Primary Filter Bracket Assembly
Кронштейн Первичного Фильтра
Soporte del Filtro Primario
OEM Primary Filter Bracket Assembly DZ93259190076 precision‑engineered for the Shacman X5000 air intake system. This robust DZ93259190076 mounting structure secures the primary air filter housing to the chassis, maintaining proper alignment and vibration isolation.
Fabricated from high‑strength structural steel with durable anti‑corrosion coating, the Primary Filter Bracket Assembly DZ93259190076 withstands engine vibration and the mechanical loads of filter service operations.
Replacing a cracked or corroded bracket with the genuine DZ93259190076 assembly restores proper filter housing support and prevents the intake duct stress that leads to air leaks and contamination.
| Parameter | Specification |
|---|---|
| OEM Part Number | DZ93259190076 |
| Product Name | Primary Filter Bracket Assembly |
| Brand / Model | Shacman X5000 |
| Material | High‑Strength Structural Steel with Black Powder Coating |
| Bracket Type | Formed steel support with welded gussets |
| Chassis Mounting Holes | 3‑hole pattern, 10.50 mm diameter |
| Filter Housing Mount | Clamp‑style with M8 bolt retention |
| Load Capacity | Supports up to 15 kg filter assembly |
| Corrosion Protection | Black powder coating, 500 hours salt spray rated |
| Application | Shacman X5000 primary air filter housing chassis mounting |
The DZ93259190076 primary filter bracket assembly anchors the air filter housing to the Shacman X5000 chassis. It positions the housing correctly for intake duct alignment and provides a stable base for filter service.
Air filter housings require periodic opening for element replacement, and the bracket must withstand the torque applied during cover removal without loosening or deforming from the chassis mounting points.
The Primary Filter Bracket Assembly DZ93259190076 includes vibration‑dampening features that isolate the filter housing from chassis vibrations, preventing intake duct fatigue and connection loosening.
The DZ93259190076 bracket is fabricated from high‑strength structural steel with welded reinforcement gussets. The black powder coating provides durable corrosion protection for chassis service.
The clamp‑style filter housing mount includes a vibration‑dampening liner that grips the housing securely while preventing metal‑to‑metal contact that could abrade the filter housing surface.
The DZ93259190076 bracket mounts to the chassis frame using three high‑strength bolts. The filter housing is secured in the clamp mount with the M8 retention bolt torqued to specification.
During filter element replacement, the bracket should be inspected for cracks, corrosion, and secure attachment. The clamp liner should be checked for deterioration that could affect its grip.
Each production batch of DZ93259190076 brackets undergoes dimensional verification and static load testing to confirm weld integrity and mounting hole accuracy against engineering specifications.
Powder coating adhesion is verified through cross‑hatch testing, and coating thickness is measured using eddy current equipment to ensure consistent corrosion protection for the bracket assembly.
Rust staining or bubbling of the powder coating on the DZ93259190076 bracket indicates corrosion has penetrated the protective layer. If unchecked, this reduces structural integrity over time.
Cracks at weld joints or around bolt holes indicate fatigue damage. Cracked brackets must be replaced immediately to prevent filter housing detachment during vehicle operation.
During filter service, the bracket should be inspected for condition. Loose or damaged brackets compromise intake system integrity and should be addressed promptly to maintain proper filtration.
The DZ93259190076 bracket is specifically configured for the Shacman X5000 primary filter housing dimensions and chassis mounting pattern, matching factory specifications exactly.
Fleet workshops should maintain spare bracket assemblies for replacement during filter service when corrosion or damage is discovered, ensuring continued intake system security and performance.
Aftermarket brackets with incorrect dimensions can misalign filter housings and stress intake ducts. We supply only the authentic Shacman X5000 Primary Filter Bracket Assembly DZ93259190076 built to OEM specifications.
Each assembly is individually packaged with protective wrapping. The part number DZ93259190076 is clearly displayed on the packaging for immediate identification and verification.
Our international logistics network ensures genuine DZ93259190076 filter bracket assemblies are available for dispatch to dealerships and fleet facilities worldwide.
Complete bracket assembly with clamp mount and vibration liner. Ready for chassis installation and filter housing attachment.
Expert guidance on bracket installation and filter service procedures. We help ensure your DZ93259190076 assembly provides secure filtration system support.
For current stock availability on the genuine Primary Filter Bracket Assembly DZ93259190076, please use the contact buttons above.
