Fuel Tank Bracket Assembly
Кронштейн Топливного Бака
Soporte del Tanque
OEM Fuel Tank Bracket Assembly DZ91189553760 precision‑engineered for the Shacman X5000 heavy‑duty truck. This robust DZ91189553760 mounting component secures the fuel tank to the chassis frame, providing stable support under all driving conditions.
Fabricated from high‑strength structural steel with a durable protective coating, the Fuel Tank Bracket Assembly DZ91189553760 withstands the combined loads of a fully fueled tank, road vibration, and dynamic chassis flexing.
Replacing worn or damaged brackets with the genuine DZ91189553760 assembly ensures that your fuel tank remains securely mounted and protected against movement that could cause leaks or structural damage.
| Parameter | Specification |
|---|---|
| OEM Part Number | DZ91189553760 |
| Product Name | Fuel Tank Bracket Assembly |
| Brand / Model | Shacman X5000 |
| Material | High‑Strength Structural Steel with Powder Coating |
| Assembly Components | Upper bracket, lower support, rubber cushion, hardware |
| Mounting Bolt Hole Diameter | 14.00 mm (chassis frame mounting points) |
| Load Capacity | Supports tanks up to 500 kg fully fueled |
| Corrosion Protection | Black powder coating, 600 hours salt spray rated |
| Tank Contact Interface | Rubber‑lined cradle to prevent abrasion |
| Application | Shacman X5000 fuel tank mounting to chassis frame |
The DZ91189553760 fuel tank bracket assembly is the structural interface between the vehicle chassis and the fuel storage system. It must safely support the considerable weight of a fully fueled tank through all vehicle maneuvers.
A fully loaded 380‑liter diesel tank weighs over 300 kilograms. The brackets transfer this static load and the dynamic forces from acceleration, braking, and cornering into the chassis frame without deformation or fatigue.
The Fuel Tank Bracket Assembly DZ91189553760 also incorporates rubber cushioning elements that isolate the tank from chassis vibration, preventing the fretting wear that could eventually compromise the tank wall integrity.
The DZ91189553760 bracket is manufactured from high‑strength structural steel that provides the necessary load‑bearing capacity with an appropriate safety margin for overload conditions encountered in rough terrain.
The black powder coating applied to all bracket surfaces creates a durable barrier against moisture, road salt, and stone impact. This coating maintains its protective properties through years of exposure to harsh operating environments.
Installing the DZ91189553760 bracket assembly requires aligning the upper and lower components with the chassis frame holes. The rubber cushion must be correctly positioned in the tank cradle before the straps are secured.
All mounting bolts must be tightened to the torque values specified in the Shacman service manual. A calibrated torque wrench ensures that the clamping force is sufficient to prevent movement without damaging the frame or bracket.
Each production batch of DZ91189553760 brackets undergoes static load testing at twice the rated capacity. The bracket assembly must show no permanent deformation or cracking after the test load is applied.
Coating adhesion is verified using cross‑hatch testing according to ISO 2409 standards. The powder coating must achieve a classification of 0 or 1, indicating excellent bonding to the steel substrate.
Rust staining around the mounting holes or along welded joints indicates that the powder coating on the DZ91189553760 bracket has been compromised and corrosion is advancing into the steel substrate.
Cracks initiating from bolt holes or sharp corners are evidence of fatigue damage. Cracked brackets can fail suddenly, potentially causing the fuel tank to separate from the vehicle with catastrophic consequences.
During routine chassis inspections, all tank mounting hardware should be checked for tightness and the bracket assemblies visually inspected for damage or deformation. Prompt replacement prevents progressive deterioration.
The DZ91189553760 bracket assembly is specifically designed for the Shacman X5000 chassis frame dimensions and fuel tank configuration. It matches the factory mounting hole patterns exactly.
Fleet operators should maintain spare bracket assemblies in their parts inventory. Rapid replacement of damaged brackets minimizes vehicle downtime and prevents the secondary damage that loose tanks cause.
Aftermarket brackets made from inferior steel or lacking proper corrosion protection can fail prematurely. We supply only the authentic Shacman X5000 Fuel Tank Bracket Assembly DZ91189553760.
Each assembly is packaged with protective wrapping to prevent coating damage during transit. The part number DZ91189553760 is clearly displayed on both the component label and shipping documentation.
Our international distribution network ensures that genuine DZ91189553760 fuel tank bracket assemblies reach dealerships and fleet maintenance facilities worldwide with prompt delivery scheduling.
Complete bracket assembly including upper bracket, lower support, rubber cushion, and all required mounting hardware for installation.
Expert guidance on bracket installation and torque procedures. We help ensure your DZ91189553760 assemblies provide secure long‑term fuel tank support.
For current stock availability and delivery information on the genuine Fuel Tank Bracket Assembly DZ91189553760, please use the contact buttons above.
