Fastener&Pad Belt Assy
Крепёжный Ремень
Correa de Sujeción
OEM Fastener&Pad Belt Assy/83/680 × Five Hundred And Twenty DZ91259550702 precision‑manufactured for the Shacman X5000 heavy‑duty truck. This specialized DZ91259550702 securing assembly combines a high‑strength belt with an integrated cushioning pad for reliable component restraint.
Constructed with industrial‑grade webbing and a molded elastomeric pad, the Fastener&Pad Belt Assy/83/680 × Five Hundred And Twenty DZ91259550702 provides secure fastening while protecting surfaces from abrasion and vibration damage.
Replacing worn or damaged restraint belts with the genuine DZ91259550702 component ensures that critical vehicle systems remain properly secured throughout demanding operating conditions.
| Parameter | Specification |
|---|---|
| OEM Part Number | DZ91259550702 |
| Product Name | Fastener&Pad Belt Assy/83/680 × Five Hundred And Twenty |
| Brand / Model | Shacman X5000 |
| Belt Material | High‑Tenacity Polyester Webbing |
| Pad Material | EPDM Rubber with Fabric Backing |
| Belt Width | 83.00 mm |
| Belt Length | 680.00 mm effective length |
| Pad Dimensions | 520.00 mm × 80.00 mm × 6.00 mm |
| Tensile Strength | ≥ 15 kN breaking strength |
| Application | Shacman X5000 component restraint and securing system |
The DZ91259550702 fastener and pad belt assembly serves as a versatile securing solution for various components on the Shacman X5000. It combines the tensile strength of industrial webbing with the protective cushioning of an integrated pad.
This assembly is designed to restrain cylindrical or irregularly shaped objects such as air tanks, hydraulic reservoirs, and exhaust system components. The wide 83‑millimeter belt distributes clamping force evenly around the secured item.
The integrated pad, measuring 520 millimeters in length, provides a compliant interface between the belt and the secured component. This cushion absorbs vibration and prevents the belt from wearing through paint or protective coatings.
The DZ91259550702 belt is woven from high‑tenacity polyester yarns that provide exceptional strength‑to‑weight ratio and minimal stretch under sustained load. This ensures that the clamping force remains consistent over time.
Polyester webbing offers excellent resistance to ultraviolet degradation, moisture absorption, and the oil and fuel exposure common in the under‑chassis environment of heavy commercial vehicles.
The DZ91259550702 assembly is installed by wrapping the belt around the component and its mounting bracket, then feeding the free end through the fastener mechanism. The belt is pulled tight before the fastener is locked.
Proper tensioning is achieved when the belt is snug but not over‑tightened. Excessive tension can deform thin‑walled components, while insufficient tension allows movement that defeats the purpose of the restraint system.
Each production batch of DZ91259550702 assemblies is sampled for tensile testing to verify that the breaking strength exceeds the 15 kilonewton minimum specification. The webbing must fail in the body, not at the fastener joint.
The EPDM cushion pad is tested for compression set after heat aging to ensure that it retains its vibration‑absorbing properties throughout the assembly’s intended service life.
Frayed or cut fibers on the DZ91259550702 belt webbing indicate that the belt has been rubbing against a sharp edge or has been mechanically damaged. Damaged webbing loses strength rapidly and should be replaced.
A pad that has become hardened, cracked, or has separated from the belt backing no longer provides effective cushioning. The secured component may show signs of fretting or abrasion at the contact point.
During routine vehicle inspections, all restraint belts should be checked for tension, condition, and correct positioning. Loose or damaged belts compromise the security of the components they are meant to protect.
The DZ91259550702 assembly is dimensioned for specific component restraint applications on the Shacman X5000 platform. Its belt width and pad length match the factory‑specified mounting requirements.
Fleet maintenance programs should include these restraint assemblies in their consumable parts inventory. Timely replacement of worn belts prevents the progressive damage that loose components can cause to adjacent systems.
Aftermarket restraint belts with lower tensile strength or inferior pad materials can fail in service. We supply only the authentic Shacman X5000 Fastener&Pad Belt Assy/83/680 × Five Hundred And Twenty DZ91259550702.
Each assembly is individually packaged to protect the webbing and pad from contamination during storage and transit. The part number DZ91259550702 is clearly printed on the packaging label.
Our international supply chain ensures that genuine DZ91259550702 fastener and pad belt assemblies are available for immediate dispatch to workshops and fleet operators across all major continents.
Complete fastener and pad belt assembly with integrated cushion. Ready for installation with standard mounting hardware configurations.
Expert guidance on belt assembly installation and tensioning best practices. We help ensure your DZ91259550702 assemblies provide reliable component restraint.
For current stock availability and pricing on the genuine Fastener&Pad Belt Assy/83/680 × Five Hundred And Twenty DZ91259550702, please use the contact buttons above.
