The Shacman H3000 Assembly Parts collection comprises a comprehensive set of high-quality fastening, structural, and decorative components specifically engineered for the Shacman H3000 heavy-duty truck series. This catalog covers essential assembly elements ranging from Reed Nuts/ST4.8-5-MAN183-B1 and Blanking Cap to Front Crossbeam Assembly, Left Outer Decorative Strip Assembly, Right Outer Decorative Strip Assembly, Cross Recessed Countersunk Head Screw, and 2 Type A11 Metal Hexagonal Lock Nut**. Every part is manufactured to exacting tolerances, ensuring seamless integration, robust mechanical performance, and extended service life in the most demanding operational environments.
This guide provides a detailed overview of each Shacman H3000 Assembly Parts component, helping fleet managers, maintenance technicians, and parts specialists make informed procurement decisions. From structural crossbeams that provide chassis rigidity to decorative strips that enhance exterior aesthetics and reed nuts that offer reliable thread locking, our assembly parts are designed to uphold the renowned durability and reliability of the Shacman brand. With exact fitment and OEM-grade quality, these components ensure that every assembly operation on your H3000 is completed with precision and confidence.
These reed nuts are self-locking fasteners designed for secure and vibration-resistant connections. The ST4.8-5-MAN183-B1 variant offers excellent thread engagement and is ideal for use in high-stress chassis and body applications.
The blanking cap seals unused mounting holes and openings, preventing dirt, moisture, and debris from entering sensitive areas. It ensures a clean, professional finish while protecting against corrosion and contamination.
The front crossbeam assembly is a critical structural component that reinforces the vehicle’s frontal framework. It distributes loads evenly, enhances torsional rigidity, and provides a solid mounting base for various front-end attachments.
This decorative strip assembly enhances the exterior styling of the left side of the vehicle. It is manufactured from durable materials that resist fading and impact, while its precise fit ensures a seamless appearance alongside body panels.
The right outer decorative strip assembly mirrors the left side, delivering symmetrical styling enhancements. It provides protection against minor abrasions while contributing to the overall aerodynamic and visual appeal of the H3000.
These countersunk head screws feature a cross recess drive for easy installation with standard screwdrivers. They provide a flush surface finish when fully seated, making them ideal for trim and panel fastening without protruding heads.
This all-metal lock nut offers superior resistance to loosening under severe vibration and dynamic loads. Its hexagonal design facilitates torque application, and the locking feature ensures permanent joint integrity without the need for adhesives.
This variant of reed nuts features a slightly different thread specification (ST4.8.5) for compatibility with specific Shacman H3000 sub-assemblies. It retains the same robust self-locking design, offering consistent clamping force and resistance to back-off even under extreme vibration.
Often used as a protective or mesh-type screen, this component features a countersunk head with cross recess for flush mounting. It provides a protective barrier while maintaining a sleek appearance, and its design allows for easy removal and replacement during maintenance.
| Part Number | Part Name |
|---|---|
| 06.13189.0108 | Reed Nuts/ST4.8-5-MAN183-B1 |
| 06.13189.0108 | Reed Nuts/ST4.8.5-MAN183-B1 |
| DZ15221970014 | Blanking Cap |
| DZ15221970116 | Front Crossbeam Assembly |
| DZ15221970023 | Left Outer Decorative Strip Assembly |
| DZ15221970024 | Right Outer Decorative Strip Assembly |
| Q2714816F60 | Cross Recessed Countersunk Head Screw |
| Q2714816F60 | Cross Recessed Countersunk Head Screen |
| Q33214T13F3 | 2 Type A11 Metal Hexagonal Lock Nut** |
Our Shacman H3000 Assembly Parts are engineered to meet or exceed original equipment specifications, ensuring a perfect fit and flawless function. Every component undergoes rigorous quality control, including dimensional verification and material testing, to guarantee reliability in the most demanding trucking applications.
With a comprehensive inventory covering every Shacman H3000 Assembly Parts category – from fasteners and structural beams to decorative trims – we simplify your supply chain. Our one-stop solution reduces procurement lead times and eliminates the hassle of sourcing from multiple suppliers.
Durability is at the core of every Shacman H3000 Assembly Parts product. Our components are built with corrosion-resistant coatings, high-strength alloys, and precision threads to withstand extreme temperatures, road salts, and mechanical stress, giving you peace of mind and lower total cost of ownership.
We understand the importance of uptime. Our logistics network ensures fast delivery of Shacman H3000 Assembly Parts worldwide, supported by technical documentation and installation guidance. Choose our parts for dependable performance, expert support, and a commitment to keeping your fleet moving efficiently.
The Shacman H3000 Assembly Parts range is designed for straightforward installation, with each component featuring clear identification markings and standardized dimensions. The reed nuts, for instance, are color-coded for quick size recognition, while the crossbeam assembly comes pre-drilled for common mounting configurations, reducing workshop time.
For maintenance professionals, having access to genuine Shacman H3000 Assembly Parts is essential for preserving vehicle warranty and resale value. Our parts are produced using the same tooling and materials as the original equipment, ensuring that every replacement matches the performance of the factory-installed components perfectly.
The decorative strip assemblies (left and right) are not only aesthetic enhancements but also provide aerodynamic benefits by smoothing airflow along the vehicle sides. They are manufactured from UV-stabilized materials to resist fading and cracking, ensuring that your H3000 maintains a professional appearance over years of service.
When selecting Shacman H3000 Assembly Parts for your repair or restoration project, it is important to choose the correct variant – for instance, the two reed nut versions differ slightly in thread pitch to accommodate different substrate thicknesses. Our technical datasheets provide detailed specifications to help you make the right choice.
The front crossbeam assembly is a safety-critical part that must withstand dynamic bending and torsion forces. Our crossbeams are manufactured from high-strength low-alloy steel, with precise welding and heat treatment to ensure structural integrity. They are 100% inspected for dimensional accuracy before leaving our facility.
For bulk purchasers and fleet operators, we offer competitive pricing on Shacman H3000 Assembly Parts without compromising on quality. Our supply chain is optimized to maintain consistent stock levels, ensuring that even large orders are fulfilled promptly, minimizing downtime across your entire fleet.
The cross recessed countersunk head screws and screen variants are often used in interior trim and protective covers. Their flush-mount design prevents snagging and provides a clean, professional finish. The screws are treated with a corrosion-resistant coating, making them suitable for both exterior and interior applications.
We continuously update our Shacman H3000 Assembly Parts catalog to reflect the latest model changes and engineering improvements. This commitment to currency ensures that you always receive parts that are compatible with your specific vehicle configuration, whether it’s a current production model or an earlier version.
Trust Shacman H3000 Assembly Parts for every fastening, structural, and finishing need on your heavy-duty truck. From Reed Nuts to the Front Crossbeam Assembly and decorative strips, our components deliver the durability, precision, and reliability that Shacman vehicles are known for. Equip your H3000 with the best – choose our genuine assembly parts.
