Main Filter Element Assembly
Фильтроэлемент Основной
Elemento Filtrante Principal
OEM Main Filter Element Assembly SZ919000958 precision‑engineered for the Shacman X5000 heavy‑duty truck. This essential SZ919000958 filtration component removes contaminants from vital fluid systems, protecting precision engine and hydraulic components from wear and damage.
Constructed with multi‑layer synthetic filter media and robust end caps, the Main Filter Element Assembly SZ919000958 delivers high dirt‑holding capacity with low flow restriction for extended service intervals.
Installing the genuine SZ919000958 filter element during routine maintenance ensures that your Shacman X5000 operates with clean fluid and maximum component protection.
| Parameter | Specification |
|---|---|
| OEM Part Number | SZ919000958 |
| Product Name | Main Filter Element Assembly |
| Brand / Model | Shacman X5000 |
| Filter Media Type | Multi‑Layer Synthetic Microfiber |
| Filtration Efficiency | 99.5% at 10 microns (Beta 200) |
| Dirt Holding Capacity | ≥ 45 grams before bypass |
| Maximum Flow Rate | 120 liters per minute |
| End Cap Material | Glass‑Reinforced Nylon with Bonded Seal |
| Overall Height | 285.00 mm |
| Application | Shacman X5000 main fluid filtration system |
The SZ919000958 main filter element assembly is the primary defense against particulate contamination in the Shacman X5000 fluid systems. It captures abrasive particles that would otherwise circulate through precision‑machined components.
Modern high‑pressure fuel injection and hydraulic systems operate with clearances measured in microns. Even particles invisible to the naked eye can cause accelerated wear on pump plungers, injector nozzles, and valve spools.
The Main Filter Element Assembly SZ919000958 removes these harmful contaminants while allowing unrestricted fluid flow, ensuring that downstream components receive clean fluid at the required pressure and volume.
The SZ919000958 filter element features a gradient‑density media structure that captures larger particles on the outer layers while finer inner layers trap microscopic contaminants. This design maximizes dirt‑holding capacity.
The synthetic microfiber material resists moisture, chemical degradation, and bacterial growth that can compromise cellulose‑based filter media. It maintains consistent filtration efficiency throughout the service interval.
Replacing the SZ919000958 element requires removing the filter housing cover and extracting the used element. The housing bowl should be cleaned of any accumulated sediment before installing the new assembly.
The new element must be seated correctly on its locating spigot and the cover seal inspected for damage before reassembly. The cover should be tightened to the specified torque to prevent external leaks.
Each production batch of SZ919000958 elements is tested for filtration efficiency using ISO 16889 multi‑pass test methodology. The Beta ratio must meet the specified standard at the rated micron size.
Collapse pressure testing verifies that the element structure can withstand the differential pressure that develops as the filter loads with contaminants. The element must not fail below the bypass valve opening pressure.
A clogged SZ919000958 element causes increased pressure drop across the filter housing. This may trigger a dashboard warning light or cause sluggish system response due to restricted fluid flow to downstream components.
Extended operation with a bypassed filter allows unfiltered fluid to circulate through the system. This rapidly accelerates wear on pumps, valves, and actuators, potentially causing catastrophic component failure.
Adherence to the manufacturer’s recommended filter change interval is essential. The Main Filter Element Assembly SZ919000958 should be replaced at every scheduled service to maintain system cleanliness.
The SZ919000958 element is specifically designed for the Shacman X5000 filter housing dimensions and sealing interface. It should not be substituted with elements of different dimensions or media specifications.
Fleet operators should stock adequate quantities of genuine elements to support preventive maintenance schedules. Timely filter changes are the most cost‑effective method of extending hydraulic and engine component life.
Aftermarket filter elements with unknown filtration efficiency put your equipment at risk. We supply only the authentic Shacman X5000 Main Filter Element Assembly SZ919000958 with certified performance data.
Each element is sealed in a protective wrapper to prevent contamination before installation. The part number SZ919000958 is clearly printed on the packaging and the element body for easy identification.
Our global distribution network maintains adequate inventory levels to support fleet operators and independent workshops. Genuine SZ919000958 elements are available for immediate dispatch worldwide.
Complete filter element assembly with integrated seals. Vacuum‑sealed packaging protects against contamination before installation.
Expert guidance on filter element replacement and system cleanliness best practices. We help ensure your SZ919000958 elements provide maximum protection.
For current stock availability and pricing on the genuine Main Filter Element Assembly SZ919000958, please use the contact buttons above.
