Oil Sensor/505/16/Integrated
Датчик Масла
Sensor de Aceite
OEM Oil Sensor/505/16/Integrated DZ93189552021 calibrated specifically for the Shacman X5000 heavy‑duty diesel engine. This advanced DZ93189552021 monitoring device provides real‑time oil condition and level data to the engine management system for optimal performance.
Featuring integrated sensing technology with robust construction, the Oil Sensor/505/16/Integrated DZ93189552021 combines multiple measurement functions in a single compact unit that mounts directly into the engine lubrication circuit.
Installing the genuine DZ93189552021 sensor ensures accurate oil monitoring and protects your engine from the damage caused by undetected low oil levels or degraded lubricant.
| Parameter | Specification |
|---|---|
| OEM Part Number | DZ93189552021 |
| Product Name | Oil Sensor/505/16/Integrated |
| Brand / Model | Shacman X5000 |
| Sensor Type | Integrated multi‑function oil condition monitor |
| Measurement Functions | Oil level, temperature, and quality sensing |
| Thread Size | M16 × 1.5 mm |
| Probe Length | 505.00 mm from mounting face |
| Electrical Connector | 4‑pin sealed Deutsch connector |
| Output Signal | CAN bus digital communication protocol |
| Application | Shacman X5000 engine oil pan monitoring system |
The DZ93189552021 oil sensor represents a significant advancement in engine lubrication monitoring. Unlike traditional oil pressure switches, this integrated unit continuously analyzes multiple oil parameters simultaneously.
Real‑time oil level data allows the engine management system to alert the driver before the oil level drops to a critical point. This early warning prevents the bearing damage that occurs when engines are operated with insufficient lubrication.
The Oil Sensor/505/16/Integrated DZ93189552021 also monitors oil quality by measuring dielectric properties that change as the oil oxidizes and accumulates contaminants. This enables condition‑based oil change intervals.
The DZ93189552021 sensor combines level, temperature, and quality sensing in a single probe assembly. This integration eliminates the need for multiple separate sensors and their associated wiring and mounting provisions.
The 505‑millimeter probe length ensures that the sensing elements are positioned at the correct depth within the oil pan, providing accurate measurements regardless of vehicle inclination within normal operating limits.
The DZ93189552021 sensor threads into a dedicated port on the engine oil pan. The M16 thread must be engaged carefully to avoid cross‑threading, and the sealing washer must be replaced with each installation.
After installation, the sensor communicates with the engine control module via CAN bus. The system performs an automatic calibration cycle to establish baseline readings for the specific oil type and engine configuration.
Every DZ93189552021 sensor undergoes a multi‑point calibration verification using reference fluids of known properties. The sensor must output readings within specified tolerance bands across the full measurement range.
Thermal cycling tests subject the sensor to extreme temperature variations while monitoring output stability. The integrated electronics must maintain calibration accuracy without drift throughout the test sequence.
A faulty DZ93189552021 sensor typically triggers a diagnostic trouble code and illuminates the check engine warning lamp. The engine control module may substitute default values when sensor data is unreliable.
Contaminated or degraded engine oil can coat the sensor probe and affect its readings. In such cases, the oil should be changed and the sensor cleaned before condemning the sensor as defective.
When replacing the sensor, the oil pan port threads should be cleaned and inspected. Any damage to the threads can prevent proper sealing and lead to oil leakage around the sensor body.
The DZ93189552021 sensor is specifically programmed for the Shacman X5000 engine management system. It must be matched with the correct software calibration to provide accurate and meaningful data.
Fleet operators benefit from the extended oil change intervals enabled by accurate oil condition monitoring. The genuine sensor pays for itself through reduced lubricant consumption and fewer preventive maintenance events.
Aftermarket oil sensors with unverified calibration can provide inaccurate data that leads to incorrect driver warnings or, worse, failure to alert when oil levels are critically low. We supply only the authentic Shacman X5000 Oil Sensor/505/16/Integrated DZ93189552021.
Each sensor is sealed in protective packaging with desiccant to prevent moisture damage to the electronic components. The part number DZ93189552021 is clearly printed on both the sensor body and the packaging label.
Our international distribution network ensures that genuine DZ93189552021 oil sensors are available for immediate dispatch to dealerships, independent workshops, and fleet maintenance facilities worldwide.
Complete integrated oil sensor assembly with sealing washer and connector. Factory‑calibrated and ready for plug‑and‑play installation.
Expert guidance on sensor installation and diagnostic troubleshooting. We help ensure your DZ93189552021 sensor provides accurate engine oil monitoring.
For current stock availability and pricing on the genuine Oil Sensor/505/16/Integrated DZ93189552021, please use the contact buttons above.
