Shacman X5000 Sunroof Cover Mounting Bracket Assembly is the essential OEM fastening kit for securing the sunroof cover to the cab roof. This assembly includes one heavy‑duty sunroof cover mounting bracket and one face projection welding bolt. The Shacman X5000 Sunroof Cover Mounting Bracket Assembly ensures a rigid, rattle‑free attachment, maintaining the watertight seal and structural integrity of your flat‑top or high‑channel sunroof. Perfect for replacement during sunroof repair or full cab restoration.
Engineered to original specifications, this bracket assembly guarantees perfect alignment and long‑term clamping force.
L‑shaped steel bracket with ribbed reinforcement. Powder‑coated black for corrosion resistance. Includes a pre‑welded nut and rubber isolator pad. Attaches the sunroof cover to the roof frame. Provides precise height adjustment. Tested for 10,000 vibration cycles without loosening.
Projection weld bolt with M6 thread, zinc‑plated. Designed for permanent attachment to the sunroof cover frame. Provides a strong, aligned stud for the mounting bracket. Resists stripping and corrosion. OEM exact replacement.
| Part Number | Part Name |
|---|---|
| DZ16231420103 | Sunroof Cover Mounting Bracket |
| Q1980616 | Face Projection Welding Bolt |
Rigid clamping force – The bracket’s ribbed design and rubber isolator provide even pressure. Prevents cover rattling. The Shacman X5000 Sunroof Cover Mounting Bracket Assembly holds the seal tight for years.
Precision welding bolt – Face projection bolt ensures exact positioning and permanent attachment. No loose studs. Eliminates stripped threads common with aftermarket hardware.
Corrosion protected – Bracket powder‑coated, bolt zinc‑plated. Passes 500h salt spray. Ideal for harsh environments and road salt exposure.
Direct replacement – Matches original part dimensions. Installs in minutes with basic tools. Restores sunroof security and leak prevention immediately.
Easy alignment – Bracket features slotted holes for ±3mm adjustment. Compensates for minor roof variations. Ensures seal compression uniformity.
Service friendly – Bracket can be removed and reused. Welding bolt is permanently attached to sunroof cover. Replace only the bracket if damaged.
Global availability – Part numbers DZ16231420103 and Q1980616 stocked regionally. Fast shipping for urgent roof repairs.
Durability validated – 50,000km road vibration test, 10,000 open/close cycles. No bracket deformation or bolt loosening. OEM certified for Shacman X5000.
Dimensions – Bracket: 65x40x25mm, weight 120g. Welding bolt: M6x16mm, head diameter 12mm. Rubber isolator thickness 5mm.
Eco-friendly – Bracket steel fully recyclable. Powder coating VOC‑free. Bolt zinc passivation compliant with RoHS.
Shacman X5000 Sunroof Cover Mounting Bracket Assembly is the only genuine fastening solution for your X5000 sunroof. Order part numbers DZ16231420103 (bracket) and Q1980616 (welding bolt). The Shacman X5000 Sunroof Cover Mounting Bracket Assembly ensures a secure, leak‑free, and rattle‑free roof hatch. Trust Shacman original parts for perfect fit and long‑term reliability.
Each Shacman X5000 Sunroof Cover Mounting Bracket Assembly kit includes one bracket and one welding bolt. No additional hardware needed (washer and nut sold separately). Available now through authorized Shacman dealers. Restore your sunroof integrity with genuine quality.
Compatibility: Fits all Shacman X5000 flat‑top and high‑channel cabs with factory sunroof. Direct replacement for original brackets. Confirm welding bolt is pre‑installed on your sunroof cover.
Ordering information: Minimum order quantity 1 set. Bulk discounts for 20+ sets. Contact your local Shacman parts distributor for fleet pricing.
Service life: Bracket lasts vehicle lifetime. Rubber isolator replaceable every 8‑10 years. Welding bolt permanent. Bracket reusable if undamaged.
Packaging: Bracket wrapped in anti‑static foam, bolt in labeled poly bag. Includes torque specification card.
Authenticity: Look for holographic Shacman genuine label. Counterfeit brackets often lack rubber isolator or use weak steel. Always buy from certified sources.
Customer support: Technical drawings and torque data available. Genuine Shacman X5000 Sunroof Cover Mounting Bracket Assembly comes with 24‑month warranty.
