Intake Steel Pipe Assembly
Стальной Впускной Патрубок
Tubo de Admisión de Acero
OEM Intake Steel Pipe Assembly DZ97259198012 precision‑engineered for the Shacman X5000 air induction system. This robust DZ97259198012 rigid duct section channels clean filtered air from the flexible outlet hose to the turbocharger compressor inlet.
Fabricated from mandrel‑bent steel tubing with durable anti‑corrosion coating, the Intake Steel Pipe Assembly DZ97259198012 maintains its shape under turbocharger suction while providing precise routing in the engine bay.
Replacing a damaged or leaking intake pipe with the genuine DZ97259198012 assembly ensures unrestricted airflow to the turbocharger and prevents the dust ingestion that accelerates engine wear.
| Parameter | Specification |
|---|---|
| OEM Part Number | DZ97259198012 |
| Product Name | Intake Steel Pipe Assembly |
| Brand / Model | Shacman X5000 |
| Material | Mandrel‑Bent Steel Tube with High‑Temp Coating |
| Pipe Outer Diameter | Approximately 100.00 mm |
| Wall Thickness | 1.50 mm |
| Connection Type | Hose couplers with clamp retention at both ends |
| Corrosion Protection | High‑temperature resistant coating |
| Vacuum Resistance | Maintains shape under maximum turbocharger suction |
| Application | Shacman X5000 air filter outlet to turbocharger intake connection |
The DZ97259198012 intake steel pipe assembly forms a rigid section of the Shacman X5000 clean air duct between the flexible rubber outlet hose and the turbocharger compressor housing inlet.
The mandrel‑bent steel construction provides a smooth internal bore with consistent diameter, minimizing airflow turbulence and pressure drop in the critical section immediately before the turbocharger.
This pipe is designed to resist the strong suction pulses generated by the turbocharger compressor wheel, maintaining its circular cross‑section under vacuum conditions that would collapse unreinforced flexible ducts.
The DZ97259198012 pipe is manufactured using a mandrel bending process that maintains a constant internal diameter throughout any curves, eliminating flow‑restricting wrinkles.
The high‑temperature coating applied to the exterior resists discoloration and corrosion from under‑hood heat exposure, maintaining the pipe’s structural integrity and professional appearance over time.
The DZ97259198012 pipe connects to the rubber outlet hose and turbocharger inlet using flexible couplers and constant‑tension clamps. All connections must be fully seated and tightened to specification.
The pipe should be inspected during air filter service for cracks, loose connections, or coating damage. Any air leak in this section allows unfiltered air to bypass the filtration system entirely.
Each production batch of DZ97259198012 pipe assemblies undergoes dimensional inspection to verify bend angles, connection diameters, and overall routing against engineering specifications.
Vacuum integrity testing confirms the pipe and its welded joints maintain structural integrity under the maximum suction that the turbocharger can generate at rated engine speed and full load.
Rust staining or coating delamination on the DZ97259198012 pipe indicates corrosion has penetrated the protective layer. Pitting can eventually perforate the tube wall, causing air leaks.
A dented or partially collapsed pipe section restricts airflow to the turbocharger, reducing engine power and causing excessive exhaust smoke from incomplete fuel combustion under load.
During air induction system service, the steel intake pipe should be inspected for physical damage, corrosion, and secure connections. Damaged pipes must be replaced to maintain proper airflow.
The DZ97259198012 pipe is specifically formed for the Shacman X5000 engine bay routing, with connection diameters and geometry matching the air filter outlet and turbocharger inlet configuration.
Fleet workshops should maintain spare intake pipe assemblies for prompt replacement when collision damage or corrosion compromises the original component during vehicle service operations.
Aftermarket intake pipes with incorrect profiles can restrict airflow or fail under vacuum. We supply only the authentic Shacman X5000 Intake Steel Pipe Assembly DZ97259198012 built to OEM standards.
Each assembly is individually packaged with protective end covers. The part number DZ97259198012 is clearly printed on the packaging for immediate identification and verification.
Our international logistics network ensures genuine DZ97259198012 intake steel pipe assemblies are available for dispatch to dealerships and fleet maintenance facilities worldwide.
Complete intake steel pipe assembly with protective end covers. Ready for installation with standard hose couplers and constant‑tension clamps.
Expert guidance on intake pipe installation and air induction system inspection. We help ensure your DZ97259198012 pipe delivers clean, unrestricted airflow.
For current stock availability on the genuine Intake Steel Pipe Assembly DZ97259198012, please use the contact buttons above.
