested and packaged in a protective sleeve that prevents connector damage during transit. The part number DZ97189774065 is clearly printed on the harness label and packaging.
Our international logistics network ensures that genuine DZ97189774065 module harnesses are available for immediate dispatch to dealerships and fleet maintenance facilities across all major continents.
Complete urea tank module wiring harness with all connectors and protective conduit. Factory‑tested and ready for plug‑and‑play installation.
Expert guidance on harness routing and connector installation. We help ensure your DZ97189774065 harness provides reliable SCR electrical system performance.
For current stock availability and pricing on the genuine Urea Tank Module Harness (Wp/2.2 Pump/36L) DZ97189774065, please use the contact buttons above.
