Precision engineered for SHACMAN X5000 series, the Shacman X5000 Three Layers Of Controller Mounting Brackets kit delivers unmatched stability and modular assembly. Designed for heavy-duty commercial vehicles, this reinforced mounting system guarantees long-term reliability in extreme conditions.
This multilayer mounting plate acts as the backbone of the system, providing three-tier support for electronic controllers. Manufactured from high-strength steel with anti-corrosion coating, it isolates vibration and ensures secure placement even under harsh road shocks.
The Left Bracket is precisely formed to integrate with the chassis left rail. Its asymmetric rib structure improves load distribution, enabling perfect alignment with the controller assembly. Strict tolerance control guarantees plug-and-fit installation.
Mirror-engineered Right Bracket complements the left side to form a rigid frame. With reinforced bolt holes and extra gussets, it withstands dynamic torque, keeping the controller stack stable during long-haul operations.
These Welding Square Nuts offer reliable fastening points for the brackets. Pre-positioned and weldable, they enhance assembly precision and reduce installation time. Each nut ensures high clamp load and resistance to loosening.
| Part Number | Part Name |
|---|---|
| DZ97189585629 | Controller Bracket Three-Layer Mounting Plate |
| DZ97189585615 | Left Bracket |
| DZ97189585614 | Right Bracket |
| Q37106 | Welding Square Nut |
OEM-grade durability – Every bracket is forged from high-tensile steel and zinc-plated to resist rust, salt, and extreme temperature. Perfect for long-haul fleets and off-road conditions.
Triple-layer stability – The three-layer mounting plate design eliminates controller sway, reduces fatigue on electronic units, and provides extra fixing points for aftermarket accessories.
Direct replacement fitment – No drilling or modification required. 100% compatible with Shacman X5000 chassis, saving workshop time and ensuring hassle-free upgrade for your truck.
Cost-effective reliability – Rigorously tested under vibration and load cycles. Extend controller lifespan and lower downtime risk, backed by industry leading logistics support.
The Shacman X5000 Three Layers Of Controller Mounting Brackets system adopts finite element analysis to optimize stress distribution. Every component is CAD validated to avoid resonance.
Each bracket integrates anti-loosening thread inserts and alignment pins. This ensures zero-movement even after 500,000 km of severe road profiles.
Compared to generic brackets, the Shacman X5000 Three Layers Of Controller Mounting Brackets set reduces mounting time by 30% due to pre-welded nut positions.
Advanced robotic welding provides consistent structural rigidity. All edges are deburred for safe handling during maintenance.
Start by removing old brackets and cleaning mounting surfaces. Position the Left Bracket and Right Bracket on respective chassis rails.
Attach the Three-Layer Mounting Plate using supplied hardware and welding square nuts. Torque to 85 Nm for optimal clamp force.
Ensure controller units are seated onto the three-layer platform, then secure with lock washers. Recheck alignment before final tightening.
Professional installation is recommended for heavy fleet use. Always follow torque specifications from Shacman service manual.
Specifically designed for Shacman X5000 truck models including tractor heads, rigid dumpers, and concrete mixers. It also retrofits certain X3000 variants with minor adjustments.
The kit integrates with ECAS, ABS, and EBS controller units. The Shacman X5000 Three Layers Of Controller Mounting Brackets guarantee interference-free harness routing.
Validated for both automatic and manual transmission configurations. Perfect for dealer workshops and DIY experienced mechanics.
Each batch undergoes 240-hour salt spray test (ASTM B117) and dynamic vibration sweep from 10Hz to 500Hz. No cracks or fasteners loosening observed.
Temperature cycling from -40°C to +85°C ensures reliable performance in arctic or desert environments. The Shacman X5000 Three Layers Of Controller Mounting Brackets exceed OE requirements.
Impact resistance validated via pendulum test, guaranteeing structural integrity in emergency braking or collision events.
Minimizes electronic controller failure caused by excessive vibration. Enhanced grounding path reduces EMC interference for sensitive modules.
Modular design allows future addition of telematics devices or extra sensors. The Shacman X5000 Three Layers Of Controller Mounting Brackets kit supports scalability.
Reduces cabin noise transmission because of dampening elastomer isolators (optional accessory). Fleets report 18% less controller-related issues after upgrading.
Manufactured under IATF 16949 certified facility. Each component traceable via laser marking. Strict ISO 9001:2015 quality management applied.
All parts are 100% inspected with coordinate measuring machine (CMM) ensuring critical dimensions within ±0.2mm tolerance. Shacman genuine logo embossed.
Third-party laboratory reports available upon request. The Shacman X5000 Three Layers Of Controller Mounting Brackets meet strict European ECE R10 electromagnetic compatibility standards.
Global warehouses ensure fast shipment to Europe, Middle East, Africa, and Asia. Standard packaging includes anti-rust paper and bubble wrap.
Each order includes a detailed installation leaflet and torque card. Technical remote assistance available through authorized dealers.
Bulk order discounts apply for fleet owners. All brackets come with 12-month warranty against manufacturing defects.
