Cross Beam
Поперечная Балка
Travesaño Transversal
OEM Cross Beam DZ95259594126 precision‑engineered for the Shacman X5000 heavy‑duty truck chassis. This structural DZ95259594126 member spans between the left and right frame rails, providing essential lateral stability and torsional resistance under load.
Fabricated from high‑strength structural steel with durable anti‑corrosion coating, the Cross Beam DZ95259594126 maintains precise frame geometry while serving as a mounting foundation for critical vehicle systems and accessories.
Replacing a damaged or corroded cross beam with the genuine DZ95259594126 component restores proper chassis stiffness and prevents the frame misalignment that affects handling and component life.
| Parameter | Specification |
|---|---|
| OEM Part Number | DZ95259594126 |
| Product Name | Cross Beam |
| Brand / Model | Shacman X5000 |
| Material | High‑Strength Structural Steel with Black E‑coat |
| Beam Profile | C‑channel section with reinforcement gussets |
| Overall Length | Approximately 845.00 mm |
| Mounting Bolt Pattern | Multiple bolt holes at each end, 12 mm diameter |
| Load Capacity | Engineered for heavy‑duty chassis reinforcement |
| Corrosion Protection | Electrophoretic coating, 480 hours salt spray rated |
| Application | Shacman X5000 chassis frame lateral bracing |
The DZ95259594126 cross beam is an integral chassis component that connects the left and right longitudinal frame rails at a designated location along the vehicle’s length. It prevents the rails from spreading or twisting relative to each other.
When a heavy truck traverses uneven surfaces, the frame experiences torsional loading that tries to twist one rail relative to the other. The cross beam resists this twisting motion, maintaining the structural integrity of the entire frame assembly.
The Cross Beam DZ95259594126 also functions as a mounting platform for various chassis‑mounted components, providing secure attachment points for the urea supply module, air reservoirs, exhaust brackets, and related hardware.
The DZ95259594126 cross beam features a C‑channel profile that provides excellent bending strength with efficient use of material. The open side of the channel allows access for bolt installation and wiring routing.
Strategic reinforcement gussets are welded at high‑stress locations to distribute loads and prevent localized deformation. These gussets increase the fatigue life of the cross beam under the cyclical loading of vehicle operation.
The DZ95259594126 cross beam bolts to pre‑drilled holes in the chassis frame rails using high‑strength fasteners. The bolts must be installed loosely initially, then tightened progressively after verifying frame alignment.
Correct cross beam installation requires that the frame rails be parallel and at the specified distance apart. Forcing the cross beam into position with misaligned rails introduces residual stresses that can lead to premature cracking.
Each production batch of DZ95259594126 cross beams undergoes dimensional inspection to verify overall length, hole positions, and flange angles. These critical dimensions must conform to engineering specifications.
Weld integrity is verified through visual inspection and sampling with non‑destructive testing methods. All welded joints must be free of cracks, porosity, and incomplete fusion that could compromise structural performance.
Rust staining or bubbling of the e‑coat on the DZ95259594126 cross beam indicates that corrosion has penetrated the protective layer. If unchecked, this corrosion reduces the effective thickness and load‑carrying capacity.
Cracks visible at bolt holes, gusset welds, or flange bends are serious structural defects. A cracked cross beam must be replaced immediately to prevent frame distortion and potential separation of chassis components.
During routine chassis inspections, the cross beam and its mounting hardware should be checked for tightness and structural condition. Loose or missing bolts allow movement that accelerates wear and fatigue at the connection points.
The DZ95259594126 cross beam is specifically configured for the Shacman X5000 chassis frame rail spacing and bolt hole patterns. It matches the factory‑specified mounting locations for this vehicle platform.
Fleet operators should maintain spare cross beams in their chassis parts inventory. Prompt replacement of damaged beams maintains vehicle structural integrity and prevents the progressive damage that frame distortion causes.
Aftermarket cross beams with inadequate material specifications or incorrect dimensions can compromise chassis safety. We supply only the authentic Shacman X5000 Cross Beam DZ95259594126 built to OEM standards.
Each cross beam is individually packaged with protective edge guards to prevent coating damage during transit. The part number DZ95259594126 is clearly displayed on the component label and shipping documentation.
Our international supply chain maintains strategic stock levels to support fleet operators and service facilities worldwide. Genuine DZ95259594126 cross beams are dispatched promptly to minimize vehicle downtime.
Complete cross beam with welded reinforcement gussets and e‑coat finish. Mounting hardware available separately for chassis frame installation.
Expert guidance on cross beam installation and frame alignment procedures. We help ensure your DZ95259594126 beam provides reliable chassis reinforcement.
For current stock availability and delivery scheduling on the genuine Cross Beam DZ95259594126, please use the contact buttons above.
