Shacman X5000 Clamp Assembly is the original equipment securing solution for hoses, lines, and wiring on X5000 trucks. This complete assembly includes the Circular Tube (DZ14251230067) and two Face Projection Welding Bolts (Q1980625). The Shacman X5000 Clamp Assembly ensures robust, vibration‑resistant clamping of critical fluid and air lines, preventing leaks and chafing. Engineered from high‑strength steel with precision fabrication, this clamp withstands heavy daily use and harsh environmental conditions. Every component is manufactured to Shacman’s strict OEM tolerances for perfect fit and long‑term reliability. Replace damaged or corroded clamps with this genuine assembly to restore line security and system integrity.
Restore reliable line securement with this genuine clamp kit. Ideal for engine bay, chassis, and cooling system repairs.
Stamped steel circular tube clamp designed for secure line retention. Powder coated black for corrosion resistance. Inner diameter 22.5mm, wall thickness 2mm, pre‑drilled weld hole. Provides a stable base for the welding bolt. Direct OEM replacement.
Face projection welding bolts (2 pcs), M6 thread, zinc plated. Raised projections on the welding face ensure fast, reliable resistance welding to the circular tube. Provide strong, permanent threaded studs for nut attachment. Prevent spinning during installation. Corrosion‑resistant for long service life.
| Part Number | Part Name |
|---|---|
| DZ14251230067 | Circular Tube |
| Q1980625 | Face Projection Welding Bolt |
Vibration‑proof securement – The Shacman X5000 Clamp Assembly holds hoses and lines firmly in place. Eliminates chafing and ensures leak‑free operation.
Rattle‑free design – Precision‑formed circular tube with dual weld studs prevents loosening. No squeaks or rattles during driving.
Corrosion protected – Tube powder coated, bolts zinc plated. Passes 500h salt spray test. Resists road salt, moisture, and mud.
Direct bolt‑on fit – Pre‑welded assembly aligns with factory chassis holes. No modifications. Includes all necessary hardware.
Easy installation – The circular tube comes with pre‑welded bolts. Simply position line and secure using a nut. Torque to 12 Nm. Install in under 10 minutes.
Long service life – Rated for 1 million vibration cycles. Welded bolts tested to 500,000 cycles. Clamp lasts vehicle lifetime. No serviceable parts.
Global availability – Part numbers DZ14251230067 and Q1980625 stocked regionally. Fast shipping for urgent repairs.
Durability validated – 500,000 vibration cycles, 200h vibration test (ISO 16750-3), 500h salt spray. No weld cracks or nut loosening. OEM certified.
Dimensions – Circular tube inner diameter: 22.5mm, width 28mm, weight 0.08kg. Welding bolt M6x16mm. Total assembly weight 0.12kg.
Sustainability – Steel components fully recyclable. Powder coating VOC‑free. Packaging uses recycled cardboard.
Shacman X5000 Clamp Assembly is the only genuine OE clamp for line securement. Order part numbers DZ14251230067 and Q1980625. The Shacman X5000 Clamp Assembly restores rigid, rattle‑free line mounting. Trust Shacman original parts for unmatched reliability and perfect fit.
Each Shacman X5000 Clamp Assembly kit includes one circular tube and two face projection welding bolts. Available now through authorized Shacman dealers. Upgrade your line securement with genuine quality.
Compatibility: Specifically designed for Shacman X5000 radiator hoses, heater hoses, fuel lines, and wiring harnesses. Direct replacement for original clamp assembly. Verify line diameter before ordering.
Ordering information: Minimum order 1 kit. Bulk discounts for 10+ kits. Contact your local Shacman parts distributor for fleet pricing.
Service life: Clamp lasts vehicle lifetime. Welding bolts are permanent and non‑serviceable. Replace clamp if threads stripped.
Packaging: Circular tube wrapped in foam, bolts sealed in labeled poly bag, all in reinforced carton. Includes full color installation diagram with torque specifications.
Authenticity: Look for holographic Shacman genuine label. Counterfeit clamps may use inferior steel or poor welds. Always buy from certified sources.
Customer support: Technical drawings and weld data available. Genuine Shacman X5000 Clamp Assembly comes with 24‑month unlimited‑mileage warranty.
