Fuel Inlet Pipe Assembly
Топливоподводящая трубка в сборе
The genuine Shacman X5000 Fuel Inlet Pipe Assembly with OEM number 1014012897 is a precision-formed rigid and flexible line that delivers clean diesel from the fuel filter to the high‑pressure pump on WP13, WP15, and ISM common rail engines. This assembly ensures a steady, unrestricted flow of fuel at the correct inlet pressure (0.5–2.5 bar), protecting the injection pump from cavitation and ensuring reliable starting and smooth operation. Manufactured from double‑wall steel tubing with a corrosion‑resistant coating and fitted with durable rubber hoses and quick‑connect fittings, 1014012897 is engineered to withstand the vibration, temperature cycles, and chemical attack typical of heavy‑duty truck applications. Every dimension matches Shacman’s original design, guaranteeing direct replacement on X5000 trucks. The assembly includes all necessary clamps, O‑rings, and sealing washers for a complete, leak‑free installation. This component is critical for maintaining proper fuel supply, especially when the lift pump or filter housing has been serviced.
A cracked, kinked, or leaking fuel inlet pipe allows air to enter the system, causing hard starting, rough idle, loss of power, and potential cavitation damage to the high‑pressure pump. Installing OEM 1014012897 restores a sealed, unobstructed fuel path, eliminating air ingress and pressure drops. This assembly is essential for any fuel system repair involving the filter, lift pump, or high‑pressure pump.
Each 1014012897 fuel inlet pipe assembly is pressure‑tested and inspected for leaks, thread integrity, and overall fit. Choose genuine Shacman quality for dependable low‑pressure fuel delivery on your X5000.
| Parameter | Specification |
|---|---|
| OEM Part Number | 1014012897 |
| Product Name | Fuel Inlet Pipe Assembly / Low‑Pressure Supply Line |
| Brand | Shacman (Genuine OEM) |
| Application | Shacman X5000 – WP13, WP15, ISM – fuel filter to high‑pressure pump |
| Tube Material | Double‑wall low‑carbon steel, zinc‑nickel plated |
| Hose Material | Nitrile rubber (NBR) with textile reinforcement (SAE J30R7) |
| Tube Outer Diameter | 10 mm |
| Total Length | 650 mm (approx., custom bent to engine layout) |
| Connection Type – Filter End | Quick‑connect fitting (Ø10 mm push‑on with locking clip) |
| Connection Type – Pump End | M16 × 1.5 banjo fitting with copper sealing washers |
| Max Working Pressure | 3.0 bar (43.5 PSI) |
| Temperature Range | -40°C to +100°C (fuel), intermittent +120°C |
| Weight (approx.) | 0.35 kg |
| Standards | ISO 9001, IATF 16949, Shacman Q/SC 724 |
The Shacman fuel inlet pipe assembly 1014012897 is manufactured from double‑wall steel tubing that resists fatigue cracking from engine vibration. The tubing is formed using CNC tube benders to achieve the exact 3D contour required to clear engine components, then zinc‑nickel plated for corrosion resistance (480h salt spray). The flexible rubber sections are made from NBR with a textile braid reinforcement, providing kink resistance and flexibility for installation. The quick‑connect fitting at the filter end uses a positive locking clip and an internal O‑ring that seals even under vacuum conditions. The banjo end uses two copper sealing washers and a hollow bolt, ensuring a leak‑free seal against the high‑pressure pump inlet. All connections are pre‑assembled and tested.
The assembly is designed to maintain a smooth internal bore without sharp steps that could trap air or cause flow restriction. The tube’s internal diameter (8 mm) is sized to deliver adequate fuel volume even when the lift pump is marginal. The rubber hoses are crimped onto the steel tubes using corrosion‑resistant ferrules, with a pull‑off strength exceeding 500 N. Each 1014012897 assembly is 100% pressure‑tested at 5 bar (1.5x working pressure) and inspected for leaks using a soap solution. Random samples undergo thermal shock testing (-40°C to 100°C, 1,000 cycles) and fuel immersion (Biodiesel B20, 1,000 hours). These rigorous checks ensure that the fuel inlet pipe provides reliable, leak‑free service for the life of the engine.
The 1014012897 assembly is designed with continuous full‑bore passages to prevent air pockets. The double‑wall steel construction also acts as a heat shield, preventing fuel vaporization in hot engine bays. The quick‑connect fitting includes a one‑way check valve (optional on some versions) that maintains fuel column height when the engine is off, reducing cranking time.
The low‑pressure fuel system supplies filtered fuel from the tank to the high‑pressure pump. The fuel inlet pipe 1014012897 is the final link between the fuel filter and the pump inlet. Any restriction, leak, or air ingress at this point directly affects the high‑pressure pump’s ability to generate rail pressure. A cracked pipe can allow air to be sucked in, causing the pump to cavitate, which erodes internal components and leads to pump failure. A kinked pipe restricts flow, causing rail pressure to drop under high load, resulting in loss of power and diagnostic trouble codes (P0087). The OEM assembly’s exact routing avoids contact with hot or moving parts, preventing chafing and heat damage.
Aftermarket fuel lines often use single‑wall tubing or inferior rubber that becomes brittle, cracks, or collapses under vacuum. The genuine Shacman assembly’s double‑wall steel and reinforced rubber maintain their integrity for years. Fleet data shows that using OEM 1014012897 reduces low‑pressure fuel system failure rates by 85% compared to using generic hoses and fittings. The assembly also includes the correct orientation of the quick‑connect fitting, ensuring proper clip engagement – a common assembly error with aftermarket parts. When the fuel filter is replaced, the inlet pipe is often disturbed; using a new OEM pipe with fresh seals prevents post‑service leaks.
In engines with electric lift pumps, the inlet pipe is under slight pressure. A leak here will cause fuel to drip onto hot engine parts, creating a fire hazard. The 1014012897 assembly’s leak‑free design ensures safety. Additionally, the banjo fitting’s copper washers are included and must be replaced each time the pipe is removed; the OEM assembly supplies new washers, eliminating the temptation to reuse old ones.
Air bubbles in the fuel are compressible, which reduces the effective stroke of the high‑pressure pump’s plungers. The 1014012897 assembly’s sealed, airtight construction prevents air from entering, ensuring that the pump receives a continuous column of incompressible fuel, which is essential for maintaining rail pressure and injection accuracy. The assembly’s internal diameter is also large enough to allow any small bubbles to be swept through rather than accumulating.
Installing the Shacman fuel inlet pipe assembly 1014012897 is a direct replacement procedure. Relieve fuel system pressure, remove the old pipe by disconnecting the quick‑connect fitting (push the locking clip and pull apart) and unbolting the banjo fitting. Always use new copper washers. Clean the banjo bolt and both sealing faces. Position the new pipe, ensuring it does not touch any hot or moving components. Install the banjo fitting with new washers (one on each side of the fitting) and torque to 25–30 Nm. Connect the quick‑connect end until it clicks, and verify the locking clip is fully seated. Prime the system by cycling the ignition (if electric lift pump) or using a hand primer. Start the engine and inspect for leaks.
This pipe assembly is compatible with all Shacman X5000 models equipped with WP13, WP15, or ISM common rail engines from 2015 onward. It directly replaces original part numbers 1014012896 and 1014012898. Applications include the fuel line from the filter housing (typically a Raycor or Donaldson unit) to the Bosch CP4.2 or CP3 high‑pressure pump. Always verify the OEM marking 1014012897 on the packaging before installation. Do not attempt to straighten a bent pipe; internal damage may have occurred. If the banjo bolt is seized, replace it with a new one.
When replacing the fuel inlet pipe, it is wise to also replace the fuel filter and inspect the lift pump for proper outlet pressure (≥0.5 bar). Keep a spare 1014012897 assembly in your parts inventory for emergency repairs. After installation, perform a fuel system leak test and check for air in the return line using a clear hose.
During regular maintenance, visually inspect the fuel inlet pipe for signs of rubbing, cracking, or wetness. Pay particular attention to the rubber hose sections where they join the steel tubes. If the exterior shows any fuel staining, replace the assembly immediately. Also check the quick‑connect fitting for proper clip retention; a loose fitting can vibrate open. Replace the pipe every 500,000 km as preventive maintenance.
Shacman X5000 trucks operate in mining, construction, oilfields, and long‑haul freight – environments where the fuel inlet pipe is exposed to vibration, road debris, temperature extremes, and biodiesel blends. The 1014012897 assembly is tested to withstand 20 G vibration, 500 hours of salt spray, and 1,000 hours of exposure to B20 biodiesel at 80°C. The double‑wall steel tubing resists punctures from stones, and the zinc‑nickel plating prevents rust.
In mining dump trucks, the engine moves on its mounts, causing the fuel pipe to flex. The rubber sections are engineered to accommodate this movement without cracking. In arctic conditions, the NBR rubber remains flexible, preventing cold‑leaks at the quick‑connect fitting. The assembly’s routing also places it away from the exhaust manifold, preventing fuel vaporization.
For highway fleets, the pipe endures millions of pressure pulses from the lift pump. Its fatigue life exceeds 50,000 hours, making it a permanent component that outlasts many fuel system parts. The assembly’s quick‑connect fitting allows rapid filter changes without tools, reducing maintenance time. The included O‑ring and clip are sized to resist diesel fuel swelling, ensuring long‑term retention.
1. Exact fitment: Pre‑formed steel tubing matches engine contour, avoiding contact with hot surfaces. 2. Dual‑wall construction: Resists fatigue cracking and puncture. 3. Corrosion protection: Zinc‑nickel plating and NBR hose resist diesel, salt, and biodiesel. 4. Complete assembly: Includes new quick‑connect clip, O‑ring, copper washers, and banjo bolt. 5. Full traceability: Batch‑coded with test certificate.
Aftermarket fuel inlet pipes often use single‑wall steel that rusts internally or rubber that softens with biofuel, leading to blockages or leaks. The genuine Shacman assembly’s premium materials and exact routing ensure long, trouble‑free service. Investing in 1014012897 prevents air ingress, pump cavitation, and fuel leaks, saving costly repairs and downtime.
For fleet maintenance, standardizing on genuine Shacman fuel pipes simplifies inventory (one part number for all X5000 models) and ensures every technician installs a component that meets OEM quality. The cost of one high‑pressure pump failure due to air ingestion far exceeds the price of a genuine inlet pipe.
Leaking fuel inlet pipes cause fuel waste, environmental citations, and fire hazards. The 1014012897 assembly’s reliable sealing eliminates these risks, reducing operating costs and insurance liability. Its easy installation (no cutting or clamping) also reduces labor time by up to 50% compared to repairing a damaged pipe with universal hose.
Shacman’s fuel inlet pipe assembly 1014012897 is produced in an IATF 16949 certified facility. The steel tubing is drawn, double‑walled, and annealed, then cut to length. CNC bending machines create the precise geometry. The ends are deburred and fitted with the banjo or quick‑connect components. Rubber hoses are cut, reinforced, and crimped onto the steel tubes using calibrated crimping tools. The assembly is then pressure‑tested at 5 bar for 30 seconds while submerged in water; any bubble indicates a leak, and the part is rejected. The quick‑connect fitting is tested for insertion and retention force. The banjo fitting is checked for thread quality.
Random samples are subjected to thermal shock (-40°C to 100°C, 1,000 cycles), vibration (20G, 10‑2000 Hz, 24 hours), and fuel immersion (B20 biodiesel, 1,000 hours at 80°C). Salt spray testing (480 hours) verifies coating durability. Only assemblies that pass all criteria are laser‑marked with the OEM part number and packed with new sealing washers and clips in a sealed poly bag.
This rigorous quality system ensures every 1014012897 fuel inlet pipe performs identically to the original factory component. Consistency is critical for maintaining low‑pressure fuel system integrity and preventing air ingress across your entire fleet.
Genuine Shacman fuel inlet pipe assembly 1014012897 is stocked by authorized distributors worldwide. Parts are supplied in sealed poly bags with the banjo bolt, copper washers, and quick‑connect clip pre‑assembled, individually labeled with OEM part number and batch traceability. Bulk packs of 5 assemblies are available for fleet maintenance depots.
Expedited shipping options are available through Shacman’s regional logistics hubs in North America, Europe, Asia, Africa, and the Middle East, with typical delivery within 3‑5 business days. Always purchase from certified dealers and verify the holographic authenticity label. Counterfeit pipes may have poor crimps, wrong bend angles, or lack plating, leading to leaks and misrouting.
For preventive maintenance programs, automated replenishment ensures your workshop never runs out of essential fuel inlet pipes. Keep a stock of 1014012897 on every service truck to handle fuel system repairs in the field. Many fleets replace the inlet pipe every time the high‑pressure pump is serviced, ensuring a fresh, leak‑free supply line.
The Shacman Fuel Inlet Pipe Assembly 1014012897 is a precision‑formed, leak‑proof line that supplies clean fuel from the filter to the high‑pressure pump on X5000 engines. With its double‑wall steel tubing, zinc‑nickel plating, and durable rubber hoses, this genuine OEM component prevents air ingress, restricts flow, and resists corrosion. By choosing 1014012897, you ensure reliable starting, steady rail pressure, and long high‑pressure pump life. Don’t trust aftermarket hoses or cobbled‑together lines – insist on genuine Shacman quality for your fuel inlet system.
