OEM Angle Plate 81.41506.2724 precision‑formed for the Shacman X5000 heavy‑duty truck. This versatile 81.41506.2724 bracket provides rigid 90‑degree mounting support for various chassis and body components, ensuring secure attachment and proper alignment.
Manufactured from high‑strength structural steel with comprehensive corrosion protection, the Angle Plate 81.41506.2724 withstands the mechanical stresses and environmental exposure encountered in demanding commercial vehicle applications.
Replacing a damaged or corroded angle plate with the genuine 81.41506.2724 component restores proper component support and prevents the misalignment that leads to accelerated wear and structural fatigue.
| Parameter | Specification |
|---|---|
| OEM Part Number | 81.41506.2724 |
| Product Name | Angle Plate |
| Brand / Model | Shacman X5000 |
| Material | High‑Strength Structural Steel with Zinc‑Nickel Plating |
| Plate Dimensions | 120.00 mm × 80.00 mm × 65.00 mm |
| Material Thickness | 5.00 mm |
| Mounting Hole Diameter | 10.50 mm (multiple mounting points) |
| Bend Angle | 90 degrees ± 1 degree |
| Corrosion Protection | Zinc‑Nickel plating, 720 hours salt spray rated |
| Application | Shacman X5000 chassis and body component mounting |
The 81.41506.2724 angle plate serves as a fundamental building block in the Shacman X5000 chassis and body assembly. It provides rigid 90‑degree connections between structural members, creating strong corner joints.
In heavy truck construction, angle plates are used to mount steps, battery boxes, tool storage compartments, mudguard brackets, and various other accessories to the chassis frame. They distribute loads over a wider area than individual bolts.
The Angle Plate 81.41506.2724 also serves as a reinforcement gusset at frame joints, increasing the stiffness of bolted connections and reducing the stress concentrations that can lead to fatigue cracking over time.
The 81.41506.2724 angle plate is fabricated from 5‑millimeter thick structural steel plate, providing substantial load‑bearing capacity and resistance to bending deformation under the weight of mounted components.
The zinc‑nickel electroplating provides superior corrosion protection compared to conventional zinc coatings, withstanding 720 hours of neutral salt spray exposure. This plating ensures long‑term durability in harsh under‑chassis environments.
The 81.41506.2724 angle plate is installed using high‑strength bolts through the pre‑punched mounting holes. The bolts should be tightened to the specified torque using a calibrated torque wrench for consistent clamping force.
When mounting components to the angle plate, the load should be distributed as evenly as possible across the available bolt holes. Concentrating the load on a single hole can overstress the plate and lead to localized deformation.
Each production batch of 81.41506.2724 angle plates is sampled for dimensional inspection. The bend angle, hole positions, and overall dimensions are verified against engineering drawings using precision measurement equipment.
The zinc‑nickel plating thickness is measured using X‑ray fluorescence spectroscopy to ensure it meets the minimum specification across all surfaces. Plating adhesion is verified through bend testing of sample coupons.
Rust staining or flaking of the plating on the 81.41506.2724 angle plate indicates that the zinc‑nickel layer has been compromised. If corrosion penetrates the base steel, the effective thickness is reduced and structural capacity diminishes.
Cracks radiating from bolt holes or along the bend line are evidence of fatigue or overload. Cracked angle plates must be replaced immediately to prevent the supported component from becoming detached during vehicle operation.
During routine vehicle inspections, all visible angle plates should be checked for tightness and condition. Loose or missing bolts allow movement that accelerates wear on both the plate and the attached component.
The 81.41506.2724 angle plate is dimensioned for specific mounting locations on the Shacman X5000 chassis and body. Its hole pattern and bend configuration match the factory‑specified attachment points.
Fleet workshops should maintain a stock of these angle plates as part of their standard hardware inventory. Having genuine plates readily available supports prompt repairs when collision damage or corrosion necessitates replacement.
Aftermarket angle plates with thinner material or inferior plating can fail prematurely in service. We supply only the authentic Shacman X5000 Angle Plate 81.41506.2724 manufactured to OEM specifications.
Each angle plate is individually packaged to protect the plated surface during handling and transit. The part number 81.41506.2724 is clearly displayed on both the component label and packaging.
Our international supply chain ensures that genuine 81.41506.2724 angle plates are available for immediate dispatch to dealerships and fleet maintenance facilities across all major continents.
Single angle plate with zinc‑nickel protective plating. Mounting hardware available separately. Protective packaging prevents surface damage during transit.
Expert guidance on angle plate installation and load distribution. We help ensure your 81.41506.2724 plates provide reliable long‑term structural support.
For current stock availability and pricing on the genuine Angle Plate 81.41506.2724, please use the contact buttons above.
