Engine Left Rear Bracket
Кронштейн Двигателя
Soporte Trasero Izquierdo
OEM Engine Left Rear Bracket DZ96259590221 precision‑cast for the Shacman X5000 heavy‑duty diesel engine. This robust DZ96259590221 mounting component secures the powertrain at the left rear position, maintaining proper engine alignment under torque loads.
Manufactured from high‑strength ductile iron with precision‑machined mounting faces, the Engine Left Rear Bracket DZ96259590221 provides a rigid connection between the engine block and the chassis mounting isolator.
Replacing a cracked or distorted bracket with the genuine DZ96259590221 component restores proper engine positioning and prevents the driveline misalignment that causes vibration and premature wear.
| Parameter | Specification |
|---|---|
| OEM Part Number | DZ96259590221 |
| Product Name | Engine Left Rear Bracket |
| Brand / Model | Shacman X5000 |
| Material | Ductile Iron GJS‑500‑7 with Machined Faces |
| Engine Block Bolt Pattern | 4‑bolt pattern, M14 threaded holes |
| Mount Isolator Hole Diameter | 16.00 mm through hole |
| Overall Dimensions | Approximately 185.00 mm × 125.00 mm × 95.00 mm |
| Surface Finish | Machined mounting pads, black painted |
| Tensile Strength | ≥ 500 MPa |
| Application | Shacman X5000 engine left rear mounting to chassis |
The DZ96259590221 engine left rear bracket is a vital powertrain mounting component that transfers the engine’s weight and torque reaction forces into the chassis frame. It positions the engine precisely within the engine bay.
During acceleration and engine braking, significant torsional forces act on the engine mounts. The bracket must withstand these cyclical loads without fatigue cracking, while maintaining the correct alignment of the driveline.
The Engine Left Rear Bracket DZ96259590221 also provides the mounting interface for the rubber isolator that absorbs engine vibration, preventing it from being transmitted through the chassis into the cab and steering components.
The DZ96259590221 bracket is cast from GJS‑500‑7 ductile iron, a material that combines high tensile strength with excellent elongation and impact resistance. It withstands shock loads without brittle fracture.
The spheroidal graphite structure inherent to ductile iron provides natural vibration damping that helps reduce the transmission of engine noise and vibration into the vehicle structure.
The DZ96259590221 bracket bolts to the engine block using high‑strength fasteners that must be tightened to the specified torque in the correct sequence. The mating surfaces must be clean and free of oil or debris.
The chassis‑side isolator bolt passes through the bracket hole and must be torqued after the engine weight is resting on the mounts. This ensures correct isolator preload and proper engine positioning.
Each production batch of DZ96259590221 brackets is sampled for dimensional inspection using coordinate measuring equipment. Critical mounting face positions and hole locations are verified against engineering drawings.
Hardness testing and microstructural analysis confirm that the material meets the GJS‑500‑7 specification. The machined faces are inspected for surface finish and flatness to ensure proper clamping.
Cracks visible on the DZ96259590221 bracket, particularly around bolt holes or at changes in cross‑section, are evidence of fatigue or overload. Cracked brackets must be replaced immediately to prevent engine mount failure.
Excessive engine movement or vibration that worsens under load may indicate a loose or broken bracket. The bracket bolts should be checked for proper torque during investigation of mounting system issues.
During engine overhaul or clutch replacement, the mounting brackets should be inspected for cracks, corrosion, or distortion. Any damage warrants replacement with a new Engine Left Rear Bracket DZ96259590221.
The DZ96259590221 bracket is specifically designed for the left rear mounting position on the Shacman X5000 engine. Its bolt pattern and dimensional configuration match this engine platform exactly.
Fleet operators should maintain spare engine mounting brackets for rapid replacement when damage is discovered. Prompt replacement prevents the progressive damage that loose engine mounts cause to driveline components.
Aftermarket brackets with incorrect material or dimensional inaccuracies can cause engine misalignment. We supply only the authentic Shacman X5000 Engine Left Rear Bracket DZ96259590221 built to OEM specifications.
Each bracket receives a protective black paint finish and is individually packaged. The part number DZ96259590221 is cast into the component for permanent identification.
Our international supply chain maintains strategic inventory levels to support fleet operators and engine rebuilders worldwide. Genuine DZ96259590221 brackets are dispatched promptly to minimize vehicle downtime.
Single engine left rear mounting bracket with machined faces and protective coating. Mounting hardware available separately.
Expert guidance on engine bracket installation and torque procedures. We help ensure your DZ96259590221 bracket provides reliable powertrain support.
For current stock availability and delivery information on the genuine Engine Left Rear Bracket DZ96259590221, please use the contact buttons above.
