OEM Elbow Tube DZ93259190072 precision‑formed for the Shacman X5000 heavy‑duty truck. This engineered DZ93259190072 component redirects fluid flow through a 90‑degree angle, enabling compact routing within the engine compartment and chassis systems.
Constructed from seamless steel tubing with corrosion‑resistant plating, the Elbow Tube DZ93259190072 maintains consistent internal diameter and smooth bore surface for unrestricted fluid passage with minimal pressure drop.
Replacing a damaged or corroded elbow with the genuine DZ93259190072 unit restores proper system function and prevents the fluid leaks that can lead to component failure.
| Parameter | Specification |
|---|---|
| OEM Part Number | DZ93259190072 |
| Product Name | Elbow Tube |
| Brand / Model | Shacman X5000 |
| Material | Seamless Steel Tube with Zinc‑Nickel Plating |
| Tube Outer Diameter | 15.00 mm |
| Wall Thickness | 1.50 mm |
| Bend Angle | 90 degrees ± 1 degree |
| Leg Length (each side) | 65.00 mm from bend center |
| Working Pressure Rating | Up to 20 bar |
| Application | Shacman X5000 pneumatic and fluid routing systems |
The DZ93259190072 elbow tube enables directional changes in fluid and air lines without the flow restrictions that occur when hoses are bent beyond their minimum radius. It maintains a smooth, constant‑diameter passage around corners.
In the confined spaces of a heavy truck chassis and engine bay, rigid elbow tubes provide reliable routing solutions that flexible hoses cannot achieve without kinking. The Elbow Tube DZ93259190072 is engineered for these challenging installations.
The smooth internal bore minimizes turbulence and pressure loss in pneumatic and fluid systems. This efficiency contributes to proper brake system response times and consistent engine accessory operation.
The DZ93259190072 elbow is manufactured from seamless drawn steel tube, which eliminates the longitudinal weld seam that can be a source of leaks and corrosion initiation in welded tubing products.
The zinc‑nickel electroplating provides uniform corrosion protection across all surfaces, including the interior bore. This coating system withstands exposure to road salt, moisture, and the temperature variations typical of under‑vehicle environments.
The DZ93259190072 tube is designed for connection using compression fittings or push‑connect couplings. The tube ends should be cut square and deburred before insertion into the fitting to ensure a proper seal.
The tube must be fully inserted into the fitting until it bottoms out against the internal stop. The fitting nut or collet is then tightened according to the fitting manufacturer’s specification to complete the leak‑free connection.
Every production lot of DZ93259190072 elbow tubes is sampled for burst pressure testing. Sample tubes must withstand three times the rated working pressure without rupture or permanent deformation.
Dimensional inspection verifies bend angle, leg length, and tube diameter using optical comparator and coordinate measuring equipment. The bend radius is checked to ensure it meets the minimum specification for unrestricted flow.
External rusting or pitting on the DZ93259190072 tube surface indicates that the protective plating has been compromised. If corrosion penetrates the tube wall, a pinhole leak will develop under system pressure.
A kinked or dented elbow tube restricts flow and creates a stress concentration that can lead to fatigue cracking. Any tube showing mechanical damage should be replaced immediately regardless of its apparent functional condition.
During routine system inspections, all rigid tubing should be visually examined for signs of corrosion, damage, or loose connections. Replacing a suspect Elbow Tube DZ93259190072 prevents system failures and fluid loss.
The DZ93259190072 elbow tube matches the tubing diameter and fitting interface dimensions used across the Shacman X5000 air and fluid systems. It integrates seamlessly with the factory‑specified connectors.
Fleet maintenance programs benefit from standardizing on genuine replacement tubing that guarantees correct fit and material compatibility with the fluids and pressures present in each system.
Aftermarket tubing with inconsistent wall thickness or inferior plating can fail unexpectedly. We supply only the authentic Shacman X5000 Elbow Tube DZ93259190072 manufactured to stringent OEM specifications.
Each tube is individually packaged to protect the plating and prevent bending during transit. The part number DZ93259190072 is clearly displayed on the packaging for rapid identification.
Our global distribution network ensures that genuine DZ93259190072 elbow tubes are available for immediate dispatch to dealerships, independent workshops, and fleet maintenance facilities worldwide.
Single elbow tube with protective end caps. Ready for installation with standard compression or push‑connect fittings.
Expert guidance on tube installation and fitting connection procedures. We help ensure your DZ93259190072 tubes provide reliable leak‑free service.
For current stock availability and pricing on the genuine Elbow Tube DZ93259190072, please use the contact buttons above.
