Telescopic Transmission Shaft
Телескопический Трансмиссионный Вал
Eje de Transmisión Telescópico
OEM Telescopic Transmission Shaft 4010101-DZ9114312072 precision‑engineered for the Shacman X5000 driveline system. This balanced 4010101-DZ9114312072 assembly transmits torque between the transmission output and the rear drive axle with reliable power transfer under all conditions.
Constructed from high‑strength alloy steel with hardened splines and precision‑welded yokes, the Telescopic Transmission Shaft 4010101-DZ9114312072 withstands torsional loads and vibration of heavy‑duty commercial operation.
Replacing a bent or worn telescopic transmission shaft with the genuine 4010101-DZ9114312072 component restores proper driveline alignment and prevents the vibration that causes bearing and seal damage.
| Parameter | Specification |
|---|---|
| OEM Part Number | 4010101-DZ9114312072 |
| Product Name | Telescopic Transmission Shaft |
| Brand / Model | Shacman X5000 |
| Material | High‑Strength Alloy Steel, Induction‑Hardened Splines |
| Shaft Type | Telescopic / Slip-Type Driveline Shaft |
| Spline Specification | Involute spline at sliding joint end, precision ground |
| Surface Hardness | HRC 55‑60 on spline and bearing surfaces |
| Corrosion Protection | Phosphate coating with anti‑corrosion oil film |
| Balancing Standard | ISO 1940 G16, dynamically balanced |
| Max Torque Capacity | 12,800 Nm |
| Max Rotational Speed | 3600 rpm continuous |
| Universal Joint Type | Heavy‑duty cross bearing with grease fitting |
| Overall Length (flange to flange) | 1220 mm (telescopic range: 980‑1280 mm) |
| Net Weight | 34.5 kg ±0.6 kg |
| Certifications | IATF 16949, ISO 9001:2025, OEM Approved |
The 4010101-DZ9114312072 telescopic transmission shaft is a critical driveline component that connects the transmission output to the rear axle input. It transmits engine torque through universal joints while accommodating chassis movement.
As the rear axle moves vertically through suspension travel, the shaft’s slip joint accommodates length changes. The balanced design ensures smooth rotation without vibration at highway speeds under load.
The induction‑hardened splines and precision‑welded yokes resist wear under high‑torque loading, maintaining secure attachment to universal joint assemblies throughout the vehicle’s extended service intervals.
The 4010101-DZ9114312072 shaft is manufactured from high‑strength alloy steel with induction‑hardened spline surfaces, providing excellent wear resistance at the critical sliding joint interface.
The phosphate coating provides corrosion protection while the anti‑corrosion oil film helps prevent fretting at the spline connections with the universal joint yokes during high‑torque operation.
The 4010101-DZ9114312072 shaft installs between the transmission and rear axle with universal joint connections. Correct yoke phasing is essential to prevent driveline vibration during rotation.
Driveline angular alignment should be verified after installation to ensure operating angles at both universal joints are within specification, preventing premature joint and bearing wear in service.
Each 4010101-DZ9114312072 shaft undergoes dynamic balancing to minimize vibration at highway speeds. Correction weights are applied as needed to meet the balance grade for heavy‑duty driveline applications.
Spline fit and weld integrity are verified during assembly to ensure proper function and structural reliability throughout the demanding duty cycles of commercial vehicle driveline operation.
Driveline vibration that increases with speed indicates the 4010101-DZ9114312072 shaft may be bent, out of balance, or have worn splines causing excessive runout during high‑speed rotation under load.
Worn or fretted splines create driveline backlash producing a clunking sound during acceleration or deceleration, requiring shaft inspection and possible replacement to prevent further component damage.
During driveline service, the shaft should be inspected for straightness, spline condition, and universal joint wear. Damaged shafts must be replaced to maintain driveline reliability and safe vehicle operation.
The 4010101-DZ9114312072 shaft is specifically configured for the Shacman X5000 telescopic driveline position, with spline dimensions, overall length, and balance specification matching this vehicle platform.
Fleet operators should maintain spare telescopic transmission shafts and universal joint components for prompt replacement when driveline issues are diagnosed, minimizing vehicle downtime from driveline failures.
Aftermarket telescopic transmission shafts with incorrect specifications can cause driveline vibration. We supply only the authentic Shacman X5000 Telescopic Transmission Shaft 4010101-DZ9114312072 built to OEM specifications.
Each shaft is individually packaged with protective coating and yoke guards. The part number 4010101-DZ9114312072 is clearly printed on the packaging for immediate identification and verification.
Our international logistics network ensures genuine 4010101-DZ9114312072 telescopic transmission shafts are available for dispatch to dealerships and fleet maintenance facilities worldwide.
Complete telescopic transmission shaft assembly with welded yokes, hardened splines, and dynamic balancing. Ready for driveline installation with appropriate hardware.
Expert guidance on telescopic transmission shaft installation and driveline alignment. We help ensure your 4010101-DZ9114312072 shaft provides smooth torque transmission.
For current stock availability on the genuine Telescopic Transmission Shaft 4010101-DZ9114312072, please use the contact buttons above.
