The Shacman X6000 Bumper System is a comprehensive assembly designed to provide exceptional protection and functionality for your vehicle. Crafted with precision and durability in mind, this system features a variety of components that work together to enhance both safety and aesthetics.
| NO | Part.No | Name | Quantity | Suited type |
| 1 | Q2140820F60 | Screw | 6 | |
| 2 | Q401B08 | Washer | 6 | |
| 3 | DZ9X259620027 | Antiskid plate | 1 | X Platform |
| NO | Part.No | Name | Quantity | Suited type |
| 1 | Q2214816 | Grooved oval head screw | 12 | |
| 2 | DZ9X259620079 | Spring nut | 12 | |
| 3 | DZ9X259620023 | Step plan-L | 1 | X Platform |
| 4 | DZ9X259620024 | Step plan-R | 1 | X Platform |
| NO | Part.No | Name | Quantity | Suited type |
| 1 | Q2214816 | Grooved oval head screw | 16 | |
| 2 | DZ9X259620079 | Spring nut | 12 | |
| 3 | DZ9X259620015 | Headlamp out plan-L | 1 | X Platform |
| 4 | DZ9X259620017 | Headlamp inside plan-L | 1 | X Platform |
| 5 | DZ9X259620018 | Headlamp out plan-R | 1 | X Platform |
| 6 | DZ9X259620016 | Headlamp inside plan-R | 1 | X Platform |
| NO | Part.No | Name | Quantity | Suited type |
| 1 | DZ9X259620019 | Bumper up grill chroming strip | 1 | |
| 2 | DZ9X259620022 | Bumper up middle plan | 1 | |
| 3 | DZ9X259620021 | Bumper down grill chroming strip | 1 | |
| 4 | DZ9X259620071 | Bumper lift cover | 1 | |
| 5 | DZ9X259620072 | Bumper right cover | 1 | |
| 6 | DZ9X259620073 | Bumper lift fixed cover | 1 | |
| 7 | DZ16251870083 | Spring nut | 4 | |
| 8 | DZ9X259620074 | Bumper lift fixed cover | 1 | |
| NO | Part.No | Name | Quantity | Suited type |
| 1 | DZ9X259620092 | Bracket right assembly | 1 | |
| 2 | Q1811445TF3 | Screw | 4 | |
| 3 | 06.11251.2005 | Hexagon nut | 4 | |
| 4 | DZ9X259620091 | Bracket left assembly | 1 | |
| 5 | Q1811240TF3 | Screw | 4 | |
| NO | Part.No | Name | Quantity | Suited type |
| 1 | Q2214816 | Grooved oval head screw | 15 | |
| 2 | Q150B0820T1F3 | Screw | 6 | |
| 3 | Q401B08 | Washer | 6 | |
| 4 | Q2214816 | Grooved oval head screw | 6 | |
| 5 | DZ9X259620079 | Spring nut | 21 | |
| 6 | DZ9X259620026 | Bumper down grill | 1 | |
| NO | Part.No | Name | Quantity | Suited type |
| 1 | DZ9X259620014 | Bumper down plan | 1 | |
| 2 | DZ9X259620013 | Bumper right plan | 1 | |
| 3 | DZ9X259620025 | Bumper up grill | 1 | |
| 4 | DZ9X259620028 | Bumper up web | 1 | |
| 5 | Q401B08 | Washer | 13 | |
| 6 | Q150B0820T1F3 | Screw | 13 | |
| 7 | DZ9X259620012 | Bumper lift plan | 1 | |
| 8 | DZ9X259620011 | Bumper down plan | 1 | |
| 9 | Q2140616F60 | Screw | 2 | |
| NO | Part.No | Name | Quantity | Suited type |
| 1 | Q401B08 | Washer | 18 | |
| 2 | Q150B0830T1F3 | Screw | 16 | |
| 3 | Q150B0820T1F3 | Screw | 2 | |
| NO | Part.No | Name | Quantity | Suited type |
| 1 | Q150B0625TF3 | Screw | 12 | |
| 2 | Q401B06 | Washer | 12 | |
| 3 | DZ9X259620032 | Bumper bracket right | 1 | |
| 4 | DZ9X259620084 | Bumper bracket right Ⅰ | 1 | |
| 5 | DZ9X259620036 | Bumper up bracket | 1 | |
| 6 | DZ9X259620085 | Bumper bracket right Ⅱ | 1 | |
| 7 | DZ9X259620031 | Bumper bracket right | 1 | |
| 8 | DZ9X259620083 | Bumper bracket lift Ⅰ | 1 | |
| 9 | DZ9X259620063 | Positioning pin | 2 | |
| 10 | Q401B08 | Washer | 6 | |
| 11 | Q150B0830T1F3 | Screw | 2 | |
| 12 | DZ9X259620041 | Lift step | 1 | |
| 13 | DZ9X259620053 | Lift step bracket | 1 | |
| 14 | Q150B0820T1F3 | Screw | 4 | |
| 15 | DZ9X259620054 | Right step bracket | 1 | |
| 16 | DZ9X259620042 | Right step | 1 | |
| 17 | DZ9X259620086 | Bumper bracket lift Ⅱ | 1 | |
| NO | Part.No | Name | Quantity | Suited type |
| 1 | DZ9X259620034 | Bumper right bracket for headlamp | 1 | |
| 2 | DZ9X259620064 | Spin axle | 2 | |
| 3 | Q150B0830T1F3 | Screw | 4 | |
| 4 | Q401B08 | Washer | 4 | |
| 5 | DZ9X259620065 | Bumper down bracket | 1 | |
| 6 | DZ9X259620037 | Bumper block | 4 | |
| 7 | DZ9X259620033 | Bumperlift bracket for headlamp | 1 |
