Front View Mirror Assembly
Сборка переднего зеркала
Conjunto de espejo delantero
The Shacman X5000 Front View Mirror Assembly, genuine OEM part DZ14251771013, is a purpose‑built component for both left‑hand and right‑hand drive versions of the X5000 cab. This assembly integrates a wide‑angle convex mirror with a robust mounting bracket, delivering enhanced forward visibility to reduce the dangerous blind spot immediately ahead of the truck. The DZ14251771013 mirror is designed to meet ECE R46 safety standards, ensuring that drivers can spot pedestrians, obstacles, and curbs during tight maneuvers. As a direct replacement for the original equipment, it guarantees perfect fitment, vibration‑free operation, and lasting optical clarity in the most demanding transport environments.
The housing is moulded from impact‑resistant ABS plastic with a UV‑stable coating, while the glass features a high‑reflectivity silver coating that resists tarnishing. The internal tilt‑and‑swivel mechanism allows precise adjustment to suit individual driver preferences, and the steel bracket incorporates rubber isolators to dampen cab vibrations. This assembly is a straightforward bolt‑on solution for restoring or upgrading the front mirror on any Shacman X5000 truck, providing immediate safety benefits and compliance with international visibility regulations.
| Parameter | Specification |
|---|---|
| OEM Part Number | DZ14251771013 |
| Product Name | Front View Mirror Assembly (J-type, D/RHD) |
| Brand | Shacman (Genuine OEM) |
| Vehicle Compatibility | Shacman X5000 (LHD & RHD cab variants) |
| Mirror Type | Convex (wide‑angle), manual adjustment |
| Housing Material | UV‑stabilized ABS plastic, matte black |
| Bracket Material | Steel, powder‑coated, with rubber isolators |
| Glass Dimensions | Approx. 275mm (W) x 175mm (H) |
| Adjustment Range | ±15° tilt, ±20° rotation (knob‑operated) |
| Weight (approx.) | 1.9 kg (with bracket and hardware) |
| Certification | ECE R46, FMVSS 111 compliant |
| Operating Temperature | -40°C to +85°C |
| Included Hardware | Bolts, washers, trim covers, and adjustment knobs |
The DZ14251771013 front view mirror is the outcome of advanced optical simulation and aerodynamic testing. Its compact, streamlined housing reduces wind noise and drag, while the convex glass profile delivers a distortion‑free panorama of the front corner zones. The internal pivot mechanism uses self‑lubricating nylon bearings that provide smooth, precise adjustments without play, even after years of use.
Shacman engineers have placed the mirror at an optimal height and angle to complement the cab’s A‑pillar, ensuring that the driver’s line of sight to the front ground area is unobstructed. The bracket incorporates a break‑away safety feature that allows the mirror to deflect on impact, reducing the risk of cab damage in low‑speed collisions. The entire assembly is tested to withstand 15g vibration loads and extreme temperature swings, guaranteeing reliable performance in all climates.
The mirror glass is treated with an anti‑glare coating that balances reflectance and light transmission, providing clear images both day and night. The housing includes a rubber seal that prevents moisture ingress, ensuring that internal components remain dry and functional. This attention to detail makes the DZ14251771013 a superior choice for safety‑conscious fleets.
The convex mirror surface expands the horizontal field of view to approximately 120°, allowing the driver to see the ground directly in front of the bumper. This is crucial for detecting children, bollards, or loading dock edges that are otherwise invisible from the cab. The reflective coating maintains 92% reflectivity, ensuring bright, sharp images even in low‑light conditions.
The front view mirror is a mandatory safety device in many jurisdictions, as it eliminates the blind spot that can hide vulnerable road users. Without a functional mirror, the driver cannot see directly ahead, increasing the risk of pedestrian accidents or front‑end collisions. The DZ14251771013 assembly ensures that the mirror is correctly positioned and securely held, providing a consistent, vibration‑free image that supports safe driving.
In fleet operations, a damaged or missing front mirror can lead to drivers misjudging distances, resulting in expensive repairs and liability claims. By using the genuine Shacman mirror, you restore the original safety standards of the X5000 cab, protecting both drivers and other road users. The mirror’s durable construction also means fewer replacements over the vehicle’s life, reducing total maintenance costs.
Regular checks of the mirror’s tightness and glass condition are recommended, but the OEM design minimizes common failure points such as loose pivots or cracked housings. This reliability is especially important for trucks operating in urban environments where frequent low‑speed maneuvers demand constant visibility.
Heavy‑duty engines and rough roads generate significant cab vibrations that can make mirrors flutter, reducing image clarity and causing driver eye strain. The DZ14251771013 uses rubber‑isolated mounting points and a balanced pivot system that effectively absorbs high‑frequency vibrations, ensuring that the mirror remains steady and the image stays crisp at all engine speeds.
Installing the DZ14251771013 mirror assembly is a simple, tool‑friendly process. The kit includes the mirror head pre‑attached to its steel bracket, along with all necessary bolts, washers, and decorative trim covers. The bracket aligns with the factory mounting points on the X5000 cab’s A‑pillar or door frame, requiring no drilling or modifications.
To install, remove the old mirror by unbolting its bracket. Position the new assembly, insert the bolts, and tighten them to the specified torque (22‑28 Nm). Adjust the mirror angle using the two knobs until the desired view is achieved, then secure the locking screws. The entire procedure takes less than 30 minutes for a trained technician.
Compatibility covers all Shacman X5000 models produced from 2018 onward, including both left‑hand drive and right‑hand drive configurations. Always verify your vehicle’s original part number against DZ14251771013 to ensure a correct match. Using the OEM mirror preserves the cab’s aerodynamic integrity and maintains its safety certification.
Clean the mirror glass regularly with a soft cloth and a non‑abrasive glass cleaner to avoid scratching the reflective surface. Inspect the bracket bolts for tightness during every scheduled service. If the mirror becomes loose, tighten the pivot screws gently – do not over‑tighten as this can strip the threads. Replace the assembly if the glass becomes cracked or the housing is damaged.
The Shacman X5000 is a versatile platform used in container haulage, construction, mining, and long‑distance freight. In each application, the front view mirror DZ14251771013 proves invaluable. For port operations, it helps drivers navigate between tightly packed containers with precision. On construction sites, it assists in avoiding ground obstacles like rebar, pipes, or uneven terrain that could damage the truck’s underside.
In long‑haul trucking, the mirror reduces stress during tight parking at rest areas, fuel stations, and loading docks. The UV‑stable housing ensures that the mirror maintains its appearance and structural integrity even after years of sun exposure in desert climates. The assembly is also compatible with optional heater elements (sold separately), providing de‑icing capability for cold‑weather operations.
This mirror is equally suited for municipal services such as garbage collection or street sweeping, where frequent stops and tight turns demand maximum front visibility. Its rugged design and compliance with international standards make it a reliable choice for any X5000 fleet.
Choosing the genuine DZ14251771013 ensures that you receive a mirror built to Shacman’s exact specifications. Unlike aftermarket alternatives that may use inferior plastics, incorrect curvature, or non‑compliant glass, the OEM mirror delivers the correct field of view, accurate reflection, and a mounting system that resists fatigue over millions of kilometers.
The OEM mirror also fits perfectly without the need for adapter plates or modifications that could compromise the cab’s structural integrity. This is vital for maintaining the vehicle’s crashworthiness and warranty coverage. Furthermore, the genuine part comes with a clear part number and full traceability, giving fleet managers confidence in its origin and quality.
For fleet operators, the slightly higher upfront cost of the OEM mirror is offset by its longer service life and reduced downtime. A failed aftermarket mirror may vibrate excessively, loose adjustment, or fog up internally – problems that are virtually eliminated with the Shacman original. Over a fleet’s lifetime, using genuine mirrors reduces total cost of ownership.
Considering that a single front‑end collision caused by poor visibility can cost tens of thousands in repairs and liability, the price of the OEM mirror is negligible. It provides an immediate safety upgrade and peace of mind. The durable construction also means fewer replacements, lowering long‑term maintenance expenditure.
Every DZ14251771013 mirror assembly is produced in an IATF 16949 certified facility under Shacman’s stringent quality control. The process includes injection moulding of the housing with precision‑machined tooling, CNC‑cut glass with edge polishing, and robotic assembly of the pivot mechanism. Each unit undergoes a 100% visual inspection, plus functional tests for adjustment torque and locking stability.
Random samples are subjected to accelerated weathering (UV, thermal cycling) and vibration tests that simulate years of service. The glass is tested for optical distortion using laser interferometry, ensuring that every mirror meets the required curvature tolerance. These rigorous procedures ensure that each assembly delivers consistent, reliable performance.
The part number is laser‑etched on the bracket for easy identification, and each unit is packaged with a serialised quality certificate. This level of traceability is not offered by generic products, making the genuine mirror the only choice for safety‑critical applications.
The genuine Shacman front view mirror DZ14251771013 is available through authorised distributors worldwide. Each assembly is packed in a custom‑moulded foam insert inside a heavy‑duty carton to prevent damage during transit. For large fleets, volume discounts and express shipping options are available through Shacman’s global logistics network.
Emergency orders can be fulfilled within 48 hours in most regions, minimising vehicle downtime. Always purchase from verified dealers to avoid counterfeit products that may lack safety certifications. The genuine packaging includes a Shacman hologram and a QR code for instant authenticity verification.
The Shacman Front View Mirror Assembly DZ14251771013 is a critical safety component that enhances forward visibility for X5000 drivers. With its robust construction, precise optics, and perfect fitment, this genuine OEM mirror ensures that blind spots are minimised and manoeuvres are executed with confidence. By choosing the DZ14251771013, you invest in driver safety, fleet efficiency, and long‑term reliability – the hallmarks of Shacman quality.
