Assembled Sealing Washer
Уплотнительная шайба в сборе
Arandela de sellado ensamblada
The OEM Assembled Sealing Washer 13023362 is a precision-engineered multi-component sealing device manufactured exclusively for the Shacman X5000 heavy-duty truck platform. This critical assembly combines a metal outer ring with a bonded elastomeric inner sealing element, creating a reliable, reusable seal at bolted joints, hydraulic connections, and pneumatic fittings where the prevention of fluid or gas leakage is absolutely essential for system integrity and vehicle safety under all operating pressures and environmental conditions.
Manufactured from high-quality steel, copper, or aluminum for the outer ring and durable nitrile, fluorocarbon, or silicone rubber for the bonded sealing element, the assembled sealing washer delivers exceptional conformability, chemical resistance, and reliable sealing performance across thousands of pressure and thermal cycles. The 13023362 part features a precisely controlled thickness and inner diameter that fits perfectly around the bolt, stud, or fitting, ensuring uniform compression and a complete seal when the fastener is torqued to specification.
Installing a genuine OEM assembled sealing washer at every critical fluid connection preserves the designed leak-free integrity of the engine, transmission, and chassis systems. The 13023362 identifier provides complete traceability to Shacman’s rigorous material specifications and precision manufacturing quality assurance standards for these safety-critical sealing components.
| Parameter | Specification | Details |
|---|---|---|
| OEM Part Number | 13023362 | Unique Shacman X5000 identifier |
| Product Name | Assembled Sealing Washer | Bonded metal and elastomeric sealing ring |
| Brand / Vehicle Model | Shacman X5000 | Heavy-duty truck series |
| Outer Ring Material | Steel, copper, or aluminum | Provides structural support and crush resistance |
| Sealing Element Material | Nitrile, fluorocarbon, or silicone rubber | Excellent conformability and fluid compatibility |
| Manufacturing Process | Precision stamping and bonding | Consistent thickness and concentricity |
| Sealing Mechanism | Compressive face sealing with elastomeric conformability | Seals surface irregularities under bolt torque |
| Fluid Compatibility | Oil, coolant, fuel, and air resistant | Suitable for all vehicle fluid systems |
| Application | Bolted joints, hydraulic and pneumatic fittings | Creates leak-free seal under fastener compression |
| Packaging | Protective sealed packaging | Shacman genuine labeled packaging |
The bonded elastomeric element conforms to microscopic surface imperfections on both mating faces, creating a positive seal that prevents fluid or gas leakage even under high pressure and vibration conditions where a standard metal washer would fail to seal.
The 13023362 washer’s metal outer ring limits the compression of the elastomeric element, preventing over-compression that could extrude or damage the seal, while ensuring the correct sealing pressure is achieved at the specified bolt torque.
Unlike single-use crush washers, the assembled design can often be reused multiple times without loss of sealing performance, reducing maintenance costs and ensuring a reliable seal is always available during field service operations.
The assembled sealing washer 13023362 is installed under the head of a bolt, banjo bolt, or other threaded fastener on the Shacman X5000 vehicle. Before installation, both the washer and the mating surfaces must be clean and free of debris, old sealant, or damage that could prevent proper sealing. The washer is placed over the bolt shank with the elastomeric sealing element oriented toward the surface to be sealed, and the bolt is threaded into position. The fastener is then torqued to the exact factory specification, compressing the elastomeric element against the mating surface to create the seal. The metal outer ring prevents over-torquing from crushing or extruding the rubber element. After the system is pressurized, the connection should be visually inspected for any signs of leakage. If a leak is detected, the fastener torque should be rechecked before considering washer replacement, as under-torquing is a common cause of seal failure.
Each assembled sealing washer produced under OEM number 13023362 is manufactured using a precision bonding process. The metal outer ring is stamped from high-quality sheet stock to achieve the exact inner and outer diameters and thickness specified by Shacman engineering. The surface that will receive the elastomeric element is specially prepared to ensure maximum adhesion. The elastomeric sealing element is injection-molded or compression-molded directly onto the metal ring, creating a permanent chemical and mechanical bond that will not separate during installation or service.
The elastomeric material is precisely formulated to provide the correct hardness, compression set resistance, and chemical compatibility for its intended application. After molding and bonding, each washer undergoes dimensional inspection to verify inner diameter, outer diameter, and overall thickness. The bond integrity is tested on a sample basis to ensure the elastomeric element will not detach from the metal ring under compression. Sample washers are subjected to pressure testing to verify their sealing performance at the specified bolt torque. The completed washers are packaged in sealed, protective packaging and labeled with the 13023362 part number for complete traceability.
Assembled sealing washers should be visually inspected whenever the fastener they seal is removed for service. Technicians should examine the elastomeric element for any signs of cracking, hardening, swelling, or permanent compression set that would prevent it from conforming to the mating surfaces. The metal ring should be checked for any deformation, corrosion, or damage that could affect its compression-limiting function or prevent it from seating flat against the mating surface.
If the elastomeric element shows any signs of deterioration or if the washer has been subjected to a leak condition, it should be replaced with a new 13023362 component. While these washers are more durable than single-use crush washers, they should not be reused indefinitely. A good practice is to replace sealing washers at major service intervals or whenever the connected component is replaced. The cost of a new sealing washer is insignificant compared to the potential damage and safety risk caused by a fluid leak from a degraded seal.
Procuring the authentic assembled sealing washer for your Shacman X5000 vehicle service is a simple process that ensures reliable sealing performance. Use the inquiry button above to verify current stock availability and request a prompt quotation. We maintain comprehensive inventory of these essential sealing components to support both individual system repairs and complete fleet maintenance programs across all international markets.
To ensure you receive the exact factory-specified sealing washer with correct dimensions and elastomeric material for your application, always reference the OEM part number 13023362 in your purchase order. Our logistics team provides complete export documentation with every international shipment for efficient customs clearance and inventory verification at your facility.
Global Stock Available
Immediate dispatch for Shacman X5000 sealing applications worldwide.
Choosing the genuine Assembled Sealing Washer 13023362 is a decision that directly protects the sealed integrity and long-term reliability of your Shacman X5000 vehicle’s critical fluid and pneumatic systems. Aftermarket sealing washers manufactured from inferior materials or with imprecise bonding can fail to seal, allowing the escape of engine oil, coolant, fuel, or compressed air. A leaking seal at a critical connection can cause system performance loss, component damage from fluid starvation, or create a safety hazard from fuel or oil spray onto hot engine surfaces.
The OEM sealing washer’s specific metal and elastomer combination, precise dimensions, and controlled bonding process were validated through extensive pressure pulsation, thermal cycling, and vibration testing on Shacman’s component test stands. Engineers specified this exact sealing washer design to provide the optimal balance of conformability, durability, and chemical resistance required for its specific application on the X5000 vehicle. The 13023362 washer delivers the dependable, long-life sealing performance that professional fleet operators require to keep their vehicles on the road generating revenue.
Professional fleet technicians and maintenance managers worldwide standardize on the 13023362 assembled sealing washer for its guaranteed material quality, precise fit, and proven sealing reliability in the field. This small but sophisticated component performs the vital function of keeping critical fluids and gases contained within their systems, protecting both the environment and the vehicle’s mechanical integrity. Trust only the sealing washer that Shacman engineered and certified for the demanding X5000 heavy truck platform.
The assembled sealing washer 13023362 represents an evolution beyond simple metal crush washers or flat gaskets. By combining the structural support of a metal ring with the conformability of an elastomeric element, this design provides the best characteristics of both materials. The metal ring ensures that the bolt torque is converted into a controlled compressive force on the seal, while the elastomeric element flows into surface imperfections that would cause a leak path for a purely metal seal. This combination creates a seal that is both robust and forgiving of minor surface irregularities.
When installing an assembled sealing washer, orientation is important. The elastomeric element should face the surface that requires the most conformability, which is typically the component being sealed rather than the bolt head or banjo fitting. This allows the rubber to fill any machining marks or surface imperfections on the component, while the metal side of the washer provides a stable bearing surface for the bolt head to rotate against during tightening, preventing the rubber from twisting or tearing as torque is applied.
For our international customers, we take exceptional care in packaging the 13023362 assembled sealing washers to prevent any damage to the elastomeric elements or metal rings during global transit and extended warehouse storage. Each washer is individually protected and packed in sealed, moisture-resistant packaging that prevents corrosion and preserves the elastomeric properties. Partner with our global supply network for a reliable source of genuine Shacman sealing components, and ensure that every fluid connection on your fleet’s vehicles is sealed with the quality and reliability that Shacman engineers intended.
