Aluminum Alloy Fuel Tank Assembly 38
Топливный Бак Алюминиевый
Tanque de Combustible
OEM Aluminum Alloy Fuel Tank Assembly 38 (ISM) DZ91189554780 manufactured to exact Shacman X5000 specifications. This genuine DZ91189554780 fuel storage component provides the extended range required for long‑haul transportation with superior corrosion resistance.
Constructed from high‑grade aluminum alloy with precision‑welded seams and internal baffles, the Aluminum Alloy Fuel Tank Assembly 38 (ISM) DZ91189554780 combines lightweight design with exceptional structural durability.
Replacing a damaged or corroded tank with the authentic DZ91189554780 unit restores proper fuel capacity and eliminates the contamination risks associated with aging fuel storage systems.
| Parameter | Specification |
|---|---|
| OEM Part Number | DZ91189554780 |
| Product Name | Aluminum Alloy Fuel Tank Assembly 38 (ISM) |
| Brand / Model | Shacman X5000 |
| Tank Material | 5754 Aluminum Alloy with Internal Coating |
| Fuel Capacity | 380 liters |
| Overall Dimensions | 1280 mm × 650 mm × 600 mm (approximate) |
| Internal Baffle Design | Multi‑chamber with anti‑slosh perforations |
| Filler Neck Diameter | 80.00 mm with integrated vent |
| Mounting System | Heavy‑duty steel straps with rubber insulators |
| Application | Shacman X5000 ISM engine long‑haul fuel system |
The DZ91189554780 fuel tank assembly is the primary reservoir that stores diesel fuel for the Shacman X5000 ISM engine. Its 380‑liter capacity enables extended driving range between refueling stops, critical for efficient logistics operations.
Aluminum alloy construction offers significant weight savings compared to traditional steel tanks while providing natural corrosion resistance that eliminates the internal rust problems that contaminate fuel systems.
The Aluminum Alloy Fuel Tank Assembly 38 (ISM) DZ91189554780 incorporates internal baffles that control fuel movement during vehicle acceleration, braking, and cornering, maintaining consistent fuel pickup at the sender unit.
The DZ91189554780 tank is fabricated from 5754 aluminum alloy, a marine‑grade material selected for its excellent weldability and resistance to corrosion from diesel fuel, road salt, and atmospheric exposure.
The internal surface receives a protective coating that prevents any aluminum oxide formation from entering the fuel stream, ensuring that downstream filters and injection components remain free of particulate contamination.
The DZ91189554780 tank is secured to the chassis using heavy‑duty steel mounting straps lined with rubber insulators. These insulators prevent metal‑to‑metal contact that could cause galvanic corrosion.
The mounting straps must be tightened evenly to the specified torque to ensure uniform load distribution. Over‑tightening can distort the tank shell, while loose straps allow movement that fatigues the mounting brackets.
Every DZ91189554780 tank assembly undergoes a pressurized leak test after fabrication. The tank is pressurized with air and submerged in water to detect any weld porosity or seam leakage.
Dimensional inspection verifies that mounting bracket positions, filler neck location, and fuel sender opening dimensions conform to engineering drawings for proper vehicle fitment.
External pitting or white powdery corrosion on the DZ91189554780 tank surface indicates that the aluminum has been exposed to corrosive chemicals or that the protective coating has been compromised.
Diesel fuel odor around the vehicle or visible wet spots on the tank exterior indicate a developing leak. Even minor seepage at welded seams requires immediate tank replacement to prevent fuel loss and fire hazard.
During routine vehicle inspections, tank mounting straps should be checked for tension and corrosion. Loose or rusted straps allow tank movement that can eventually wear through the tank wall at contact points.
The DZ91189554780 tank assembly is specifically configured for the Shacman X5000 chassis with ISM engine application. Its mounting points and plumbing connections match this vehicle platform.
Fleet operators benefit from standardizing on the genuine tank assembly, which ensures consistent fuel capacity, proper fitment, and the corrosion resistance necessary for long‑term reliable service.
Aftermarket fuel tanks with thinner material or inferior welding can develop leaks prematurely. We supply only the authentic Shacman X5000 Aluminum Alloy Fuel Tank Assembly 38 (ISM) DZ91189554780.
Each tank is carefully packaged with protective padding to prevent damage during transit. The part number DZ91189554780 is clearly marked on both the tank identification plate and the shipping documentation.
Our international logistics network ensures that genuine DZ91189554780 fuel tank assemblies reach fleet operators and service facilities promptly, supporting both scheduled replacements and collision repair operations.
Complete fuel tank assembly with internal baffles, filler neck, and mounting provisions. Fuel sender unit and mounting straps available separately.
Expert guidance on fuel tank installation and mounting strap procedures. We help ensure your DZ91189554780 assembly provides reliable long‑term fuel storage.
For current stock availability and delivery scheduling on the genuine Aluminum Alloy Fuel Tank Assembly 38 (ISM) DZ91189554780, please use the contact buttons above.
