OEM Integrated Electromagnetic Water Valve Assembly DZ97259740516 precision‑engineered for the Shacman X5000 SCR system. This sophisticated DZ97259740516 unit controls engine coolant flow to the urea tank heating circuit, enabling rapid DEF thawing in cold conditions.
Featuring a solenoid‑actuated valve with integrated electronic control, the Integrated Electromagnetic Water Valve Assembly DZ97259740516 provides precise coolant modulation for optimal SCR system performance across all climate conditions.
Replacing a malfunctioning valve with the genuine DZ97259740516 assembly restores proper DEF heating function and prevents the SCR system faults triggered by frozen diesel exhaust fluid.
| Parameter | Specification |
|---|---|
| OEM Part Number | DZ97259740516 |
| Product Name | Integrated Electromagnetic Water Valve Assembly |
| Brand / Model | Shacman X5000 |
| Valve Type | 2‑way normally closed solenoid valve |
| Operating Voltage | 24 Volts DC |
| Port Size | 16.00 mm hose barb connections |
| Flow Capacity | Up to 12 liters per minute at 0.5 bar |
| Response Time | Less than 100 milliseconds open/close |
| Electrical Connector | 2‑pin sealed connector with integrated diode |
| Application | Shacman X5000 urea tank coolant heating circuit control |
The DZ97259740516 integrated electromagnetic water valve assembly controls the flow of hot engine coolant through the urea tank heating circuit. When energized, it opens to circulate coolant and thaw frozen diesel exhaust fluid.
Diesel exhaust fluid freezes at approximately minus 11 degrees Celsius. Without a functioning heating system, the SCR system cannot operate in cold weather, triggering fault codes and potentially initiating engine derate conditions.
The Integrated Electromagnetic Water Valve Assembly DZ97259740516 responds to commands from the engine control module, opening proportionally or fully to regulate coolant flow based on real‑time DEF temperature sensor readings.
The DZ97259740516 valve features a robust electromagnetic solenoid that provides rapid, reliable actuation over millions of operating cycles. The integrated diode suppresses voltage spikes that could damage the engine control module.
The valve body is constructed from corrosion‑resistant materials compatible with engine coolant chemistry, ensuring long service life without internal corrosion or scale buildup that could affect valve operation.
The DZ97259740516 valve assembly mounts to the urea supply module bracket using the integrated mounting flange. The coolant hoses connect to the barbed ports and are secured with constant‑tension hose clamps.
The electrical connector must be fully seated and the locking tab engaged to prevent moisture ingress. The connector should be oriented to allow water drainage away from the electrical terminals.
Every DZ97259740516 valve assembly undergoes a functional test that verifies opening and closing response times, flow capacity at rated pressure, and leak‑free sealing in both energized and de‑energized states.
The solenoid coil is tested for correct resistance and insulation integrity. The integrated diode is verified for proper polarity and function to ensure adequate protection of the vehicle electrical system.
A malfunctioning DZ97259740516 valve typically triggers diagnostic trouble codes related to the urea tank heating circuit. The SCR system may fail to thaw DEF in cold weather, causing dosing interruption faults.
Coolant leakage from the valve body or hose connections indicates seal failure or hose degradation. Any external coolant loss from the valve assembly requires immediate investigation and repair.
When diagnosing heating circuit faults, the valve should be tested for proper electrical operation using a diagnostic tool to command the valve open and closed while monitoring coolant flow or temperature change.
The DZ97259740516 valve assembly is specifically configured for the Shacman X5000 SCR heating circuit. Its flow characteristics and electrical specifications match the requirements of this vehicle platform.
Fleet operators operating in cold climate regions should maintain spare valve assemblies in their parts inventory. Prompt replacement of a failed valve restores DEF heating and prevents cold‑weather SCR system downtime.
Aftermarket water valves with incorrect flow characteristics or inferior solenoid construction can cause persistent heating circuit faults. We supply only the authentic Shacman X5000 Integrated Electromagnetic Water Valve Assembly DZ97259740516.
Each valve assembly is factory‑tested and packaged in a protective container. The part number DZ97259740516 is clearly marked on both the valve body and the packaging for immediate identification.
Our international logistics network ensures that genuine DZ97259740516 water valve assemblies are available for immediate dispatch to dealerships and fleet maintenance facilities across all major continents.
Complete electromagnetic water valve assembly with integrated solenoid, electrical connector, and mounting flange. Factory‑tested and ready for installation.
Expert guidance on water valve installation and SCR heating system diagnostics. We help ensure your DZ97259740516 assembly provides reliable DEF thawing performance.
For current stock availability and pricing on the genuine Integrated Electromagnetic Water Valve Assembly DZ97259740516, please use the contact buttons above.
