Brake Pedal Assembly
Педаль Тормоза
Pedal de Freno
OEM Brake Pedal Assembly 81.48235.5042 precision‑engineered for the Shacman X5000 hydraulic braking system. This critical 81.48235.5042 safety component converts driver foot input into hydraulic pressure for reliable vehicle deceleration and stopping.
Featuring hardened pivot pins, self‑lubricating bushings, and a rigid steel mounting frame, the Brake Pedal Assembly 81.48235.5042 delivers consistent pedal feel and dependable brake actuation through millions of cycles.
Replacing a worn or damaged brake pedal assembly with the genuine 81.48235.5042 component restores proper braking control and maintains the vehicle safety performance designed by the manufacturer.
| Parameter | Specification |
|---|---|
| OEM Part Number | 81.48235.5042 |
| Product Name | Brake Pedal Assembly |
| Brand / Model | Shacman X5000 |
| Frame Material | High‑Strength Steel with Black E‑coat |
| Pivot Pins | Hardened steel with phosphate coating |
| Bushing Type | Self‑lubricating composite bushings |
| Mounting Pattern | 4‑bolt cab floor mount, M10 fasteners |
| Master Cylinder Interface | Clevis pin connection with push rod |
| Corrosion Protection | Electrophoretic coating, 480 hours salt spray rated |
| Application | Shacman X5000 hydraulic brake actuation system |
The 81.48235.5042 brake pedal assembly is the driver’s primary interface with the Shacman X5000 braking system. It converts foot pressure into hydraulic force distributed to all wheel brake chambers.
The pedal lever ratio is engineered to provide optimal mechanical advantage, allowing the driver to modulate braking force precisely while generating sufficient hydraulic pressure for full brake application.
The Brake Pedal Assembly 81.48235.5042 incorporates a return spring that ensures the pedal returns fully when released, preventing unintended brake drag and ensuring complete master cylinder piston retraction.
The 81.48235.5042 assembly uses hardened steel pivot pins with a phosphate coating. Self‑lubricating composite bushings eliminate periodic grease requirements while ensuring smooth operation.
This bearing combination delivers consistent pedal feel throughout the assembly’s service life without developing the squeaks or stiffness that compromise braking precision and driver confidence.
The 81.48235.5042 assembly bolts to the cab floor. The master cylinder push rod connects via a clevis pin, and free play must be adjusted according to service manual specifications.
Proper adjustment ensures the master cylinder piston returns fully when the pedal is released, preventing the hydraulic lock that causes brake drag, overheating, and premature lining wear.
Each production batch of 81.48235.5042 assemblies undergoes dimensional verification of pivot points and mounting hole positions to ensure correct pedal geometry when installed.
Cycle testing subjects sample assemblies to millions of actuation cycles while monitoring bushing wear, spring tension, and pivot pin integrity to validate long‑term durability under real‑world conditions.
Excessive side‑to‑side pedal movement indicates worn bushings in the 81.48235.5042 assembly. Squeaking or clicking suggests dry or damaged pivot pins requiring immediate replacement.
A pedal that does not return fully may indicate a broken return spring or binding in the linkage. This condition must be corrected immediately to prevent brake drag and potential overheating.
During cab inspections, the brake pedal assembly should be checked for smooth operation and secure mounting. Any damage to this safety‑critical component must be addressed before returning the vehicle to service.
The 81.48235.5042 assembly is specifically configured for the Shacman X5000 hydraulic brake system and cab mounting pattern, matching factory specifications for this safety‑critical application.
Fleet workshops should maintain spare brake pedal assemblies for replacement during brake system service, ensuring continued reliable and safe vehicle operation on the road.
Aftermarket brake pedal assemblies with incorrect geometry can compromise braking safety. We supply only the authentic Shacman X5000 Brake Pedal Assembly 81.48235.5042 built to OEM specifications.
Each assembly is individually packaged with protective wrapping. The part number 81.48235.5042 is clearly printed on the packaging for immediate identification and verification.
Our international logistics network ensures genuine 81.48235.5042 brake pedal assemblies are available for dispatch to dealerships and fleet facilities across all major continents.
Complete brake pedal assembly with frame, pedal arm, pivot pins, bushings, and return spring. Ready for cab installation and push rod connection.
Expert guidance on brake pedal installation and push rod adjustment. We help ensure your 81.48235.5042 assembly delivers reliable braking performance.
For current stock availability on the genuine Brake Pedal Assembly 81.48235.5042, please use the contact buttons above.
