Intermediate Rocker Arm Assembly
Промежуточный Рычаг в Сборе
Brazo Intermedio Completo
This OEM intermediate rocker arm assembly (part DZ95319470007) is precision-engineered for the Shacman X5000. It serves as a pivot point in the steering linkage system, transferring motion between steering components.
Manufactured from high-strength forged steel with precision-machined pivot points and bearings, this intermediate rocker arm withstands constant steering loads and articulation during heavy-duty commercial vehicle operation.
Replacing worn or damaged rocker arm assemblies with this genuine component restores proper steering geometry and eliminates play. The OEM number guarantees exact fitment and safety.
| Parameter | Specification |
|---|---|
| OEM Part Number | DZ95319470007 |
| Product Name | Intermediate Rocker Arm Assembly |
| Brand / Model | Shacman X5000 |
| Material | High-Strength Forged Steel |
| Manufacturing Process | Precision Forging with Bearing Installation |
| Function | Steering Linkage Motion Transfer and Pivot |
| Bearing Type | Sealed Tapered Roller / Needle Bearings |
| Surface Protection | Anti-Corrosion Coating |
| Packaging | Protective Wrapping with OEM Labeling |
The intermediate rocker arm is a critical steering linkage component that acts as a pivot point and direction changer within the steering system, especially in heavy trucks with complex steering geometries.
It connects the steering gear output to the drag link and then to the steering knuckles. The rocker arm rotates on its pivot shaft, converting the steering gear’s motion into appropriate movement of the wheels.
By providing a strong, low-friction pivot point, this assembly ensures smooth and precise steering response, especially during turns and when navigating uneven road surfaces.
This intermediate rocker arm is manufactured from high-strength forged steel, providing exceptional strength and fatigue resistance. The integrated bearings are sealed against contamination.
The anti-corrosion coating protects the arm from rust and environmental damage, ensuring long-term reliability and safety. The precision pivot shaft and bushings minimize friction and wear.
This rocker arm assembly installs on a pivot shaft mounted to the chassis. Correct alignment of the arm on its splines and proper torque of the retaining nut are critical for safe operation.
After installation, the entire steering linkage must be checked for correct geometry. Any play in the rocker arm bearings or connections must be addressed before returning the vehicle to service.
Each intermediate rocker arm undergoes dimensional inspection, hardness testing, and bearing preload verification to ensure smooth rotation and compliance with safety standards.
Surface finish, coating integrity, and sealed bearing performance are verified on every production batch to ensure long service life.
Visible play or looseness at the pivot point indicates bearing wear, requiring replacement of the complete rocker arm assembly to restore steering precision.
Seized or rough-feeling pivot rotation suggests bearing failure. Cracks or deformation of the forged arm are also reasons for immediate replacement.
Corrosion that has penetrated the surface or affected the pivot area also warrants replacement of the intermediate rocker arm assembly.
Aftermarket rocker arms with inferior materials or poor-quality bearings can compromise steering safety. We supply only authentic components built to exact OEM specifications.
Each assembly is individually packaged with protective wrapping. The part number DZ95319470007 is clearly marked for immediate identification and verification.
Our international logistics network ensures prompt dispatch to dealerships and fleet maintenance facilities worldwide, with full certification provided for every shipment.
Complete intermediate rocker arm assembly with sealed bearings and pivot shaft. Ready for installation with appropriate mounting hardware.
Expert guidance on rocker arm installation and steering linkage alignment is available. We help ensure proper steering function for your Shacman X5000.
For current stock availability on this genuine intermediate rocker arm assembly, please use the contact buttons above.
