The OEM Ball Pipe Connector 1004164267 is a precision-engineered articulated fluid coupling manufactured exclusively for the Shacman X5000 heavy-duty truck platform. This critical component provides a flexible, leak-free connection between rigid fluid lines and system components, accommodating angular misalignment, thermal expansion, and vibration-induced movement while maintaining absolute sealing integrity in engine oil, fuel, coolant, and air systems under all operating conditions.
Constructed from high-grade steel or brass with a precision-ground spherical ball end and a matched conical seat, the ball pipe connector delivers exceptional durability, corrosion resistance, and reliable sealing performance across thousands of thermal cycles. The 1004164267 part features accurately machined threads and a hex body that facilitates secure tightening to the specified torque, ensuring a permanent, vibration-resistant connection that will not loosen or leak over time.
Installing genuine OEM ball pipe connectors preserves the designed fluid system integrity and prevents the leaks that can cause component damage, system performance loss, and environmental contamination. The 1004164267 identifier provides complete traceability to Shacman’s rigorous material specifications and precision manufacturing quality assurance standards for critical fluid connection components.
| Parameter | Specification | Details |
|---|---|---|
| OEM Part Number | 1004164267 | Unique Shacman X5000 identifier |
| Product Name | Ball Pipe Connector | Articulated fluid line coupling |
| Brand / Vehicle Model | Shacman X5000 | Heavy-duty truck series |
| Body Material | High-grade steel or brass | Excellent strength and corrosion resistance |
| Sealing Interface | Precision-ground spherical ball and conical seat | Metal-to-metal leak-free articulation |
| Thread Type | Precision-rolled or cut threads | Secure and vibration-resistant fastening |
| Wrenching Feature | Hex body for precise torque application | Facilitates correct installation torque |
| Angular Accommodation | Designed for minor misalignment | Compensates for thermal expansion and vibration |
| Application | Engine oil, fuel, coolant, and air systems | Connects rigid pipes to system components |
| Packaging | Protective sealed packaging | Shacman genuine labeled packaging |
The spherical ball end articulates within the conical seat, allowing the rigid pipe to be connected even when perfect axial alignment between the pipe and the mating component cannot be achieved due to manufacturing tolerances or assembly constraints.
The 1004164267 connector accommodates the small movements caused by the differential thermal expansion between connected components, preventing the stress buildup that would otherwise crack rigid pipes or cause fitting loosening over time.
The ball joint interface decouples the rigid pipe from engine and chassis vibrations, preventing the high-cycle fatigue cracking that can occur at rigid pipe connections in the harsh under-hood and under-chassis environments of heavy-duty trucks.
The ball pipe connector 1004164267 is installed at the junction between a rigid fluid pipe and its mating component on the Shacman X5000 vehicle. Before installation, both the spherical ball surface and the conical seat in the mating component must be meticulously cleaned and inspected for any damage, pitting, or debris that could prevent a proper seal. The connector is threaded into the mating component by hand to avoid cross-threading, then tightened to the exact torque specification using a calibrated torque wrench on the hex body. The rigid pipe is then attached to the other end of the connector using the specified fitting type. The spherical interface must be free to articulate slightly as the pipe is positioned and secured. After the system is filled and pressurized, the connection must be visually inspected for any signs of fluid leakage before the vehicle is returned to service. The ball joint does not require any sealant or thread tape; the metal-to-metal contact between the precision-ground surfaces creates the seal when torqued correctly.
Each ball pipe connector produced under OEM number 1004164267 is manufactured from high-grade steel or brass bar stock selected for its strength, machinability, and corrosion resistance. The body is precision-turned on CNC lathes to achieve the exact hex geometry, thread dimensions, and internal passages specified by Shacman engineering. The spherical ball end is formed with extreme precision and then ground and polished to achieve the exact spherical radius and an exceptionally smooth surface finish that is critical for creating a reliable metal-to-metal seal.
The threads are produced using precision rolling or cutting processes that ensure correct pitch, form, and fit with the mating component. After machining, the connector undergoes a thorough cleaning process to remove all machining fluids and debris. Each production batch is subjected to dimensional inspection, including thread gauge verification, ball end radius measurement, and surface finish analysis. Sample connectors are tested for leakage under pressure when assembled to a reference seat at the specified torque. The completed connectors are preserved with a light rust-preventive coating and individually packaged in sealed protective bags placed inside Shacman branded boxes displaying the 1004164267 part number.
Ball pipe connectors should be visually inspected during routine vehicle service for any signs of fluid seepage, staining, or wetness around the connection point. Any indication of a leak must be investigated immediately. The connector body should be checked for any signs of physical damage, corrosion, or cracking. The hex body should be examined for evidence of rounding from improper wrench use, which could prevent correct torque application during future service.
If a ball pipe connector is removed for any reason, it is generally recommended to replace it with a new 1004164267 component. The spherical ball surface and the mating seat conform to each other microscopically during the initial torqueing, creating a matched sealing pair. Reusing a connector may result in an unreliable seal because the previously deformed surfaces may not align perfectly on reassembly. The cost of a new connector is minimal compared to the potential damage and downtime caused by a fluid leak from a reused fitting.
Procuring the authentic ball pipe connector for your Shacman X5000 fluid system service is a simple process that ensures reliable sealing performance. Use the inquiry button above to verify current stock availability and request a prompt quotation. We maintain comprehensive inventory of these essential fluid coupling components to support both individual system repairs and complete fleet maintenance programs across all international markets.
To ensure you receive the exact factory-specified connector with correct thread size, ball end radius, and material for your application, always reference the OEM part number 1004164267 in your purchase order. Our logistics team provides complete export documentation with every international shipment for efficient customs clearance and inventory verification at your facility.
Global Stock Available
Immediate dispatch for Shacman X5000 fluid system service worldwide.
Choosing the genuine Ball Pipe Connector 1004164267 is a decision that directly impacts the sealed integrity and long-term reliability of your Shacman X5000 vehicle’s critical fluid systems. Aftermarket connectors that are manufactured from inferior materials or with imprecise ball end geometry can leak under pressure, allowing the escape of hot engine oil, fuel, or coolant. A fuel leak presents an immediate fire hazard, an oil leak can cause engine damage from lubrication loss, and a coolant leak can lead to engine overheating and catastrophic head gasket failure.
The OEM connector’s specific material, ball end radius, and thread specifications were validated through extensive pressure pulsation, thermal cycling, and vibration testing on Shacman’s component test stands. Engineers specified this exact connector design to provide the optimal balance of articulation freedom, sealing reliability, and structural strength required for its specific application on the X5000 vehicle. The 1004164267 connector delivers the dependable, leak-free fluid connection that professional fleet operators require to keep their vehicles on the road generating revenue.
Professional fleet technicians and maintenance managers worldwide standardize on the 1004164267 ball pipe connector for its guaranteed material quality, precise fit, and proven sealing reliability in the field. This precision coupling performs the vital function of keeping critical fluids contained within their systems, protecting both the environment and the vehicle’s mechanical integrity. Trust only the ball pipe connector that Shacman engineered and certified for the demanding X5000 heavy truck platform.
The ball pipe connector 1004164267 functions on the principle of spherical metal-to-metal sealing. When the connector is torqued into its mating seat, the precision-ground spherical surface contacts the conical seat along a continuous circular line. As torque is increased, the contact pressure along this line exceeds the yield strength of the softer material, causing a controlled microscopic deformation that creates a continuous, impermeable seal. This sealing mechanism is highly reliable and requires no additional sealants, gaskets, or O-rings that could degrade over time.
The hex body of the connector is designed to accept a standard open-end or flare-nut wrench. Using the correct wrench size and a calibrated torque wrench is essential for achieving the designed seal without damaging the hex or over-torquing the fitting. An adjustable wrench or pliers should never be used on these precision fittings, as they will round the hex corners and make it impossible to achieve or maintain the correct torque during future service operations.
For our international customers, we take exceptional care in packaging the 1004164267 ball pipe connectors to prevent any thread damage, corrosion, or surface contamination during global transit and extended warehouse storage. Each connector is individually sealed in a VCI protective bag and packed in compartmented cartons that prevent any contact between parts during shipping. Partner with our global supply network for a reliable source of genuine Shacman fluid system components, and keep your fleet’s critical fluid systems sealed, protected, and operating reliably for the long haul.
