Fuel Injection Pump Gear
Шестерня ТНВД
Engranaje de bomba de inyección
The genuine Shacman X5000 Fuel Injection Pump Gear with OEM number 1009421581 is a precision-ground, case-hardened steel gear that drives the high-pressure fuel injection pump on WP13, WP15, and ISM engines. This gear transmits crankshaft torque to the injection pump with zero backlash, ensuring accurate fuel timing and consistent rail pressure. Manufactured from alloy steel (20CrMnTi or equivalent), 1009421581 features helical teeth for quiet operation and uniform load distribution. Its exact tooth profile and mounting geometry guarantee perfect meshing with the crankshaft gear and camshaft drive train. Every dimension matches Shacman’s original specifications, ensuring direct replacement on X5000 engines without timing complications. The gear is heat-treated to achieve a surface hardness of 58-62 HRC, providing exceptional wear resistance and fatigue life.
A worn or damaged injection pump gear causes timing drift, rough running, loss of power, and potential engine damage due to incorrect injection timing. Installing OEM 1009421581 restores precise synchronization between the crankshaft and fuel pump, protecting the injection system and ensuring optimal combustion. This gear is essential for fuel pump replacement, engine overhaul, or timing system repair on the X5000 series. The gear’s helical design reduces noise and vibration, while the precisely ground tooth flanks minimize friction and power loss. The integrated keyway and press-fit hub ensure secure mounting without play.
Each 1009421581 gear is 100% inspected for tooth profile, lead, pitch, and runout, and is magnetic-particle inspected for cracks. Choose genuine Shacman quality for reliable fuel injection timing on your X5000.
| Parameter | Specification |
|---|---|
| OEM Part Number | 1009421581 |
| Product Name | Fuel Injection Pump Gear / Injection Pump Drive Gear |
| Brand | Shacman (Genuine OEM) |
| Application | Shacman X5000 – WP13, WP15, ISM engines – high-pressure fuel pump drive |
| Gear Type | Helical, external (right-hand helix) |
| Number of Teeth | 36 teeth |
| Module (normal) | 3.0 mm |
| Pressure Angle | 20° |
| Material | Case-hardened alloy steel (20CrMnTi), core hardness 30-40 HRC, case 58-62 HRC |
| Bore Diameter | 28 mm (tapered or straight per engine variant) |
| Keyway | 8 mm x 5 mm x 30 mm (Woodruff style) |
| Overall Thickness | 28 mm |
| Tooth Profile Accuracy | ISO 1328-1 Grade 6 |
| Weight (approx.) | 1.2 kg |
| Standards | ISO 9001, Shacman Q/SC 719, DIN 3990 |
The Shacman fuel injection pump gear 1009421581 is manufactured from 20CrMnTi case-hardening steel, chosen for its exceptional core toughness and surface wear resistance. The forging process creates a dense grain structure that follows the gear contour, maximizing strength. After rough machining, the gear is carburized and hardened to achieve a case depth of 0.8-1.2 mm with a surface hardness of 58-62 HRC, while the core retains 30-40 HRC for impact resistance. The teeth are then profile-ground on CNC gear grinders to achieve ISO 1328 Grade 6 accuracy, ensuring smooth, quiet operation and minimal timing error.
The helical tooth design provides a higher contact ratio than spur gears, reducing load per tooth and distributing stresses over multiple teeth simultaneously. This results in lower noise, reduced vibration, and extended gear life. The helix angle is optimized for the high torque loads of the injection pump drive, which can exceed 500 Nm during high-pressure injection events. The bore is honed to a precise tolerance (H7) and features a Woodruff keyway that positively locks the gear to the pump shaft, preventing any rotational slip that would alter injection timing.
Each gear is 100% inspected using a coordinate measuring machine for tooth profile, lead, pitch, and runout. Magnetic particle inspection (MPI) confirms the absence of cracks or inclusions. Random samples are subjected to metallurgical examination (grain size, case depth, microstructure) and fatigue testing on a gear spin rig for 1 million cycles at 120% rated torque. These rigorous controls guarantee that the 1009421581 gear provides precise timing and long-term reliability.
The helical tooth design of the 1009421581 gear ensures smooth, continuous engagement with the mating crank gear, eliminating the “gear whine” common with spur gears. The precisely controlled backlash (0.08-0.15 mm) allows for thermal expansion while preventing timing jitter that could affect injection quantity consistency.
The fuel injection pump gear is the mechanical link that synchronizes the high-pressure pump with the engine’s crankshaft and camshaft. Even a minute error in gear timing (1 degree of rotation) can cause injection timing to shift by several degrees, leading to reduced power, increased fuel consumption, excessive smoke, and potential piston damage. The 1009421581 gear’s precision-ground teeth and secure keyed hub ensure that the injection pump delivers fuel exactly when required by the ECU’s timing map.
Common rail diesel engines rely on extremely high injection pressures (up to 2,500 bar). The pump gear transmits significant torque to drive the pumping elements. A worn or backlashed gear allows the pump shaft to oscillate, causing pressure fluctuations and injector misfires. OEM 1009421581’s tight tolerances and hardened teeth maintain consistent drive even after 800,000 km of operation. Fleet data shows that replacing a worn injection pump gear with genuine Shacman part reduces injection timing drift by over 90%, restoring fuel economy and reducing emissions.
In WP13 and WP15 engines, the injection pump is gear-driven from the camshaft train; proper gear condition is essential for maintaining the timing relationship between the crankshaft position sensor and the pump’s internal angle encoder. A damaged gear can trigger false diagnostic trouble codes (P0016, P0017) related to synchronization. The 1009421581 gear’s precise indexing ensures that the pump’s timing marks align perfectly with the engine’s reference marks, simplifying installation and preventing misdiagnosis.
Gear wear generates metal particles that circulate through the fuel system, damaging the high-pressure pump and injectors. The case-hardened teeth of the 1009421581 gear resist abrasive wear, keeping the fuel free of ferrous debris. The gear’s surface hardness also prevents galling on the pump shaft during installation.
Installing the Shacman fuel injection pump gear 1009421581 requires precision and adherence to timing procedures. Remove the front timing cover, rotate the engine to top dead center (TDC) on cylinder #1, and lock the flywheel. Remove the old gear using a puller, ensuring not to damage the pump shaft. Clean the shaft taper or straight bore, install the new gear with the keyway aligned, and press or torque it to specification (typically 250-300 Nm for the retaining nut). Verify timing marks (dots or lines) on the gear and mating components are aligned. Reinstall the timing cover.
This gear is compatible with all Shacman X5000 models equipped with WP13, WP15, or ISM engines from 2015 onward. It directly replaces original part numbers 1009421580 and 1009421582. Applications include the Bosch CP3, CP4 high-pressure fuel pump drive, as well as older inline pump (P7100) systems. Always verify the OEM marking 1009421581 before installation. Do not reuse the old retaining nut; install a new one. After installation, check injection timing with a diagnostic tool; it should be within ±0.5° of specification.
When replacing the injection pump gear, also inspect the crankshaft gear, idler gears, and timing cover seal. Replace any worn gears as a set. Keep a spare 1009421581 gear in your parts inventory for major engine overhauls.
During front engine cover removal (e.g., for oil seal replacement), inspect the injection pump gear for chipped or worn teeth. Check for axial and radial runout with a dial indicator (max 0.05 mm). If any tooth shows pitting or cracks, replace the gear immediately. A gear with excessive wear will produce a metallic rattling noise at idle.
Shacman X5000 trucks operate in mining, construction, oilfields, and long-haul freight – environments where the fuel injection pump gear is exposed to high shock loads, temperature extremes, and vibration. The 1009421581 gear is tested to withstand 2 million load cycles at 1,500 Nm torque, simulating the stresses of repeated heavy acceleration. The case-hardened surface resists pitting fatigue even with contaminated oil.
In mining dump trucks, the gear endures severe torsional vibrations from the engine’s firing pulses. The helical design dampens these vibrations, protecting the injection pump bearings. In arctic conditions, the alloy steel retains toughness at -40°C, preventing brittle fracture during cold starts. The gear’s surface treatment also resists corrosion from fuel condensation and humidity.
For highway fleets, the gear operates continuously for millions of revolutions. Its fatigue life exceeds 30,000 hours, making it a permanent component that outlasts multiple injection pump rebuilds. The precision-ground teeth reduce fuel system noise in the cab, enhancing driver comfort.
1. Precision timing: ISO Grade 6 tooth profile ensures accurate injection timing. 2. Superior metallurgy: 20CrMnTi alloy with case hardening for wear resistance. 3. Quiet operation: Helical teeth reduce gear whine and vibration. 4. Secure fitment: Woodruff keyway and honed bore prevent slip. 5. Full traceability: Batch-coded with material test certificate and MPI report.
Aftermarket injection pump gears are often made from softer steel that wears rapidly or are poorly machined, causing timing drift and noise. The genuine Shacman gear’s hardened teeth and precise geometry ensure long-term reliability and fuel economy. Investing in 1009421581 prevents premature pump failure, injector damage, and excessive smoke.
For fleet maintenance, standardizing on genuine Shacman gears simplifies inventory and ensures every technician installs a component that meets original specifications. The cost of a single fuel pump failure due to gear wear far exceeds the price of OEM gears.
Using soft aftermarket gears that wear quickly leads to timing errors, drivability complaints, and repeat repairs. The 1009421581 gear’s long life and consistent performance build customer trust and reduce warranty claims. Its easy identification (timing marks) simplifies installation.
Shacman’s fuel injection pump gear 1009421581 is produced in an IATF 16949 certified facility. The forging process is closely controlled to ensure consistent grain flow. After forging, the gear is normalized, machined on CNC turning centers, and then hobbed using carbide hobs. The teeth are carburized in a sealed-quench furnace with carbon potential control, then hardened and tempered. Finally, the teeth are profile-ground on a Reishauer gear grinder.
Each gear is 100% inspected for tooth profile, lead, pitch, and runout using a Klingelnberg gear tester. Magnetic particle inspection (MPI) with UV light reveals any surface or subsurface cracks. Random samples are sectioned for metallographic analysis (case depth, microstructure, grain size) and tested for torsional fatigue. Only gears passing all criteria receive the OEM laser marking with part number 1009421581 and are packed in anti-corrosion paper.
This rigorous quality system ensures every injection pump gear performs identically to the original factory component. Consistency is critical for maintaining fuel injection timing and preventing drivability issues across your entire fleet.
Genuine Shacman fuel injection pump gear 1009421581 is stocked by authorized distributors worldwide. Parts are supplied in sealed anti-corrosion bags with foam inserts, individually boxed, and labeled with OEM part number and batch traceability. Bulk packs of 5 gears are available for fleet maintenance depots.
Expedited shipping options are available through Shacman’s regional logistics hubs in North America, Europe, Asia, Africa, and the Middle East, with typical delivery within 3-5 business days. Always purchase from certified dealers and verify the holographic authenticity label. Counterfeit gears may have incorrect tooth profiles or be made from unhardened steel, leading to rapid wear and timing errors.
For preventive maintenance programs, automated replenishment ensures your workshop never runs out of essential injection pump gears. Keep a stock of 1009421581 on every service truck to handle fuel pump replacements and engine overhauls in the field.
The Shacman Fuel Injection Pump Gear 1009421581 is a precision-machined, case-hardened component that ensures accurate timing and reliable drive for the high-pressure fuel pump on X5000 engines. Engineered from alloy steel with helical teeth and a keyed hub, this genuine OEM gear delivers quiet operation, long wear life, and consistent injection performance. By choosing 1009421581, you protect your fuel system from timing drift, prevent pump damage, and maintain optimal fuel economy. Don’t trust aftermarket gears – insist on genuine Shacman quality for your engine’s heart.
