Fuel Tank Bracket
Кронштейн Топливного Бака
Soporte del Tanque
OEM Fuel Tank Bracket DZ91189553761 precision‑formed for the Shacman X5000 heavy‑duty truck chassis. This sturdy DZ91189553761 mounting component provides a secure anchor point for the fuel tank, maintaining proper positioning through all vehicle maneuvers.
Fabricated from high‑strength structural steel with a durable anti‑corrosion finish, the Fuel Tank Bracket DZ91189553761 withstands the static and dynamic loads imposed by a fully fueled tank on rough terrain and highway conditions.
Replacing a bent or corroded bracket with the genuine DZ91189553761 component restores proper tank support and prevents the fuel system stress that leads to leaks and structural fatigue.
| Parameter | Specification |
|---|---|
| OEM Part Number | DZ91189553761 |
| Product Name | Fuel Tank Bracket |
| Brand / Model | Shacman X5000 |
| Material | High‑Strength Structural Steel with Black E‑coat |
| Bracket Type | Individual chassis‑mounted support arm |
| Mounting Hole Diameter | 12.00 mm (2 chassis frame bolt holes) |
| Tank Strap Slot Width | 35.00 mm |
| Load Capacity | Supports up to 250 kg per bracket |
| Corrosion Protection | Electrophoretic coating, 480 hours salt spray |
| Application | Shacman X5000 fuel tank chassis mounting system |
The DZ91189553761 fuel tank bracket is a critical chassis component that transfers the weight of the fuel tank and its contents directly into the vehicle frame. It maintains the tank in its designed position relative to the chassis.
During vehicle operation, the bracket must withstand not only the static weight but also the dynamic forces generated by acceleration, braking, cornering, and road surface irregularities. These combined loads can exceed twice the static weight.
The Fuel Tank Bracket DZ91189553761 also provides the anchor slot through which the tank securing strap passes. This slot positions the strap correctly around the tank circumference for uniform clamping force distribution.
The DZ91189553761 bracket is manufactured from high‑strength structural steel that provides the necessary load‑bearing capacity with a generous safety margin for overload conditions encountered in demanding applications.
The electrophoretic coating applied to the bracket provides uniform corrosion protection across all surfaces, including internal corners and edges that are difficult to protect with spray‑applied coatings. This e‑coat layer withstands 480 hours of salt spray exposure.
The DZ91189553761 bracket mounts to pre‑drilled holes in the chassis frame rail using high‑strength bolts and prevailing‑torque lock nuts. The mounting surfaces must be clean and free of corrosion before installation.
The bolts should be tightened to the torque specification in the Shacman service manual. Under‑torqued bolts allow bracket movement that can elongate the frame holes, while over‑torquing can fracture the bracket or strip threads.
Each production batch of DZ91189553761 brackets is sampled for static load testing. The bracket must withstand a test load of three times its rated capacity without permanent deformation or crack formation.
Coating thickness measurements are taken at multiple points on each bracket using eddy current testing equipment. The e‑coat thickness must meet the minimum specification across all functional surfaces.
Rust staining or bubbling of the coating on the DZ91189553761 bracket indicates that corrosion has penetrated the e‑coat layer. If left unaddressed, this corrosion can progress to pitting that reduces the effective cross‑section.
Cracks propagating from the mounting holes or the strap slot are evidence of fatigue loading. Cracked brackets must be replaced immediately to prevent sudden failure that could cause the fuel tank to detach from the vehicle.
During chassis inspections, all fuel tank brackets should be checked for tightness and structural integrity. Loose or damaged brackets compromise the security of the entire fuel storage system.
The DZ91189553761 bracket is specifically designed for the Shacman X5000 chassis frame rail dimensions and hole pattern. It mates correctly with the corresponding tank straps and the fuel tank configuration.
Fleet maintenance programs should include these brackets in their chassis component inventory. Rapid replacement of damaged brackets minimizes the risk of tank‑related incidents and keeps vehicles in service.
Aftermarket brackets made from thinner gauge steel or lacking proper corrosion protection can fail in service. We supply only the authentic Shacman X5000 Fuel Tank Bracket DZ91189553761 manufactured to OEM specifications.
Each bracket is individually packaged to prevent coating damage during handling and transit. The part number DZ91189553761 is clearly displayed on both the component label and the packaging.
Our international supply chain maintains strategic stock levels to support fleet operators and service facilities worldwide. Genuine DZ91189553761 brackets are dispatched promptly to minimize vehicle downtime.
Single fuel tank bracket with protective coating. Mounting hardware available separately. Protective packaging prevents transit damage to the finished surface.
Expert guidance on bracket installation and chassis mounting procedures. We help ensure your DZ91189553761 brackets provide secure long‑term fuel tank support.
For current stock availability and delivery scheduling on the genuine Fuel Tank Bracket DZ91189553761, please use the contact buttons above.
