Water Valve Integrated Urea Tank Sensor
Датчик Мочевины с Клапаном
Sensor de Urea Integrado
OEM Water Valve Integrated Urea Tank Sensor DZ95259740567 precision‑calibrated for the Shacman X5000 selective catalytic reduction system. This sophisticated DZ95259740567 unit combines fluid quality sensing, level measurement, temperature monitoring, and coolant valve control in a single assembly.
Featuring an integrated water valve for tank heating and advanced sensor elements, the Water Valve Integrated Urea Tank Sensor DZ95259740567 provides comprehensive DEF management for reliable emissions compliance in all climate conditions.
Installing the genuine DZ95259740567 sensor assembly restores accurate SCR monitoring and prevents the fault codes that lead to engine derate and costly downtime.
| Parameter | Specification |
|---|---|
| OEM Part Number | DZ95259740567 |
| Product Name | Water Valve Integrated Urea Tank Sensor |
| Brand / Model | Shacman X5000 |
| Sensor Functions | Quality, level, temperature sensing with coolant valve |
| Valve Type | Solenoid‑actuated water valve for tank heating |
| Probe Length | 420.00 mm from mounting flange |
| Mounting Flange | 6‑bolt pattern with integrated seal |
| Electrical Connector | 8‑pin sealed connector with CAN bus communication |
| Operating Temperature | -40°C to +85°C sensor, valve to +120°C |
| Application | Shacman X5000 urea tank monitoring and heating control |
The DZ95259740567 water valve integrated urea tank sensor is the intelligence center of the Shacman X5000 DEF storage system. It continuously monitors the condition of the diesel exhaust fluid and reports data to the engine control module.
The quality sensing element uses ultrasonic or optical technology to measure urea concentration, ensuring that only certified DEF with the correct 32.5 percent concentration is present in the tank. Incorrect fluids trigger an immediate warning.
The integrated water valve controls the flow of engine coolant through the tank heating circuit. When the DEF temperature approaches freezing, the valve opens to circulate warm coolant and thaw the fluid for proper SCR operation.
The DZ95259740567 sensor combines four functions in one unit, reducing the number of individual components that must be mounted on the urea tank. This integration simplifies tank design and reduces potential leak points.
The solenoid‑actuated water valve responds to commands from the engine control module, opening proportionally to regulate coolant flow based on DEF temperature. This precise control prevents energy waste while ensuring reliable thawing performance.
The DZ95259740567 sensor mounts into the top of the urea tank with a six‑bolt flange that compresses an integrated sealing gasket. The bolts must be tightened evenly in a star pattern to ensure uniform seal compression.
The coolant lines connect to the water valve ports with quick‑connect fittings. The electrical connector must be fully seated and the locking tab engaged to prevent moisture ingress into the sensitive electronic circuits.
Every DZ95259740567 sensor assembly undergoes a multi‑point calibration using reference urea solutions of known concentration and temperature. The sensor outputs must fall within specified tolerance bands across the full measurement range.
The water valve is cycled through its full operating range while monitoring response time and leakage. The valve must open and close within specified time limits and show zero external leakage at rated pressure.
A faulty DZ95259740567 sensor typically generates diagnostic trouble codes related to DEF quality, level signal implausibility, or water valve circuit malfunctions. Multiple fault codes may appear simultaneously.
Crystallized urea deposits on the sensor probe can cause inaccurate quality readings. The probe should be cleaned with distilled water if contamination is suspected before concluding that the sensor has failed.
When replacing the sensor, the tank interior should be inspected for contamination or sludge accumulation. The sealing surface on the tank must be clean and undamaged to ensure a proper seal with the new sensor flange.
The DZ95259740567 sensor is specifically programmed for the Shacman X5000 engine management system. Its calibration parameters and communication protocols are matched to this vehicle platform.
Fleet operators benefit from the comprehensive monitoring provided by this integrated sensor. Accurate DEF quality and level data enable condition‑based maintenance and prevent the SCR‑related derates that interrupt operations.
Aftermarket sensors with unverified calibration or inferior valve components can cause persistent SCR system faults. We supply only the authentic Shacman X5000 Water Valve Integrated Urea Tank Sensor DZ95259740567.
Each sensor is factory‑calibrated and packaged in a protective container with desiccant. The part number DZ95259740567 is clearly marked on both the sensor body and the packaging for immediate identification.
Our international distribution network ensures that genuine DZ95259740567 sensor assemblies are available for immediate dispatch to dealerships and fleet maintenance facilities across all major continents.
Complete integrated sensor assembly with water valve, mounting flange, and sealing gasket. Factory‑calibrated and ready for installation.
Expert guidance on sensor installation and SCR system diagnostics. We help ensure your DZ95259740567 assembly provides accurate DEF monitoring and heating control.
For current stock availability and pricing on the genuine Water Valve Integrated Urea Tank Sensor DZ95259740567, please use the contact buttons above.
