Cutting Sleeve Straight Joint
Прямой Штуцер с Режущей Втулкой
Racor Recto de Manguito Cortante
This OEM cutting sleeve straight joint (part 190003559472) is precision-engineered for the Shacman X5000. It provides a reliable, leak-free connection for plastic or nylon air lines in pneumatic systems.
Manufactured from high-grade brass or steel with a precision-machined cutting ring, this fitting withstands constant air pressure and vibration during heavy-duty commercial vehicle operation.
Replacing worn or damaged fittings with this genuine component restores air system integrity. The OEM number guarantees exact thread and tube size compatibility.
| Parameter | Specification |
|---|---|
| OEM Part Number | 190003559472 |
| Product Name | Cutting Sleeve Straight Joint |
| Brand / Model | Shacman X5000 |
| Material | High-Grade Brass / Nickel-Plated Brass |
| Thread Type | Metric / NPT as per OEM spec |
| Tube Connection | Cutting Ring (Compression) for Nylon/Plastic Tube |
| Function | Connects / Repairs Pneumatic Air Lines |
| Max Pressure | OEM Standard (150-200 PSI) |
| Packaging | Protective Wrapping with OEM Labeling |
A cutting sleeve fitting, also known as a compression or bite-type fitting, is designed to connect plastic or nylon air lines to components like valves, brake chambers, or air tanks.
As the nut is tightened, the cutting sleeve (ferrule) compresses against the tube, “biting” into its outer surface. This creates a high-pressure seal without the need for sealants or heat.
This straight joint provides a direct, leak-free connection point, ensuring reliable air pressure delivery for critical systems like brakes and suspension.
This fitting is machined from high-grade brass for corrosion resistance. The precision-cut threads ensure a secure connection to the mating port.
The cutting ring is hardened to grip the air line securely without cutting through it, providing a vibration-resistant seal under full system pressure.
To install, cut the air line squarely, insert it fully into the fitting, then tighten the nut. A common rule is to tighten until resistance is felt, then 1 to 1.5 turns further.
Over-tightening can damage the tube or fitting. Under-tightening will result in a leak. Always use the correct tube size for the fitting.
Each fitting is inspected for thread quality, dimensional accuracy, and surface finish. The cutting ring is tested for the correct hardness.
Samples are pressure-tested to ensure they meet OEM sealing and burst pressure requirements.
Any air leak from the connection point is a clear sign of a failed fitting. Damaged threads or a cracked fitting body also warrant replacement.
If the nut or cutting sleeve is cross-threaded or damaged, the fitting must be replaced. The fitting should also be replaced if the tube has been crushed or cut improperly.
Aftermarket fittings may have poor thread tolerances or a weak cutting ring, leading to persistent leaks. We supply only authentic components built to exact OEM specifications.
Each fitting is individually packaged. The part number 190003559472 is clearly marked.
Our international logistics network ensures prompt dispatch to your facility.
Complete cutting sleeve straight joint. Ready for installation.
Expert guidance on fitting installation and air line repair is available. We help ensure correct fitment for your Shacman X5000.
For current stock availability on this genuine cutting sleeve straight joint, please use the contact buttons above.
